Summarization of Contents
General Safety Instructions and Warnings
Important Note on Manual Usage
Manual is integral part, must accompany product for correct installation and use.
Critical Warnings
Prevent fire/shock, use professional riggers, read manual before rigging.
Key Safety Precautions
Read all precautions, power supply safety, prevent short circuit, no unauthorized repairs.
General Operating Precautions
Hearing Loss Prevention
Exposure to high sound levels can cause permanent hearing loss; use protection.
Power Requirements and Setup
Current Requirements
Long term and peak current requirement for HDL 6-A/HDL12-AS modules.
Grounding Guidelines
Ensure proper grounding for reduced hums in the audio system.
AC Cables and Daisy Chains
Risk of Fire Warning
Exceeding module limit in daisy chain can exceed connector ratings, creating a dangerous situation.
Rigging the System
General Rigging Warnings and Precautions
Suspend loads with caution, wear protective gear, never allow people under the system during installation.
Rigging Compliance and Parts Check
Rigging must comply with laws; check non-RCF parts are appropriate, certified, and rated.
RCF Shape Designer Software and Safety Factor
Safety Factor Classification System
Results classified in four classes (GREEN, YELLOW, ORANGE, RED) based on safety factor.
Required Software: MATLAB Runtime
MATLAB Runtime Installation
Process for selecting the installation folder for MATLAB Runtime.
Installation Confirmation
Installation Complete
Confirmation that software and runtime installation was successful.
Designing the System with Software
Autosplay Functionality
Software performs calculations for hanging points, tilt, splays, and loads.
Rigging Components List
Suspension Bar and Pins
Components: BARRA SOSPENSIONE and QUICK LOCK PIN.
Fly Bar and Clamping Brackets
Components: FLY BAR PICK UP and CONNECTION BRACKET.
Pole Mount Bracket
Component: POLE MOUNT BRACKET.
Additional Rigging Components
Hoist Spacing Chain
HOIST SPACING CHAIN for vertical balance when suspended from a single point.
Azimut Plate and Kart
Components: AC 2X AZIMUT PLATE and KART WITH WHEELS.
Truss Clamp and Linkbar
Components: AC TRUSS CLAMP and LINKBAR HDL12 TO HDL6.
Rain Cover
Component: RAIN COVER 06-01.
Rigging Procedure Overview
Rigging Safety Warnings
Steel wires not for load; weight carried by links/strands; lock pins must be secure.
Flybar Setup
Setting Central Bar to 'B' Position
Steps to re-position the central bar to configuration 'B' for better inclination.
System Suspension Procedure
Single Pick Up Point
Positioning the flybar pick-up point for single suspension.
Dual Pick Up Point
Lifting the cluster with two pulleys using an optional pick up point.
Stacking Procedure
Stacking on Sub HDL12-AS
Procedure for stacking HDL6-A on HDL12-AS subwoofer.
Stacking on Other Subwoofers
System Solidity Warning
Always verify system solidity in every configuration.
Ground Stacking
Pole Mounting with Suspension Bar
How to pole mount speakers using a suspension bar.
Payload and Solidity Warning
Always verify system solidity and pole payload.
Transportation: Positioning Speakers on Kart
Kart Capacity Warning
The kart has been designed to carry up to 6 speakers.
