Denon AVR-3311CI Brochure & Specs page 2

State-of-the-art Denon Solutions for
Maximizing Content Quality
• Fully discrete, identical quality and power for all
7 channels (125 W x 7ch)
To faithfully reproduce the original surround sound, each of
the AVR-3311CI's 7 channels is equipped with the same
power amp of equal power. Since these power amps also use
discrete circuits configured with parts strictly selected for their
contribution to high sound quality, rather than with low-cost
integrated circuits (ICs), the surround sound playback is of
impeccably high quality.
• Featuring 3D pass-through technology
By connecting a 3D-compliant Blue-ray disc player and 3D-
compliant TV to the AVR-3311CI, you will have a 3D home
theater where you can enjoy high-definition sound and video
on a level you've never experienced before.
• S u p p o r t s H D M I 1 . 4 a w i t h 3 D, Au d i o R e t u r n
Channel, Deep Color, "x.v.Color " , Auto Lipsync
and HDMI control function
When you connect the AVR-3311CI to a T V with a single
HDMI cable, it supports Audio Return Channel (ARC)(*1) that
can play back the TV audio in surround sound. Until now, if
you wanted to enjoy surround sound from a TV, you needed
to use an optical digital cable or coaxial digital cable to bring
sound from the TV to the A/V receiver. The AVR-3311CI's ARC
feature, however, helps you keep cable connections neat and
out of the way as you build your home theater.
*1: The TV must also support ARC.
•Dynamic Discrete Surround Circuit, D.D.S.C.-HD
- 32-bit floating point high precision DSP processor
- AL24 Processing Plus provides improved fidelity and clarity
- High-precision 24 bit/192 kHz D/A converters
• Clock jitter reduction on all digital inputs
• High-definition audio support, with Dolby TrueHD
and DTS-HD Master Audio, high resolution audio for-
mats found on many Blu-ray titles
Main Specifications
Power amplifier section
Rated output *THD figures are power amp stage values.
Front L/R 125 W + 125 W
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %)
165 W + 165 W
(6 ohms, 1 kHz, THD 0.7%)
Center 125 W
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %)
165 W
(6 ohms, 1 kHz, THD 0.7%)
Surround L/R 125 W + 125 W
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %)
165 W + 165 W
(6 ohms, 1 kHz, THD 0.7%)
Surround Back L/R 125 W + 125 W
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %)
165 W + 165 W
(6 ohms, 1 kHz, THD 0.7%)
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: 201-762-6500 usa.denon.com
• Audyssey DSX processing
Audyssey DSX extends 5.1-channel and 7.1-channel sound
sources to a wider and higher dimension. Featuring the latest
precision DSP processing algorithms, Audyssey DSX creates ad-
ditional front height or front width channels, for a dramatically
expanded front soundstage.
• High-bit I/P Converter and Scaler up to 1080p
- Multi cadence detection for SD and HD video signals
The AVR-3311CI uses a high-performance video scaler to convert
SD (standard definition) video to HD (high definition) quality.
• Minimum Signal Path for clear audio and video signal
The "simple and straight" design concept has been thoroughly
implemented in the signal paths to contribute to immaculately
clean audio and video playback. Signal paths are as short as
possible to keep signal degradation in the audio and video
circuitry to an absolute minimum
• Direct Mechanical Ground Construction, embody-
ing concepts for thorough vibration resistance
Vibration-resistant construction includes design features
such as securely mounting the power transformers, a source of
vibration. to the highly rigid bottom chassis. Direct mounting of
cast-iron feet to the radiator in near proximity to each other serves
to additonally suppress mutual vibration with the power trans-
formers and other sources of vibration. By controlling all aspecs
of component vibrations, the rigid chassis provides for greater
audio fidelity and freedom from vibration-induced extraneous
noise, on par of that normally associated with much more costly
separate components.
Connectivity & Future-ready Expandability
• 6 x HDMI in / 2 x HDMI out (Repeater)
• Selectable Dual HDMI outputs allowing for easy
switching between video projectors or flat panel HDTVs.
• Direct play for iPod and iPhone via USB
You can also listen to music files from your iPod by simply con-
necting it to the AVR-3311CI's front panel USB port with the USB
cable that came with the iPod. To start play, just press the iPod
Preamplifier section
Input sensitivity/impedance 200 mV / 47 kΩ/kohms
Frequency response 10 Hz ~ 100 kHz — +1, –3 dB (DIRECT mode)
S/N Ratio 100 dB (IHF-A weighted, DIRECT mode)
FM section
Tuning frequency range 87.5 - 107.9 MHz
Usable sensitivity 1.0 µV (11.2 dBf)
AM section
Tuning frequency range 520 - 1710 kHz
Usable sensitivity 18 µV
General
Power supply AC 120 V, 60 Hz
Power consumption 670 W (Standby 0.1 W)
Dimensions (W x H x D) 17-3/32" x 6-47/64" x 15"
434 x 171 x 381 mm
Weight 26 lbs 14.3 oz, 12.2 kg
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: 905-475-4085 ca.denon.com
Play button on the AVR-3311CI or its remote control unit. Digital
signals from the iPod are transmitted as is to the AVR-3311CI
where they pass through Denon's exclusive Compressed Audio
Restorer and are processed by advanced audio circuitry to pro-
duce a clean, high-quality sound with improved treble detail.
• HD Radio provides dramatically improved fidelity
• Sirius satellite radio ready
• Power Amp Assign function, that allows multiple
amp and speaker configurations
Ease-of-use
• On-Board GUI via HDMI output (up to 1080p)
The AVR-3311CI is equipped with an easy-to-view Graphical
User Interface (GUI) featuring visual menu displays. These menu
displays can also be output to the HDTV over HDMI cable.
• Newly developed pre-memory remote control hand-
set with Glo-Key buttons, and a 2nd zone remote
• Remote Setup Guidance via On-Screen Display
• Three Quick Select buttons
• Auto surround mode
• Sleep timer function
• Audio Delay function (max. 6 frames or 200 mSec)
• Muting level settings (Full/-40dB/-20dB)
• Audio level memory, capable of correcting for
different signal levels for each input device
• Variable subwoofer crossover switching
Custom Integration
• Control4, AMX, Crestron third party control support
• 150 mA Trigger output
• web control
• Multi-Zone Management
• Remote Access & Maintenance
• IP Control
• Audyssey installer Program Ready
• IR Remote in/out ports
Ports
In HDMI
Component
S-Video
Composite (Video)
Analog Audio (Tuner included)
Digital Optical
Digital Coaxial
Out HDMI Monitor
Component Monitor
Composite Monitor
Composite (DVR/ Zone2)
Audio Preout (FL/ FR/ C/ SL/ SR/ SBL/ SBR)
Audio Preout (SW)
Audio Preout (Zone2 L/R, Zone3 L/R)
Audio REC out
Phones
Digital Optical
Other USB port
Ethernet
Microphone Port
Dock Control Port
FM Tuner Antenna
AM Tuner Antenna
Sirius connector
Remote Control In/Out
RS-232C
DC12V 150mA MAX. trigger out
*Design and specifications are subject to change without notice.
*"Dolby", "Pro Logic" and the double-D symbol are trademarks of Dolby Laboratories.
*DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD
Master Audio are trademarks of DTS, Inc.
*HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
*Audyssey MultEQ ® is a registered trademark of Audyssey Laboratories.
Audyssey Dynamic EQ ® is a trademark of Audyssey Laboratories.
Audyssey Dynamic Volume™ is a trademark of Audyssey Laboratories.
*"Made for iPod" means that an electronic accessory has been designed to connect specifically to
iPod and has been certified by the developer to meet Apple performance standards.
*"Works with iPhone" means that an electronic accessory has been designed to connect specifically
to iPhone and has been certified by the developer to meet Apple performance standards.
*Apple is not responsible for the operation of this device or its compliance with
safety and regulatory standards.
*iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
*iPhone is a trademark of Apple Inc.
*Microsoft, MSN, and Windows Vista are trademarks of the Microsoft group of companies.
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
x 6
x 2
x 2
x 5
x 9
x 2
x 2
x 2
x 1
x 1
x 2
7ch
x 2
x 2
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
In 1 / Out 1
x 1
x 2
17820410 A
