Pursuing the Ideal Compact Inverter
Pursuing the Ideal Compact Inverter
Series
Designed for excellent performance and user friendliness
Stöwer Antriebstechnik GmbH, Enneststrasse 3, 51702 Bergneustadt, tel: 02261-40970, Fax: 02261-41309
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Need help?
Do you have a question about the WJ200-004LF and is the answer not in the manual?
Ask a question
Questions and answers
Related Manuals for Hitachi WJ200-004LF
Inverter Hitachi WJ200 Series Instruction Manual
Wj200 series single-phase input 200v class three-phase input 200v class three-phase input 400v class (421 pages)
Inverter Hitachi WJ200 Series Quick Reference Manual
Wj200 series inverter single-phase input 200v class three-phase input 200v class three-phase input 400v class (94 pages)
Inverter Hitachi WJ200 Series Quick Reference Manual
Wj200 series inverter single-phase input 200v class three-phase input 200v class three-phase input 400v class (95 pages)
Inverter Hitachi WJ200-001S Quick Reference Manual
Wj200 series (104 pages)
Inverter Hitachi WJ200 Series Quick Reference Manual
(108 pages)
Inverter Hitachi WJ200-004M Quick Reference Manual
Wj200 series (77 pages)
Inverter Hitachi WJ200-007MF Manual
Pursuing the ideal compact inverter (28 pages)
Inverter Hitachi WJ200-007M Quick Reference Manual
Wj200 series (77 pages)
Inverter Hitachi WJ200-001SF Manual
Wj200 series (27 pages)
Inverter Hitachi WJ200-002SF Manual
Wj200 series (27 pages)
Inverter Hitachi WJ200-007HF Manual
Wj200 series (27 pages)
Inverter Hitachi WJ200-015HF Manual
Wj200 series (27 pages)
Inverter Hitachi WJ200-022HF Manual
Wj200 series (27 pages)
Inverter Hitachi WJ200-004MF Manual
(32 pages)
Inverter Hitachi WJ200-022SF Manual
Pursuing the ideal compact inverter (28 pages)
Inverter Hitachi wj200 series Quick Reference Manual
(114 pages)
Summarization of Contents
Global Standards
Compliance and Logic Configuration
Covers global standards conformity, sink/source logic, and wide voltage input range.
Ease of Use, Maintenance, and Environmental Friendliness
User-Friendly Features
Includes programming, safe stop, password, network, wiring, and maintenance ease for efficient operation.
Environmental and Operational Aspects
Covers RoHS, dual rating, monitoring, communication, display, BRD, and surge suppression for eco-friendly operation.
Operation and Programming
Operator Panel Overview
Details the functions of LEDs, buttons, and the display on the operator panel for intuitive control.
Navigation and Editing Modes
Explains keypad navigation, function maps, and single-digit edit mode for efficient parameter adjustment.
Terminal Configuration and Functions
Terminal Descriptions and Layouts
Details terminal symbols, arrangements, screw diameters, and control circuit wiring for proper connection.
Logic Input/Output Configuration
Explains sink/source logic for intelligent terminals and provides wiring samples for clear setup.
Hardware Switches and Terminal Functions
Switch Settings for Functionality
Configuration of termination resistor, safe stop, and EDM function switches for operational control.
Terminal Functionality Details
Details analog, digital input/output, and serial communication terminal functions for system integration.
Function List - Key Operational Areas
Monitor Mode Parameters
Lists parameters for monitoring inverter status like frequency, current, torque, and runtime.
Setting Mode - Basic and Analog Configuration
Covers fundamental settings like frequency, acceleration, deceleration, and analog input configuration.
Function List - Control and Protection Settings
Frequency, DC Braking, and V/f Control Parameters
Parameters for frequency limits, DC braking, and V/f characteristic settings for motor control.
PID Control and Acceleration/Deceleration Settings
Settings for PID control, jump frequencies, and acceleration/deceleration time for precise operation.
Function List - Operation Modes and Power Failure Handling
Operation Modes and Frequency Settings
Covers multi-speed operation, ADD frequency, and acceleration/deceleration curve selections.
Power Failure Restart Functions
Details settings for automatic restart after instantaneous power failure and retry functions.
Function List - Advanced Control and Safety
Electronic Thermal and Overload Management
Parameters for electronic thermal protection, overload restriction, and lock functions.
Torque Limit and Power Failure Operation
Configuration for torque limiting, nonstop operation during power failures, and window comparators.
Function List - Extended Features and Settings
Operation Control and Free-Setting V/f Patterns
Covers nonstop operation, window comparators, and free-setting V/f patterns.
Other Settings and Maintenance Parameters
Includes various settings like ambient temperature, watt-hour reset, and start frequency adjustment.
Function List - Terminal and Monitoring Configuration
Intelligent Terminal Input/Output Assignment
Assigns functions to intelligent input and output terminals for custom control.
Analog Monitoring and Output Signal Selection
Configures analog monitoring signals and output selections for terminals for data visualization.
Function List - Communication and Adjustment
Terminal Status and Communication Settings
Covers terminal status, communication speed, parity, error handling, and adjustment parameters.
General Settings and Reset Functions
Includes various settings like reset selection, restart modes, and gain adjustments for system setup.
Function List - Motor and Control Parameters
Terminal Logic and Motor Constant Settings
Configures logical output signals, motor constants, and gain settings for optimal performance.
Feedback Control and Operation Settings
Details feedback control parameters and settings for operation modes like over-speed detection.
Function List - Specialized Control and Options
Torque Control and Option Settings
Parameters for torque control, inverter action on network errors, and option settings.
Pulse Train and Positional Control
Settings for pulse train input, simple positional control, and zero-return functions.
Communication Options and User Parameters
Configuration for Profibus, CANopen, and user-defined parameter assignments.
Protective Functions
Over-current, Overload, and Voltage Faults
Details protection against over-current, overload, under-voltage, and over-voltage conditions.
System, Communication, and Motor Faults
Covers errors related to EEPROM, CPU, communication, external trips, motor faults, and braking.
Connecting Diagram
Source Type Logic Wiring
Illustrates wiring diagrams for source type logic connections for system integration.
Connecting Diagram (Continued)
Sink Type Logic Wiring
Illustrates wiring diagrams for sink type logic connections for system integration.
Connecting to PLC
Input and Output Terminal Connections
Shows wiring for PLC input/output terminals and addresses issues with multiple inverters.
Wiring and Accessories
Power Supply, Wiring, and Fuse Selection
Details power supply ratings, model-specific wiring, fuses, and accessory functions.
Peripheral Equipment Functions Explained
Explains the purpose of AC reactors, EMC filters, noise filters, and braking components.
For Correct Operation
Usage Precautions and Motor Application Guidance
Provides general precautions, guidance on motor application, drive notes, and installation environment.
Power Supply and Peripheral Equipment Considerations
Input Power and Peripheral Equipment Selection
Discusses AC reactor installation, private power generators, and peripheral equipment selection.
Component Lifespan and Noise Management
Covers primary part lifespan, high-frequency noise, and leakage current considerations.
