Jensen JDV8035 Quick Reference Manual

PANEL RELEASE:
Press to remove
control panel.
MODE: With each
press of the button the
radio will change through
the following modes:
TUNER, DVD, CARD
(SD/MMC CARD,AV IN-1).
ENCODER KNOB: Use
to adjust desired menu item.
Power On/Off:
Press and hold to turn
power ON or OFF.
MUTE:
MUTE audio.
TUNE: Press > to tune
UP in frequency. Press
< to tune DOWN in
frequency. Press and
hold to fast search.
STATION STORE
BUTTONS: Press & hold
to store current channel
playing. Momentarily
press to recall stored
channel. NOTE: you can
store up to 30 channels
(6 channels per band FM1,
FM2, FM3, AM1, AM2).
AS/PS:
stored presets. Press & hold to STORE
strongest broadcast stations in your area.
2-ZONE: Press to turn
2-ZONE ON or OFF.
SUB-W: Press to turn
SUB-W ON or OFF.
AUDIO MENU: Press to
access AUDIO MENU.
Continue to press until
desired menu item
appears. Adjust desired
menu item with
ENCODER KNOB.
PAUSE: Press to
PAUSE current audio.
STOP: Press to
STOP current audio.
TUNE/TRK: Press to
tune to next track.
Press and hold to FAST
FORWARD or REWIND
current track playing.
0
35 Quick Reference Guide
JDV8 JDV8
Press to MENU: Press and hold to access MENU FUNCTION LIST. With each con-
tinuous press of the button choose from the following menu items: ANGLE,
CONTRAST, BRIGHTNESS, COLOR, DATE SET, CLOCK, TIME FORM, AV
JACK, TUNER SET, TUNER AREA, BEEP TONE, PROGRAMMABLE TURN-
ON VOLUME, REAR SPEAKER ON/OFF, INTER AMPLIFIER ON/OFF.
Use ENCODER KNOB to adjust desired menu item.
Press to SCAN through currently
iX BASS: Press to turn
iX BASS ON or OFF.
REPEAT: Press to REPEAT current playing
track. Press to release function.
BAND: Press to select
FM BAND and AM BAND.
OPEN/EJECT: Press to
OPEN faceplate and
insert CD. Faceplate will
automatically close after
CD is inserted. Press again
to EJECT CD. Faceplate will
automatically open when
CD is ejecting and close
when CD is taken out.
*Supports MP3 and WMA File Formats.
