CD RECEIVER
KDC-5018/516S/57MR
SERVICE MANUAL
KDC-5018
ESCUTCHEON ASSY
FRONT GLASS
(B07-3007-03)
(B10-3271-01)
KDC-5018
47W 4
X
KDC-57MR
ESCUTCHEON ASSY
FRONT GLASS
(B07-3017-03)
(B10-3268-01)
KDC-57MR
47W 4
X
PLASTIC
MOUNTING
CABINET ASSY
(A02-1497-03)
(J21-9641-13)
DC CORD
(E30-4940-05)
: KDC-516S/57MR
The MECHANISM OPERATION DESCRIPTION is the same as model KDC-S3007 and KDC-5050RG.
Please refer to the service manual for model KDC-S3007(B51-7029-00) or KDC-5050RG(B51-7099-00).
PANEL ASSY
(A64-2169-02)
DAB
PANEL ASSY
(A64-2166-02)
DAB
REMOTE
HARDWARE
CONTROLLER
ASSY
ASSY
(A70-0883-05)
: KDC-5018
DC CORD
(E30-4939-05)
: KDC-5018
© 2001-3 PRINTED IN JAPAN
B51-7753-00 (N) 1736
KDC-516S
ESCUTCHEON ASSY
FRONT GLASS
(B07-3007-03)
(B10-3267-01)
KDC-516S
47W 4
X
ESCUTCHEON
STAY
(B07-3010-02)
(J54-0606-04)
SCREW SET
BATTERY
(N99-1704-05)
(SIZE: AAA)
Not supplied as
service parts
PANEL ASSY
(A64-2165-02)
DAB
LEVERx2
(D10-4562-04)
SCREW SET
(N99-1700-05)
