KP-5032 and KP-4016
Keypanels
Technical Manual
Lever Key and Pushbutton Versions
up to and including version 2.1.1
includes support for
Control Package and Audio Package
Rev. 05
6/2017
F.01U.304.914
Advertisement
Table of Contents
Related Manuals for RTS KP-5032
Summarization of Contents
Introduction
Features
Describes the key features of the KP-4016/5032 series keypanels, highlighting digital audio and advanced signal processing.
Specifications
LCD Display
Details the active area, dot resolution, color resolution, and view angle for the LCD displays.
Power Supply
Specifies the type and AC input voltage for the power supply.
General Purpose Inputs and Outputs
Describes the type and rating of the general purpose inputs and outputs.
Inputs: Matrix
Details the specifications for matrix inputs, including type, level, impedance, and bandwidth.
Front Panel Mic
Lists the type, input level, impedance, and maximum input level for the front panel microphone.
Rear Panel Mic
Lists the type, input level, impedance, and maximum input level for the rear panel microphone.
Front and Rear Headset Mic - Electret
Specifies the electret headset mic input parameters like type, level, impedance, and max level.
Front and Rear Headset Mic - Dynamic
Specifies the dynamic headset mic input parameters like type, level, impedance, and max level.
Outputs: Matrix
Details the specifications for matrix outputs, including type, level, THD+N, impedance, and response.
MIC/LINE Out
Specifies the balanced MIC/LINE out parameters: type, level, THD+N, impedance, and response.
Headset - Front, Rear
Details headset output power, earphone impedance, THD+N, and frequency response.
Speaker - Rear
Details rear speaker output power, impedance, THD+N, and frequency response.
Speaker - Front
Specifies the front speaker SPL.
Digital: OMNEO Channels
States OMNEO channels latency and frequency response.
Environmental: Dimensions
Provides physical dimensions for KP-4016 and KP-5032 units.
Weight
Lists the weight of the keypanel, power supply, and mounting bracket.
Temperature
Specifies the operating and storage temperature ranges for the unit.
Power Consumption: KP-4016
Details nominal and maximum power consumption for the KP-4016.
Power Consumption: KP-5032
Details nominal and maximum power consumption for the KP-5032.
Certification: CE Compliance
Lists CE compliance details for EMC and Safety standards.
Block Diagram
KP-4016/5032 Audio Flow Block Diagram
Illustrates the audio signal flow for the KP-4016/5032 keypanels, including inputs and outputs.
Reference View
KP-5032 Reference View
Provides a detailed view of the front and rear panels of the KP-5032 keypanel.
KP-4016 Reference View
Provides a detailed view of the front and rear panels of the KP-4016 keypanel.
Connector Pinouts
Power Supply: J1
Details the pin assignments for the J1 power supply connector.
Rear Panel Mic: J6
Details the pin assignments for the J6 rear panel microphone connector.
Rear Speaker: J2
Details the pin assignments for the J2 rear speaker connector.
MIC OUT/LINE OUT: J7
Details the pin assignments for the J7 MIC OUT/LINE OUT connector.
Aux 1: J3
Details the pin assignments for the J3 Aux 1 connector.
Matrix Connector: J8
Details the pin assignments for the J8 matrix connector, including RJ-45 and RJ-12.
Aux 2: J4
Details the pin assignments for the J4 Aux 2 connector.
Rear Headset: J5
Details the pin assignments for the J5 rear headset connector.
Installation
Requirements
Lists the minimum firmware revision requirements for using AZedit, IPedit, MCII-e, etc.
KP-5032/5032PB Installation
Provides step-by-step instructions for installing the KP-5032/5032PB keypanel.
KP-4016/4016PB Installation
Provides step-by-step instructions for installing the KP-4016/4016PB keypanel.
Connecting the Keypanel to the Intercom
Explains how to connect the keypanel to the intercom system and configure network settings.
Power Up
Details the procedure for powering up the keypanel after installation and connection.
Address Setting
Explains the process of setting the keypanel's address for network communication.
Connections
Details the physical connections for the keypanel, including Frame, Ethernet, and microphone ports.
Headset Connector
Describes the headset connectors, including locating access holes for field-swapping.
Changing the Front Headset Connector
Provides instructions on how to replace the front panel headset connector on the keypanel.
GPIO 12-Position Terminal Block Connector
Details the GPIO connector, including wire specifications and connection/detachment procedures.
Speaker 2-Position Terminal Block Connector
Details the speaker connector, including wire specifications and connection/detachment procedures.
Footswitch Cabling
Explains how to cable and configure a footswitch for use with the keypanel.
Basic Operation
Intercom Keys and Displays
Explains how the KP-Series display uses colors to distinguish key assignment types.
Color Display Descriptions for Intercom Keys
Table defining the default key colors and their corresponding descriptions for intercom keys.
Display Icons
Provides a complete description of each icon seen on the KP-Series for feature status.
Keypad Reference View
Explains the different tiers of operation for a keypanel's keypad: Primary, SHIFT, and Dial Modes.
Keypad Button
Details the function of each key button, including Shift and Dial functions.
CLR Button
Explains the function of the CLR button for menu navigation and exiting.
Basic Key Operation
Explains basic key operation for lever keys, including talk, listen, and volume adjustment.
Pushbutton
Describes how to talk, listen, and adjust volume on pushbutton keypanels.
Talk/Listen Indicator
Explains the visual indicator for active talk and listen states on each key.
Key Gain Adjustment
Explains how to adjust crosspoint listen gain on specific keys using the keypanel or AUX encoder.
Keypanel Volume Adjustments
Details how to adjust the output volume for speakers or headsets using the MAIN VOLUME encoder.
Aux Volume Adjustments
Explains how to adjust input volumes for sources like Aux, Matrix, and OMNEO using the AUX VOLUME encoder.
Priority Call Volume Control
Explains how priority caller volume is enforced to ensure the caller is heard.
Operation of Intercom Keys with Auto Functions
Describes various auto functions for intercom keys, such as Talk+auto follow and All Call.
Operation of Intercom Keys with Options
Explains key options like Group, Solo, Exclusive, Lock, Chime, Clear, and Latching keys.
Operation of Intercom Talk Keys with the Speaker DIM Setting
Describes how the DIM setting affects speaker/headphone volume when talk keys are activated.
Operation of Intercom Keys assigned to TIF Ports
Explains how keys assigned to TIF ports activate the keypanel dialing menu.
User Quick Select Scrolling
Describes the feature for fast scrolling and calling or assigning point-to-point keys.
Graphical Call Waiting Window
Explains the graphical display that shows a history of recent callers to the keypanel.
Graphical Call Waiting Window Operation
Details how to display, hide, and scroll through the Graphical Call Waiting Window.
Mute the Microphone
Explains how to mute microphones remotely or via the Mic Mute key.
Mic Select
Configures mic inputs and speaker/headset outputs as Always On, Switched, or Disabled.
Setup Pages
Allows access to more key assignments by swapping between setup pages for different users.
Menu Passwords
Explains how to lock the entire menu structure or only the service menu using passwords.
Voice Messaging (Audio Package Only)
Enables voice messaging for users who are away or busy, with AFK and Auto-Record modes.
Voice Messaging Icons
Table listing voice messaging icons and their descriptions for operational states.
Voice Messages Menu
Used to display, retrieve, and listen to voice messages stored on the keypanel.
VM Playback Menu
Guides on playing, rewinding, fast-forwarding, pausing, and listening to voice messages.
User Programmable Buttons
Allows assigning frequently used menu items or relays to UPG buttons for quick access.
Keypanel Color Window
Customizes text and background colors for function types, key assignments, and talk/listen indications.
Function Types Page
Explains changing default colors for various keypanel function types.
Color Grid
Displays function types and their assigned colors, used for key color changes.
Key Assignment Page
Assigns different colors to individual function type resources for key assignments.
Assignment Groups Page
Changes the colors of members within different assignment groups for key customization.
Miscellaneous Colors Page
Used to change colors of talk and listen indicators seen on the keypanel.
Enhanced Tallies
Configures how tallies appear on the keypanel, including color and flashing effects.
Panel Tally
Notifies keypanel users of events not specific to a key, using blinking icons controlled by UPL.
Create and Download New Icons
Guides on creating and downloading custom panel or key overlay icons for the keypanel.
Keypanel Mirroring (Control Package Only)
Allows a licensed keypanel to take control of a target keypanel in real-time.
Real-Time Control in AZedit (Control Package Only)
Enables real-time changes to intercom and keypanel controls via AZedit.
Keypanel Volume Controls
Modifies keypanel volumes (Speaker, Headset, Matrix In, Aux In) remotely via AZedit.
Mic Mute
Remotely enables or disables a selected keypanel microphone from AZedit.
Headset Transfer
Switches between headset and speaker modes on a keypanel remotely via AZedit.
AFK Mode
Enables and disables AFK (Away From Keypanel) mode on a keypanel remotely via AZedit.
Enable Tone
Enables and disables the tone generator on a selected keypanel/port remotely via AZedit.
Keypanel Configuration (Control Package Only)
Allows uploading, modifying, saving, and downloading keypanel configuration files via AZedit.
Panel Options Page
Shows the Panel Options tab within the Keypanel Configuration window.
LCP Encoder Assignments Group Box
Assigns volume control functions to LCP shaft encoders remotely from AZedit.
Panel Swap Group Box
Allows users to quickly change keypanel assignments using virtual expansion panels.
UPG Key Definition Group Box
Assigns different inputs and outputs to UPG keys for custom functions via AZedit.
Quick-Assign Listen Assignments Group Box
Assigns listen assignments to point-to-point, party line, and group keys.
Panel Mode Group Box
Configures the keypanel's operating mode and alpha display, including Intercom Mode.
Miscellaneous Group Box
Configures SEL key functions and Page Change Mode settings for the keypanel.
Snoop Tally Group Box
Configures the type and length of snoop tally, indicating when someone is listening.
GPI Inputs Assignments Group Box
Configures GPI inputs to activate intercom keys or track output states.
GPI Output Assignments Group Box
Assigns Relays 1 and 2 to keys or UPGs for controlling GPIO outputs.
Footswitch Mode Group Box
Enables the footswitch and configures latched talk key behavior upon release.
Display Page
Configures keypanel and expansion panel displays, including backlight and screen saver settings.
Keypad Backlight Group Box
Selects color and brightness for keypad backlight LEDs at various usage states.
Key Display Options Group Box
Configures keypanel keys to show crosspoint gains, listen assignments, or matrix.
Panel Display Options Group Box
Enables menu context, speaker volume display, and KP-32 emulation for the panel display.
LCD Backlight Group Box
Sets the brightness for the panel display of keypanels and expansion panels.
Screen Saver Group Box
Configures screen saver activation delay, display mode, movement, and dimming.
Key Options Page
Main window for configuring keypanel options like auto dial, chimes, and exclusive keys.
Solo And Exclusive Keys Group Box
Configures solo and exclusive keys, allowing only one solo key per keypanel.
Latch Disable Group Box
Enables or disables keypanel keys to stay on when pressed, affecting latching behavior.
Button Lock Group Box
Locks keypanel keys in the on or off position, preventing unintended changes.
Tallies Group Box
Sets the duration for blinking tallies and the option to generate indefinite incoming call tallies.
Autodial Numbers Group Box
Adds up to 100 autodial numbers locally to the keypanel for quick dialing.
One-Touch Autodials Group Box
Assigns autodial numbers to specific keypanel keys for one-touch dialing.
Key Groups Group Box
Creates key groups, allowing activation of multiple keys by activating a single master key.
Chimes Group Box
Configures chime tone and duration for incoming call announcements.
Key Icons Group Box
Enables icon overlays for various key states like Solo Key, Auto-Dial, or Exclusive Key.
Key Volumes Group Box
Enables or disables key volume adjustments and sets minimum volumes for individual keys.
KP-4016/5032 Menu System
Audio Options
Section detailing various audio settings for the keypanel, including mic, speaker, and volume controls.
Audio Options Menu, Advanced
Accesses advanced audio settings like AEC, AGC, Compression, Filters, Gating, Metering, Mixing, Mix Mode.
AGC Group Box
Sets the speed for microphone attack and decay levels in Automatic Gain Control.
Compression
Changes audio gain and compression ratio for microphone inputs to manage dynamic range.
Filters
Enables bandpass filters to set low and high frequency ranges for inputs and outputs.
Equalization
Selects predefined settings to modify audio channel frequency envelope using a 5-band equalizer.
Gating
Minimizes background noise by shutting off audio when levels drop below a threshold.
Metering
Monitors audio source energy split into five bands displayed on the keypanel.
Mixing
Routes selected audio signals to different destinations like Matrix, Speakers, or Headphones.
Mix Mode
Controls whether mixes to speakers/headsets are muted when inactive.
Noise Gate
Enables, disables, or adjusts the audio level threshold for microphone activation.
Audio Options Menu, Chime
Sets volume for built-in chimes and enables/disables chime preview.
Audio Options Menu, Dim
Configures dimming amount for speaker or headset volume when talk keys are pressed.
Audio Options Menu, Ganged Vols
Sets behavior for ganged channel pairs when adjusting volume, affecting linked controls.
Audio Options Menu, Headset Mic
Configures headset audio source and microphone type, including Auto-Mute feature.
Type
Selects microphone type: Auto-Detect, Dynamic, or Electret.
Audio Options Menu, Headset Speaker
Controls headset detection, auto-transfer, and defines Main Volume encoder for speakers.
Mode
Sets the mode for Headset Speaker: Always On, Disabled, or Switched.
Audio Options Menu, Inputs
Enables or disables volume control for audio inputs, making them visible in the Mixing menu.
Audio Options Menu, Key Volumes
Enables or disables key volume adjustments and sets minimum volumes for individual keys.
Audio Options, Menu, LCP 16 CLD
Configures input/output volumes and sidetone level for the LCP 16 CLD.
Audio Options Menu, Matrix Out
Selects matrix output mode (Normal or Hot Mic) and routes audio from active mic to the matrix.
Audio Options Menu, Max Volume
Sets the maximum output level for headset or speaker to prevent overly loud audio.
Audio Options Menu, Mic Gain
Adjusts mic gain level and enables/disables mic gain on the keypanel for specific sources.
Audio Options Menu, Mic Mute
Configures the actions of the Mic Mute key: Disabled, Momentary, or Toggle.
Audio Options Menu, Min Volume
Sets minimum volume level for sources, preventing inaudible or muted levels.
Audio Options Menu, Panel Mic
Configures how the panel microphone operates: Disabled, Enabled, or Switched.
Audio Options Menu, Preamp Out
Chooses how audio is routed to the Preamp Output connector: Disabled, Hot Mic, Invert, or Switched.
Audio Options Menu, Sidetone
Configures the level and mode for hearing one's own voice (sidetone).
Audio Options Menu, Speaker
Configures speaker operation mode and defines Main Volume encoder control for speakers.
Volume Control
Defines volume control as Ganged or Individual for headset speakers.
Audio Options Menu, Tone Gen
Turns the tone generator on or off to check the audio path from keypanel to matrix.
Audio Options Menu, VM Options (Audio Package Only)
Configures voice message playback, recording, and mailbox full actions.
Menu System, Display
Information available for display includes Assign Type, Auto Dial, Chime, Matrix, Panel ID, Version.
Menu System, Key Assign Menu
Assigns intercom key assignments and auto functions to keypanel keys.
Key Assign Menu, Matrix (Trunked System Only)
Assigns intercom keys to destinations within a matrix for trunked systems.
Key Assign Menu, Pt-to-Pt
Assigns a key to talk or listen to another intercom port, enabling full communication.
Key Assign Menu, Party Line
Assigns a key to talk or listen to a party line, defined in AZedit.
Key Assign Menu, IFB
Assigns an IFB assignment type to a key, with default restrictions.
Key Assign Menu, Special List
Assigns a key to talk or listen to a special list, requiring members assigned in AZedit.
Key Assign Menu, Sys Relay
Assigns a relay to a keypanel key for controlling devices like GPI outputs.
Key Assign Menu, Camera ISO
Assigns an ISO (isolate) assignment type to a key for camera control.
Key Assign Menu, UPL Resources
Assigns a UPL resource assignment type to a key, with default restrictions.
Key Assign Menu, IFB Spcl List
Assigns an IFB assignment type to a key, useful for news programs.
Key Assign Menu, Auto Funcs
Assigns auto functions like All Call, Auto Follow, Auto Listen, Auto Mute, Auto Recip, Auto Table, and Dim to keys.
Menu System, Key Options Menu
Configures keypanel options like auto dial functions, chime keys, exclusive keys, and latching.
Key Options Menu, Auto Dial
Stores phone numbers for local auto dialing and configures 1-Touch TIF Auto Dial.
Key Options Menu, Chime
Configures chime tone for incoming calls, including volume and duration.
Key Options Menu, Clear
Clears key options assigned to specific keys or UPG button assignments.
Key Options Menu, Exclusive
Sets up keys that turn off other exclusive keys when activated, with behavior on deactivation.
Key Options Menu, Icons
Enables icon overlays for various key states like Solo Key, Auto-Dial, or Exclusive Key.
Key Options Menu, Key Groups
Creates key groups, allowing activation of multiple keys by activating a single master key.
Key Options Menu, Latching
Enables or disables keypanel keys to stay on when pressed, affecting talk function persistence.
Key Options Menu, Lock (Button Lock)
Locks keypanel keys in the on or off position, preventing unintended changes.
Key Options Menu, Panel Swap
Allows users to quickly change keypanel assignments using virtual expansion panels.
Key Options Menu, Solo
Sets up a key that causes all other keys to turn off when activated, with keys returning on release.
Key Options Menu, Tallies
Configures tally time for incoming calls and the option to generate indefinite call tallies.
Key Options Menu, Turn Off
Allows quickly turning off all keys, talk keys, or listen keys, or creating UPG keys for this function.
Menu System, OMNEO Offers
Configures keypanel communication via OMNEO or AIO, including OMNEO channels for AUX Inputs.
Menu System, RVON Offers (Only available when an RVON-IO is detected)
Configures matrix connection when an RVON-I/O is attached to the AIO port.
Menu System, Save Config
Saves custom settings made in Audio Options, Key Options, or Service menus to non-volatile memory.
Menu System, Service
Provides access to system-level settings like Alphas, CWW, Display, Keypad, and Mirroring.
Service Menu, Aux Select
Selects the number of auxiliary inputs on the keypanel when licensed for OMNEO 3-8.
Service Menu, CWW
Configures the Call Waiting Window, including the number of entries and caller handling.
Service Menu, Display
Enables menu context, shows speaker volume, and emulates a KP-32 display.
Service Menu, Footswitch
Enables the footswitch feature and configures latched talk key behavior upon release.
Service Menu, Intercom Mode
Selects the firmware type for intercom compatibility and alpha display.
Service Menu, Key View
Configures keypanel keys to show crosspoint gains, listen assignments, or matrix names.
Service Menu, Keypad
Configures SEL key default function and keypad backlight behavior.
Service Menu, LCD Backlight
Sets the brightness of the panel display for all keypanels and expansion panels.
Service Menu, Local GPIO
Configures GPIO inputs and outputs to activate intercom keys or control GPIO Outputs.
Service Menu, Mirror (Control Package Only)
Provides a scroll list of keypanels that can be the target of a mirror operation.
Service Menu, OMNEO Setup
Configures OMNEO device name, DHCP, and IP configuration for keypanel network setup.
Service Menu, Page Change
Selects whether setup pages can be changed while talk keys are active.
Service Menu, Reset Cfg
Restores custom settings to defaults and erases stored autodial numbers.
Service Menu, RVON Setup
Configures RVON-I/O IP Address, Netmask Address, and Gateway Address for the keypanel.
Service Menu, Scrn Saver
Configures screen saver operation, including activation, delay, display dim, and mode.
Service Menu, Set Address
Indicates the poll ID of the keypanel for communication attempts with the intercom.
Service Menu, Snoop Tally
Indicates to users when someone is listening, setting chime type and tally duration.
Service Menu, Test Panel
Allows the user to check the operation of all keys and displays on the keypanel.
Telephone Interface (TIF) Operation
Receiving A Phone Call
Explains how to answer an incoming telephone call when the TIF alpha begins to tally.
Dialing and Hanging Up
Covers manual dialing, auto dialing, hanging up, and redialing via the TIF assignment.
Centralized Auto Dials
Allows storing up to 999 phone numbers for scrollable list access from keypanels.
Keypad Quick Reference
Keypad Sequence Introduction
Explains keypad sequences as shortcuts for displaying specific information or performing actions.
Keypad Sequences
Lists keypad strokes and their corresponding functions for operating the keypanel.
Key Assign Menu
Assigns intercom key assignments and auto functions to keypanel keys.
Key Options Menu
Configures keypanel options like auto dial functions, chime keys, exclusive keys, and latching.
Keypanel Menu Quick Reference
Audio Options
Details menu options for AEC, AGC, Compression, Filters, Gating, Metering, Mixing, and Mix Mode.
Display Menu
Information available for display includes Assign Type, Auto Dial, Chime, Matrix, Panel ID, Version.
Key Assign Menu
Assigns intercom key assignments and auto functions to keypanel keys.
Key Options Menu
Configures keypanel options like auto dial functions, chime keys, exclusive keys, and latching.
APPENDIX A
EKP-4016
Provides an introduction to the EKP-4016 Expansion Panel Color Display.
Introduction
Explains how the EKP-4016 provides additional keys per expansion panel to intercom applications.
Specifications
Details LCD display, connector, environmental, and power specifications for the EKP-4016.
EKP-4016 Expansion Panel Reference View
Provides a reference view of the EKP-4016 Expansion Panel, highlighting front and rear components.
Expansion Panel Cabling Reference
Details expansion panel cabling, including RJ-45 EXP IN and OUT assignments.
APPENDIX B
Unicode Support
Details minimum firmware revision requirements for Unicode support in AZedit and keypanels.
AZedit and Unicode Support
Lists minimum firmware revision requirements for Unicode support across various software and hardware.
APPENDIX C
Power Supply Mounting Options
Provides instructions for mounting the power supply bracket to KP-5032/5032PB and EKP-4016 units.
Power Supply Mounting Bracket Instructions
Details instructions for mounting the power supply bracket to the KP-5032/5032PB unit.
Mounting the Power Supply to KP-5032/5032PB Unit
Steps for attaching the power supply mounting bracket to the rear panel of the KP-5032/5032PB unit.
Mounting the Power Supply to EKP-4016/4016PB Unit
Steps for mounting the power supply bracket to the EKP-4016/4016PB unit's rear panel.
Mounting the Power Supply to a Standard Rack
Describes attaching the power supply mounting bracket horizontally or vertically to a standard rack.
APPENDIX D
Audio and Control Packages
Details the features included in the Audio and Control Add-On Packages for KP Series keypanels.
Audio and Control Add-On Package
Expands keypanel and intercom system capabilities with voice messaging and real-time control.
Need help?
Do you have a question about the KP-5032 and is the answer not in the manual?
Questions and answers
