Summarization of Contents
Product overview
Standard features
Lists the common features of the HP RP9 G1 Retail System, including form factor, design, display options, VESA mounting, stand choices, and optional peripherals.
Unfolding the ergonomic stand
Instructions on how to unfold the ergonomic stand for the HP RP9 G1 Retail System, including connecting power.
Rear components
Identifies and describes the various ports and connectors located on the rear panel of the HP RP9 G1 Retail System.
Hardware upgrades
Tools needed
Lists the tools required for performing hardware upgrade procedures on the HP RP9 G1 Retail System, such as screwdrivers.
Warnings and cautions
Provides essential safety warnings and cautions to be followed before performing any hardware upgrades on the HP RP9 G1 Retail System.
Removing and attaching the ergonomic and compact stands
Detailed steps for detaching and reattaching the ergonomic and compact stands of the HP RP9 G1 Retail System.
Routing cables (ergonomic stand)
Instructions on how to route cables for the ergonomic stand of the HP RP9 G1 Retail System, ensuring neatness and proper connection.
Routing cables (compact stand)
Instructions on how to route cables for the compact stand of the HP RP9 G1 Retail System, ensuring neatness and proper connection.
Removing and replacing the power supply (ergonomic stand)
Step-by-step guide to safely remove and replace the power supply unit for the ergonomic stand model of the HP RP9 G1 Retail System.
Installing an optional HP integrated USB barcode scanner, magnetic strip reader (MSR), biometric reader, or webcam
Steps for installing optional peripherals like USB scanners, MSRs, webcams, or biometric readers onto the HP RP9 G1 Retail System.
Installing an optional HP integrated USB barcode scanner on the bottom of the display head
Steps for installing an optional HP integrated USB barcode scanner on the bottom of the HP RP9 G1 Retail System's display head.
Installing a 2 x 20 LCD or 7" LCD customer facing display (CFD)
Guides for installing customer facing displays (CFDs), including top and bottom mount options, on the HP RP9 G1 Retail System.
Installing a top mount CFD
Procedure for installing a customer facing display (CFD) on the top mount of the HP RP9 G1 Retail System.
Installing a bottom mount CFD
Procedure for installing a customer facing display (CFD) on the bottom mount of the HP RP9 G1 Retail System.
Installing memory
Information and steps for installing or upgrading memory modules (SODIMMs) in the HP RP9 G1 Retail System.
Removing and installing a SODIMM
Step-by-step instructions for safely removing and installing a Single Outline Dual In-line Memory Module (SODIMM) in the HP RP9 G1 Retail System.
Removing and installing a 2.5-inch hard drive
Comprehensive guide on how to remove and install a 2.5-inch hard drive in the HP RP9 G1 Retail System.
Removing and installing an M.2 storage device
Instructions for removing and installing M.2 storage devices in the HP RP9 G1 Retail System.
Replacing the battery
Detailed instructions for replacing the 3-volt lithium coin cell battery that powers the real-time clock in the HP RP9 G1 Retail System.
Installing a port cover
Steps to install a rear I/O port cover, available from HP, onto the HP RP9 G1 Retail System.
Securing the RP9 to a counter top
Instructions on how to securely attach the HP RP9 G1 Retail System to a counter top using its stand.
Installing an external security lock
Guidance on how to install an external security lock, such as a cable lock, to secure the HP RP9 G1 Retail System.
Cable lock
Instructions for using a cable lock to secure the HP RP9 G1 Retail System to an external object.
Padlock
Instructions for using a padlock and security loop to secure the HP RP9 G1 Retail System to an external object.
Configuring the software
Touch screen calibration
Recommends and explains how to calibrate the touch screen for accurate input on the HP RP9 G1 Retail System.
Calibration for Windows 7 Professional and Embedded POSReady 7
Detailed steps for calibrating the touch module in Windows 7 Professional and Embedded POSReady 7 on the HP RP9 G1 Retail System.
Calibration for Windows 8.1 Professional and Embedded 8.1 Industry Pro Retail
Detailed steps for calibrating the touch module in Windows 8.1 Professional and Embedded 8.1 Industry Pro Retail on the HP RP9 G1 Retail System.
Calibration for Windows 10 Professional and Windows 10 IoT Enterprise for Retail
Detailed steps for calibrating the touch module in Windows 10 Professional and Windows 10 IoT Enterprise for Retail on the HP RP9 G1 Retail System.
Configuring all optional HP integrated USB peripheral modules (HP integrated USB barcode scanner, magnetic strip reader (MSR), biometric reader, or webcam)
Guidance on configuring optional integrated USB peripherals for the HP RP9 G1 Retail System, referring to a separate guide.
Configuring powered serial ports
Explains how to configure serial ports for powered or non-powered operation using the Computer F10 Setup utility on the HP RP9 G1 Retail System.
Electrostatic discharge
Preventing electrostatic damage
Lists precautions to prevent damage to sensitive electronic components from static electricity when handling the HP RP9 G1 Retail System.
Grounding methods
Describes various methods for grounding oneself to prevent electrostatic discharge when working with the HP RP9 G1 Retail System.
Computer operating guidelines, routine care and shipping preparation
Computer operating guidelines and routine care
Provides essential guidelines for the proper setup, operation, and routine care of the HP RP9 G1 Retail System.
Touch screen maintenance
Instructions on how to properly clean and maintain the touch sensor surface of the HP RP9 G1 Retail System.
Shipping preparation
Suggestions and steps for preparing the HP RP9 G1 Retail System for shipping, including data backup and proper packing.
