- Page 1 TDP-F10 LED PROJECTOR OWNER’S MANUAL In the spaces provided below, record the Model and Serial No. located at the bottom of your projector. Model No. Serial No. Retain this information for future reference.
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS Before using The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 3 9740 Irvine Blvd., Irvine, CA 92618-1697 U.S.A Phone: (949) 583-3000 CAUTION: Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties authorized by Toshiba, could void the user’s authority to USA ONLY operate the equipment. Notice: This Class B digital apparatus complies with Canadian ICES-003.
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER'S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This unit is fully transistorized and does not contain any parts that can be repaired by the user. - Page 5 5. Heat 8. Be sure that you firmly insert the plug into the wall outlet. The product should be situated away from heat sources such as radiators, Incorrect or faulty connections may result heat registers, stoves, other in fire or electric shock. Avoid using an products (including amplifiers) that unsound or loose outlet.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS (Continued) 11.Lightning storms 14.Do not place the product vertically For added protection for this product during a storm, or when it is left Do not use the product in the upright unattended and unused for long position or any other vertical positions to periods of time, unplug it from the wall project the pictures.
- Page 7 17.Accessories e) The product has been dropped or dam- aged in any way (If the cabinet should Do not place this product on an break, please handle with care to avoid unstable cart, stand, tripod, bracket, or injury) . table. The product may fall, causing f) The product exhibits a distinct change in serious injury to a child or adult, and performance, which indicates a need for...
-
Page 8: Replacement Parts
IMPORTANT SAFETY INSTRUCTIONS (Continued) 21.Replacement Parts 23.Do not leave thermal-paper documents or easily deformed When replacement parts are required, be sure the service technician has items on top of the unit or used replacement parts specified by near the air exhaust for long the manufacturer or have the same periods of time. -
Page 9: Important Precautions
IMPORTANT PRECAUTIONS Moisture Condensation Never operate this unit immediately after moving it from a cold location to a warm location. When the unit is exposed to such a change in temperature, moisture may condense on the lens and the crucial internal parts. Do not use the unit for at least 2 hours when there is an extreme or sudden change in temperature to prevent the unit from possible damage. -
Page 10: Exemption Clauses
EXEMPTION CLAUSES • Toshiba Corporation bears no responsibility in the case of damages arising from natural disaster such as earthquakes, lightning, etc., fire not liable to Toshiba Corporation, acts by third parties, other accidents, or use under abnormal conditions including erroneous or improper operation and other problems. -
Page 11: Other Information
OTHER INFORMATION Copyrights Showing or transmitting commercial imaging software or broadcast or cable-broad casting programs with the purpose of other than the personal and private viewing, including modifying images using the freeze function, or displaying with the varying aspect ratio of the images, could violate the direct or indirect copyrights of the imaging software or broadcast program, etc., if done without first consulting with the copyright holder. -
Page 12: Remote Control Battery
REMOTE CONTROL BATTERY Warning • Never throw the battery into a fire. • Using the battery improperly may cause them to explode or leak and may result in serious injury. If battery-leaking fluid contacts skin, wash the fluid off immediately with clean water and consult a doctor. -
Page 13: Ac Adapter
AC ADAPTER Caution • Always use the AC adapter that was provided with your projector to avoid any risk of fire,electrical shock or damage to the unit. • Never use the supplied AC adapter to other products. • AC adapter is designed only for in-door use. •... -
Page 14: Table Of Contents
CONTENTS Before using SAFETY PRECAUTIONS ................2 IMPORTANT SAFETY INSTRUCTIONS ............4 IMPORTANT PRECAUTIONS ..............9 EXEMPTION CLAUSES ................10 OTHER INFORMATION ................11 REMOTE CONTROL BATTERY ..............12 AC ADAPTER ..................... 13 CONTENTS ....................14 Preparations Checking the package contents ..............16 Names of each part on the main unit ............ - Page 15 Specifications ....................46 List of general specifications................46 List of supported signals (RGB signals)............... 47 List of supported signals (Component signals) ............ 48 Pin assignment of COMPUTER IN terminals ............49...
-
Page 16: Preparations
Checking the package contents Preparations Please make sure that the following items are included in the box, along with the main unit.If any item is missing, immediately contact the store where you purchased the product. (1) Remote control with battery (5) RGB cable [Note 2] (2) AC adapter (6) Power cord [Note 1, 2]... -
Page 17: Names Of Each Part On The Main Unit
Names of each part on the main unit (11) (10) (12) (13) Back Front Name :Function (1) Air intake :Draws in air from outside the projector for internal cool down. (2) Antitheft lock slot :Attach a safety cable or any other antitheft device. (3) Focus slide knob :Adjusts the screen focus. -
Page 18: Names Of Each Part On The Control Panel And Remote Control
Names of each part on the control panel and remote control Control panel Remote Control (11) (12) (10) Battery holder Name :Main Function Control panel (1) Selection buttons :Menu selections and adjustments, etc. p.33 (2) ENTER button :Accepts the selected mode. (3) TEMP indicator :Lights when internal temperature is too high. - Page 19 Name :Main Function (5) VIDEO button :Selects video signals from video equipment. (6) SD/USB button :Selects input signal from SD or USB memory device. p.38 (7) FREEZE button :Pauses image. p.31 (8) MUTE button :Cuts off the picture temporarily. p.30 (9) AUTOSET button :Performs auto-adjustment of input signal from com puter.
-
Page 20: Parts On The Rear Panel
Parts on the rear panel Name :Main Function (1) DC IN terminal :Connects the AC adapter here. p.26 (2) VIDEO IN terminal :Inputs video signals from video equipment. (3) COMPUTER IN terminal :Inputs analog RGB signal from a computer or other source, or a component video signal (Y/P ) from video equipment. -
Page 21: Preparing And Using The Remote Control
Preparing and using the remote control For the first time use 3 Push the battery holder back into the remote control until you feel a click. 1 Remove the transparent insulation sheet by pulling it before use. Operating the remote control Replacing battery Turning the power on by sliding the 1 Remove the battery holder. - Page 22 Preparing and using the remote control (Continued) Lithium coin battery • Before using the battery, be sure to observe the Safety Precautions described in previous pages. • Remove the battery from remote control when not using for extended periods. • If the remote control stops working, or if its range decreases, replace the battery with a new one.
-
Page 23: Placement
Placement Placement Styles As shown in the figures below, this device can be placed in 4 different styles. The factory setting is "floor-mounted front projection." Set the [Projection mode] in the Default setting menu , in accordance with your needs. p.36 Floor-mounted front projection Floor-mounted rear projection... -
Page 24: Projection Distance And Size
Projection Distance and Size Use the figures, and tables below to determine the projection size and projection distance. (Projection sizes are approximate values for full-size picture with no keystone adjustment.) projection size projection distance a (inches) As seen from above Screen 90°... -
Page 25: Connection
Connection Before connection • Read the owner's manual of the device you are connecting to the projector. • Some computers cannot be used or connected to this projector. Check for an RGB output terminal, supported signal , etc. p.47 • Turn off the power of both devices before connecting. -
Page 26: Operations
Turning the power on and off Operations Connecting the adapter and power cord Insert one end of the AC adapter into the DC IN socket of the projector. Insert the power cord connector into the other end of the AC adapter. Insert the power cord plug into a wall or other power outlet. - Page 27 Note • The start-up screen will disappear after a moment. You can also configure the system to prevent the start-up screen from appearing. To do this, use the Display setting menu. p.35 • The first time you use the projector after purchase, the language selection menu will be displayed.
-
Page 28: Basic Operations
Basic operations Turn on the power. Turn on the power by following the instructions in "Turning the power on and off”. p.26 Select the language (When using the first time). When the projector is used for the first time after purchase, the start menu for language (to display the menus and messages on the screen) selection is displayed in English. - Page 29 Note • The DLP chip is manufactured using high precision technology. There may be black ® spots (pixels that do not light) or bright spots (pixels that are constantly lit) on the panel. These are intrinsic characteristics of the manufacturing technology and are not malfunctions.
-
Page 30: Using Handy Features
Using handy features Using auto setting (For computer input only) This function automatically sets up the projector to the optimum state. It sets Remote Control up the sampling phase, frequency and screen position, etc., for each type of input signal through a simple operation. •... -
Page 31: Freezing The Image (Freeze)
Using handy features (continued) Freezing the image (FREEZE) Remote Control This function is used to pause video during a presentation. • Press the FREEZE button on the remote control. The picture will pause. To release the freeze function, press the FREEZE button again. -
Page 32: Adjusting Led Power (Led)
You can keep pressing the button until reaching the desired area. When the image returns to the original size by pressing RESIZE button several times, the zoom will be reset. Pressing the button during resizing also resets the zoom. Note •... -
Page 33: Using The Menus
Using the menus You can call up on-screen menus, and make adjustments and settings using the operation buttons on the control panel of the main unit and remote control. p.18 p.19 How to use the menus The menu shown below is for operation instructions purposes and might differ from the actual display. -
Page 34: Image Adjustment Menu
Using the menus (continued) Image adjustment menu Use this menu to set or adjust image related items. Items that can be set or adjusted are marked “Yes”, and those that cannot are marked “No”. (When an item is masked, it indicates that you cannot select for the current input.) Description Video... -
Page 35: Display Setting Menu
Display setting menu Description Video Item Correct the keystone (trapezoid) distortion of the Keystone screen. Screen shrinking Screen shrinking at bottom at top Screen size setting. [Note] Screen size (Normal) (Wide) (Normal): Display the image in a maximum size to fit in the screen (Wide): Wide-screen dispay Adjust the vertical position when Screen size is Up/down shift... -
Page 36: Default Setting Menu
Using the menus (continued) Default setting menu Description Video Item Set the priority to SD or USB input signals. SD/USB Set to "On", then plug in the SD/USB memory Quick start device will enter the Slide show mode. Set to "Off", then plug in the SD/USB memory device will enter the File view mode. -
Page 37: Displaying Information (Status Display)
Displaying Information (Status display) Description Video Item Input source name. Input Resolution (in dots). [Note] Resolution Color method of video signal. Video mode Picture mode setting. Picture mode Color space setting. Color space LED brightness. LED Power Firmware version. [Note] Version Note •... -
Page 38: Sd/Usb Memory Device Operation
SD/USB Memory Device Operation Press SD/USB button of the remote control to select SD/USB source. Plug the SD/USB memory device to the SD/ USB port. Note • USB HDD or hub is not supported. • If SD and USB memory device are inserted before power is on, the input signal is detected according to the SD/USB setting in the Default setting menu... - Page 39 • Thumbnail may not be displayed due to different file formats. • Movie files are not supported. Slide show Mode Slide show Mode • Quick start When the projector is set to the SD/USB input and “Quick start” is set to “On” , the p.36 slide show starts with JPEG files in the root folder of the SD/USB memory device.
- Page 40 This projector does not support all SD and USB memory devices. 5 Backing up the data Toshiba recommends that you back up the data saved in the SD/USB memory device before use. (Toshiba assumes no liability for losses incurred by data lost through the use of this projector.)
- Page 41 6 JPEG files • Supported file extensions are .jpg and .JPG. • Some JPEG files such as interlaced JPEG are not supported. Maximum resolution is 16384 x 16384. 7 Folders and files • Folders are limited to 4 levels. • The number of files in each folder is limited to 9986.
-
Page 42: Maintenance
Lens and main unit cleaning Maintenance WARNING • Request cleaning and maintenance of a ceiling-mounted unit from your projector dealership. Attempting to clean the unit in a high location by yourself may cause you to fall, possibly resulting in injury. Lens cleaning •... -
Page 44: Others
Indicators Others LED Indicators State/ Problems Icon/ Messages Close Messages TEMP STATUS System overheat See [Note] below Fan lock See [Note] below System error See [Note] below SD/USB error Turn off the power once and turn it back again. Some kinds of files may cause this problem, so please try to remove the files. -
Page 45: Before Calling Service Personnel
Before calling service personnel If you think something is wrong, check the followings before contacting customer service. Please see "Indicators" as well. p.44 If This Happens Check No power • Is AC adapter connected to the power cord? Is AC adapter connected to the projector? •... -
Page 46: Specifications
Specifications List of general specifications Item Specification Power consumption Weight 650g External Dimensions 139.5 x 56 x 124.5 mm (W x H x D) (including protruding parts) Cabinet material Temperature Operating temp: C to 35 C (41 F to 95 F) 0 - 1500m (0 - 5000ft) Fan mode: Normal C to 30 C (41... -
Page 47: List Of Supported Signals (Rgb Signals)
List of supported signals (RGB signals) This projector supports the following RGB signals. Note, however, that depending on the computer model, the screen may show flicker or streaking. Please adjust the projector if this happens. Compatibility Resolution H-Sync [KHz] V-Sync [Hz] 640 x 480 31.5 59.9... -
Page 48: List Of Supported Signals (Component Signals)
Specifications (Continued) List of supported signals (Component signals) Signal Horizontal Frequency (kHz) Vertical Frequency (Hz) 480i 15.8 kHz 60 Hz 480p 31.5 kHz 60 Hz 576i 15.6 kHz 50 Hz 576p 31.3 kHz 50 Hz 720p 45.0 kHz 60 Hz 720p 37.5 kHz 50 Hz... -
Page 49: Pin Assignment Of Computer In Terminals
Pin assignment of COMPUTER IN terminals Pin No. Signal Name GREEN BLUE Mini D-sub 15 pin connector VCC 5V HSYNC VSYNC...
