Summarization of Contents
Analog Module User Manual
1. Product Model List and Dimension
Lists available product models, their dimensions, and electrical specifications.
2. Indicator Description
Explains the meaning of PWR and LINK indicators on the module.
3. Power Supply Specification
Details the voltage, frequency, power loss, and protection for DC and AC power supplies.
4. Environmental Specifications for Product
Outlines operating temperature, humidity, vibration, impact, and interference immunity.
5. Analog Input (AI) Specification
Specifies input ranges, resolution, impedance, response time, and precision for analog inputs.
6. Analog Output (AQ) Specification
Details output ranges, resolution, load impedance, response time, and precision for analog outputs.
7. Analog Input (AI) Wiring Diagram
Provides diagrams for connecting voltage and current output transmitters to analog input channels.
8. Analog Output (AQ) Wiring Diagram
Illustrates wiring diagrams for connecting external devices to analog output channels.
9. MPU Terminal Wiring Diagram
Shows terminal pinouts for various Haiwell PLC analog modules (S08AI, S08XA, S04AI, etc.).
10. Module Parameter Table
Lists CR codes, their corresponding Modbus register addresses, and function descriptions for analog modules.
11. Mounting and installation
Guides on how to mount and install PLC modules securely and ensure proper heat dissipation.
Analog Module Application Case
1. Expand module through the host PLC parallel port
Explains how to expand PLC capabilities using analog modules via the host PLC parallel bus.
2. Module used as remote IO
Details using analog modules as remote I/O via RS485 or Ethernet for distributed control.
