Summary of Contents for Xtant 604X
- Page 2 (ikst`ænt, e`kstent) 1. adj. still in existence, especially. of enduring excellence.| |e.g. of xtant quality that stands the test of time and the passing of fads. 2. adj. Standing out or above, as in out- standing, the quality or state of being original.
- Page 3 We Listen to our equipment with sensitive and critical ears to provide the finest mobile audio components on the planet. We have created Xtant because we respect the music, and the people who want to really listen. The result has expanded the expectations of extraordinarily vivid mobile audio.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Safeguards Xtant 604X Specifications Electronic Crossover Optional Accessory Modules Maintenance Customer Relations / Technical Services Warranty Owner’s Installation Log Installer’s Reference Insert... -
Page 5: Safeguards
Reference for recommended wire gauges. Fusing Requirements The 604X is not fuse protected! For safety, an outboard 120 amp fuse may be added close to the amplifier. A 120 amp fuse must be installed in-line with the power wire at the battery. In the case of a multi-amp system, use a fuse value equal to the combined total demand of all amplifiers in the system. -
Page 6: Xtant 604X
Frequency selection is via a 12 pin Frequency Module (SIP). The amplifier is shipped with a 90 Hz SIP installed, 13 other frequencies are available from your Xtant Dealer. Refer to page 7 of this manual for a list of the available frequencies. -
Page 7: Specifications
Xtant 604X SPECIFICATIONS Frequency Response: 5 Hz to 50 kHz +/– 1 dB Number of Channels: Watts per Channel @ 4 : 4 x 75 Watts per Channel @ 2 : 4 x 150 Bridged Mono @ 4 : 2 x 300 Recommended Load: >2 Stereo / >4 Bridged... -
Page 8: Electronic Crossover
ON-BOARD ELECTRONIC CROSSOVER All Xtant “X” series amplifiers have on-board, two-way elec- tronic crossovers. Xtant 3 and 4 channel models feature two inde- pendent two-way crossovers. Each crossover is tied to a set of inputs and con- trols the frequency range of the associated amplifier. Independent frequency selection is provided for both the High and Low Pass sections. -
Page 9: Optional Accessory Modules
OPTIONAL ACCESSORY MODULES Xtant optional accessory modules are easily and quickly installable by your Authorized Xtant Dealer. The upgrade modules snap into place on the amplifiers PC board when the top of the unit is removed. These accessories enhance your entire system, expand- ing and customizing performance for your unique applications. -
Page 10: Maintenance
Recommended Cleaning Procedures Cleaning the fan / Circuit Board – Every 90 Days The internal fan in all Xtant amplifiers need periodic cleaning. If you are in a high dust environment, every 30 days is recommended. We recommend that your dealer remove the cover and clean the fan blades with a soft brush. -
Page 11: Customer Relations Technical Services
This commitment is not taken lightly or just for today; it is our way of doing business. We believe there is no other way. Xtant’s policies and procedures are designed, in the event of a problem, to minimize the amount of your “down-time” and inconvenience. It is our commitment that the product will be at our facility for no more than four (4) days. -
Page 12: Warranty
5. The provisions of this warranty shall not apply to any Xtant unit used for a purpose for which it is not designed, which has been repaired or altered in any way, or which has been connected, installed, or adjusted other than in accordance with the instructions furnished in Xtant’s owner’s... -
Page 13: Owner's Installation Log
OWNER’S INSTALLATION LOG Upon installation of your mobile audio sound system, your Authorized Xtant Select Dealer will complete this log. Keep this owner’s manual with your vehicle as a reference for all amplifier set- tings. owner’s name: Vehicle: year: xtant amplifier serial no.
