Jensen JRV9000 Operation Manual

6.2” double din multimedia receiver dvd / nav / siriusxm ready / built-in bt technology / iphone - ipod / mhl / hdmi / usb / av in

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

JRV9000

6.2" Double DIN Multimedia Receiver

DVD / NAV / SiriusXM Ready™ / Built-In BT

Technology / iPhone® - iPod® / MHL / HDMI / USB / AV In

Operation Manual

6VRMS

RCA Output

Table of Contents

Need help?

Do you have a question about the JRV9000 and is the answer not in the manual?

Questions and answers

john shaw

January 20, 2025

How do I interface my Android phone to JRV9000. The app in the manual doesnt seem to exist

1 comments:

Mr. Anderson

February 4, 2025

To connect your Android phone to the Jensen JRV9000:

1. Install the App: Download and install the Jensen HDMI/MHL Connect app from Google Play onto your smartphone.

2. Pair via Bluetooth: Pair your smartphone to the head unit using Bluetooth (BT) for full touch screen control. Refer to your smartphone and head unit documentation for pairing instructions.

3. Connect via HDMI/MHL:
- Most Android phones require an HDMI/MHL adapter and an HDMI cable with 2 Type A male connectors. These adapters can be purchased at smartphone retail stores.
- Connect your smartphone to the HDMI/MHL adapter.
- Plug one end of the HDMI cable into the adapter and the other end into the HDMI input on the Jensen head unit (located on the rear chassis panel).
- Check your smartphone's documentation for accessing HDMI/MHL functionality.

4. Launch and Calibrate:
- Open the Jensen HDMI/MHL Connect app on your smartphone.
- Use the head unit's touch screen to start the touch screen calibration process.

This answer is automatically generated

Bill

June 6, 2025

Sirius radio has no id

Summary of Contents for Jensen JRV9000

Page 1 JRV9000 6.2” Double DIN Multimedia Receiver DVD / NAV / SiriusXM Ready™ / Built-In BT Technology / iPhone® - iPod® / MHL / HDMI / USB / AV In Operation Manual 6VRMS RCA Output...
Page 2 JRV9000 Android is a trademark of Google Inc. Sirius, XM and all related marks and logos are registered trademarks of Sirius XM Radio Inc. All rights reserved. microSD is a trademark or registered trademark of SD-3C, LLC in the United States,...
Page 3: Table Of Contents
JRV9000 CONTENTS Features ...�� 5 Controls and Indicators ..�� 8 Remote Control ..��10 External Devices ..�.��13 Quick Start ....�.��14 Audio Equalizer .....�.��17 System Settings ..�.��19 Disc Operation �.��..��28 AM-FM Radio ......�.��.��40 USB / MicroSD card....�.��..��45 iPod®/ iPhone® Connectivity�.��.��50 AV-In1 / AV-In2 .....�.��53 HDMI / MHL Connectivity ..�.��54...
Page 4: Fcc Statement
JRV9000 FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 5: Features
If you take a few minutes to look through it, you’ll learn how to use all the features of your new Jensen JRV9000 Multimedia Receiver for maximum enjoyment. Please save this manual for future reference.
Page 6 TFT screen. *Some apps may not be supported. • USB Charging Current - 2.1 Amp Support Camera • The JRV9000 can connect with 3 cameras: CAM1, CAM2, CAM3. Each camera can be triggered separately and can be set in different trigger priority. Built-In Navigation •...
Page 7 JRV9000 WARNING! Never install this unit where operation and viewing could interfere with safe driving conditions. WARNING! To reduce the risk of a traffic accident (except when using for rear view video camera) never use the video display function while driving the vehicle.
Page 8: Controls And Indicators
CONTROLS AND INDICATORS MENU MUTE AV AUX OPEN JRV9000 Controls and Indicators 1. Disc Slot: Accepts DVD/CD/MP3 discs. If the unit is turned on, playback begins when a disc is inserted. 2. LCD Screen and Touch Screen: Touch icons on this screen to access menus or control functions.
Page 9 JRV9000 6. USB Slot: Used to connect an iPhone/iPod®, MP3 player or USB flash drive for playback of music/video files. 7. Interface Cover: Covers the 3.5mm AV In, MicroSD card and USB slot. 8. Reset Button: Press this button to reset the system settings (except password and parental lock settings) and to correct a system halt or other illegal operation.
Page 10: Remote Control
JRV9000 NOTES ON REMOTE CONTROL USAGE • Aim the remote control at the TFT/screen. • Remove the battery from the remote control or insert a battery insulator if the remote control will not be used for a month or longer.
Page 11 JRV9000 Remote Control Function Description 1. SOURCE (SRC) Button: Press this button to switch between and select available sources. (Radio/Disc/Phone/USB/Phone-Audio/SWC/AUX-1/AUX-2/ Camera) 2. EJECT Button ( ): Press this button to eject a DVD/CD/MP3 disc. Disc play is stopped, the disc is ejected and the unit will change to radio operation. If the disc is not removed from the unit and the button is pressed again, the disc will be re-loaded.
Page 12 JRV9000 12. NEXT (l) Button: Press this button to skip to the next chapter, track or song during playback of a disc. Press this button while in Radio mode to search available radio station by increasing tuning frequency. 13. PLAY / PAUSE ( ) Button: Press this button to pause the playback of a disc.
Page 13: External Devices
JRV9000 EXTERNAL DEVICES Connecting External Devices External devices, including a game console, video camera, etc. can be connected to this unit using its front A/V In 3.5mm connector (AV In1), the rear RCA inputs (AV In 2) or the USB port.
Page 14: Quick Start
MENU Button AV AUX JRV9000 Front Panel 2. Touch the desired source icon on one of the two main menu screens. Screen 1 of 2: Disc, Radio, USB, AV-IN1, SXM, BT, Navigation, or HDMI / MHL. Touch Next at the bottom of the screen to access Screen 2 of 2: Steering Wheel...
Page 15: Audible Beep Confirmation
JRV9000 System Settings Adjustment To access and adjust system settings: Touch the Settings ( ) icon on the Main Menu screen to enter the SETTINGS MENU. Sub-menus where adjustments can be made will be highlighted. Volume Adjustment / Turn On Volume To increase or decrease the volume level, rotate the rotary encoder knob.
Page 16: Playing A Disc
JRV9000 Playing a Disc To begin playback of an Audio/Video Disc: Press the front panel Power On/Off ( ) button / Rotary Volume ( ) knob / Mute button to turn the unit ON. 2. Insert a disc with the label side facing up. Playback will begin automatically.
Page 17: Audio Equalizer
JRV9000 EQUALIZER CONTROL MENU Adjusting Equalizer Controls The Equalizer adjustment screen allows the user to easily adjust the audio system to meet the acoustical characteristics of the vehicle. The acoustical characteristics vary depending on the type of vehicle and measurements.
Page 18 JRV9000 Reset Touch the Reset icon to reset the 10 equalizer band frequencies to the mid point. Loudness Touch the Loud icon to turn the loud option ON or OFF. The loud option automatically alters the frequency response curve of audio to make it sound more natural when played at a lower volume level.
Page 19: System Settings
System Settings Sub-Menus (General, Audio, Time, Language, BT, DVD or Volume) that are used to adjust the performance of each option of the JRV9000. The Version Sub-Menu is for information only. Touch a desired Sub-Menu and the Sub-Menu will appear highlighted. The features available for adjustment will appear on the screen.
Page 20 JRV9000 Beep - Touch ON or OFF to turn the selection confirmation beep ON or OFF. Calibration- The Touch Screen Calibration adjustment is used to set the parameters of the touch screen to ensure that when the screen is touched, it corresponds to the feature desired.
Page 21 JRV9000 Illumination - Customize the front panel illumination. Touch to change the illumination color. Select a color or touch Custom > Adjust to select the color palette. Custom Color - Select Custom1, Custom2, or Custom3 and then adjust to adjust your custom color. Select desired color on color gradient or by pressing - and + for RGB values.
Page 22 JRV9000 Time Sub-Menu Features The clock appears in the top right corner of the screen during certain operations. Note: The AM/PM indication will change as you continue to adjust the hour past 12. Time Sub-Menu Screen Date - Touch the Date icon and use the  or  icons to set the day, month, and year.
Page 23 JRV9000 Language Sub-Menu Features If a DVD supports more than one Subtitle or Audio language, all the languages are available for selection during playback. If the selected language is not supported by the DVD, then the default language is used.
Page 24 JRV9000 BT Sub-Menu Features The BT audio capabilities can be used for hands free applications. Before attempting to use the BT functions on this unit, please make sure the mobile phone to be connected supports BT functions. BT Pairing Code Screen 2 BT - Touch ON or OFF to turn the BT function ON or OFF.
Page 25 JRV9000 DVD Sub-Menu Features The DVD system has a built-in parental lock feature to prevent unauthorized persons from viewing restricted disc content. By default, the rating system is unlocked. Once set up, the parental lock is released only by entering the correct password.
Page 26 JRV9000 Load Factory - This feature allows the user to “Reset” the factory default settings (Rating system only). To reset the password, access the “RATING” menu and enter the current password. Once the correct password is entered, you can access the “Password” eld and enter a new one.
Page 27: Exiting The System Setup Menu
JRV9000 AV In 1 - Touch the AV In 1 icon to enter the setting of the connected device then use the  or  icons to increase or decrease the relative volume level between -6 to +6. AV In 2 - Touch the AV In 2 icon to enter the setting of the connected device then use the ...
Page 28: Disc Operation
JRV9000 DISC OPERATION Compatible Audio Discs Types This system will play the following types of discs: • DVD - DVDs that contain audio and/or video. • Audio discs - Audio CDs that contain audio files. • MP3 discs - A disc that contains audio, video and image files (for example, a CD-R with downloaded MP3 files).
Page 29 JRV9000 Title/Chapter Information - The title/chapter information displayed is the current number of the track playing, the total number of tracks on the disc, the current chapter playing and the total number of chapters on the disc. Time Display - This indicator displays the time as entered by the user in the Settings Menu.
Page 30 JRV9000 ) Repeat - Touch this icon during playback to repeat the current chapter. The icon on the screen will light and small letter C will appear below the icon and the chapter will repeat. Touch this icon a second time to repeat the current title.
Page 31 JRV9000 Direct Entry When the Direct Entry icon is touched the Direct Entry Screen appears. The user can manually select a title or a chapter. By touching  icon, the user can select a chapter or title. The title or chapter can be selected by touching the corresponding number for a title or chapter.
Page 32: Playback Information
JRV9000 Multi-Language Discs (DVD Only) Changing Audio Language - If you are watching a disc recorded in multiple languages, touch the TFT LCD screen, then touch AUDIO to choose a language. Each time the icon is touched the language will change.
Page 33: General Disc Information
JRV9000 General Disc Information Disc Properties Symbol 12cm Disc Properties Max Play Time Single side single layer (DVD-5) (MPEG 2 Method) Single side double layer (DVD-9) 133 minutes Double side single layer (DVD-10) 242 minutes Double side double layer (DVD-18)
Page 34: Cd Main Menu
JRV9000 CD Operation From the Main Menu Screen touch the DISC icon or insert a CD into the disc slot, label side up. Playback begins in CD mode when a disc is inserted correctly. CD Main Menu The on-screen icons and touch key areas are outlined below.
Page 35 JRV9000 List - Touch this icon to access the list of tracks contained on the disc. Touch a desired track icon twice and the track will begin playing. ) Shuffle - Touch this icon to play tracks in the directory in a random order.
Page 36 JRV9000 CD List Touching the List icon will display the CD List Screen. The CD List Screen illustrates the contents of a CD disc. The contents are divided into folders and various file types. Touching the icon will display the files present on the disc.
Page 37 JRV9000 Track Direct Entry When the Direct Entry icon is touched the Direct Entry Screen appears. The user can manually select a track by touching the corresponding number. After entering the track numbers touch the OK icon. If a wrong digit is entered touching the arrow will remove the number.
Page 38 JRV9000 MP3/WMA Operation MP3 is a format for storing digital audio. An audio CD-quality song can be compressed into the MP3 format with very little loss of quality, while taking up much less space. Insert a MP3 Disc into the disc slot, label side up. Playback begins in MP3 mode when a disc is inserted correctly.
Page 39 JRV9000 Controlling Playback Inserting a Disc- Upon inserting a MP3/WMA disc, disc play begins. You cannot insert a disc if there is already a disc in the unit or if the power is off. Ejecting a Disc - Press the Eject ( ) button on the front of the unit to eject the disc.
Page 40: Am-Fm Radio
JRV9000 RADIO TUNER OPERATION From the main menu screen touch the radio icon. The radio tuner display screen appears. Radio Tuner TFT Display The on-screen icons and touch key areas are outlined below. Radio Tuner TFT Display Screen Source Icon - Touch to view the SOURCE MENU and select a new playback source.
Page 41 JRV9000 More ( / ) - Touch the / icons to display the next or previous page of the Disc menu. ) Seek Down / Manual Seek - Touch this icon to seek the previous available radio station. Touch and hold this icon (Until "Manual Seek -" is displayed) to manually tune the radio in increments.
Page 42 JRV9000 PTY - The Program Type (PTY) function displays the program category of the current station such as category (news, sports, talk etc.) Use the scroll bar to select various categories. After selecting a category, press the down arrow icon to scan to the next station of the selected category.
Page 43: Using Preset Stations
JRV9000 Direct Entry Tuning When the Direct Entry icon is touched the Direct Entry Screen appears. The user can enter the desired radio station frequency using the on-screen number pad. After entering the radio station frequency touch the OK icon. If a wrong digit is entered touching the green arrow will remove the number.
Page 44 JRV9000 3. Touch the preset number in which you would like to store the current station. The station frequency is displayed at the top of the menu. The preset number will appear highlighted. The station frequency will be stored in the highlighted preset.
Page 45: Usb / Microsd Card
JRV9000 The unit will read the audio/video les on USB devices automatically. To insert a USB device: Locate the Interface Cover on the front of the radio. MUTE AV AUX USB Cable (not included) MicroSD card slot Right Audio Left Audio...
Page 46 JRV9000 USB Operation From the main menu screen touch the USB icon. USB Main Menu The on-screen icons and touch key areas are outlined below. USB Main Menu Source Icon - Touch this icon to return to the Main Menu Screen.
Page 47 JRV9000 List - Touch this icon to access the list of audio and video files contained on the USB device. Touch a folder icon and the contents of the folder will be displayed. Touch a desired track icon twice and the track will begin playing.
Page 48 JRV9000 USB List Touching the "List" icon will display the USB List Screen. The USB List Screen displays the audio and video files present on the USB device. The contents are divided into folders and various file types. The file types consist of audio and video files.
Page 49 JRV9000 Direct Entry When the Direct Entry icon is touched the Direct Entry Screen appears. The user can manually select a track by touching the corresponding number. After entering the track numbers touch the OK icon. If a wrong digit is entered use the arrow/backspace key to remove the number.
Page 50: Ipod®/ Iphone® Connectivity
JRV9000 iPod® / iPhone® Controls Accessing iPod® Mode The user can control an iPod®/iPhone® using the touch screen to access, albums, songs, etc. The unit will automatically switch to iPod® mode when an iPod®nano, iPod® touch or iPhone® is plugged into the front panel USB connector. Also the iPod®...
Page 51 JRV9000 ) Previous - Touch this icon to play the previous track. ) Play/Pause - Touch this icon to begin playback. Touch this icon again to pause playback. ) Next - Touch this icon to play the next track. List - Touch this icon to access the list of audio and video les contained on the iPod®.
Page 52 JRV9000 ) Audio Files - Touch the audio file icon to display the audio file. Touch the audio file icon to select a track. Touch the audio file icon again to confirm and playback will begin. ) Video Files - Touch the video file icon to display the video file. Touch the video file icon to select a video file.
Page 53: Av-In1 / Av-In2
JRV9000 Connecting External Devices AV In 1 / AV In 2 AV In 1 AV In 1 is used for playback of audio/video from an external device connected to the unit through a 3.5mm jack located on the front panel. The unit can increase or decrease the volume of the connected device.
Page 54: Hdmi / Mhl Connectivity
Android smartphones will require an app that must be downloaded from Google Play Store. Search for "Jensen HDMI/MHL Connect" in the search bar. Note: In order to connect your smartphone to your JRV9000, you will need an HDMI/MHL adapter for your particular brand of smartphone. In some...
Page 55 Plus® / iPhone 5® / iPhone 5S® / iPhone 5C® / iPod touch® (5th Gen) / iPod nano® (7th Gen) Note: In order to connect your smartphone to your JRV9000, you will need the "Apple Lightning Digital AV Adapter" (HDMI/MHL adapter). No app or software is needed for Apple devices.
Page 56 HDMI/MHL adapters. Connect your smartphone to the HDMI/MHL adapter. Connect one end of the HDMI cable to the HDMI/MHL adapter. Connect the remaining end of the HDMI cable to the Jensen multimedia head unit HDMI input (Rear chassis panel). Consult your smartphone documentation for instructions on how to access HDMI/MHL on your device.
Page 57 A2DP). Adhere to the following guidelines for successful operation. • Before using BT functions, you must pair your mobile phone to the JRV9000 unit (see “Pairing the Your Mobile Phone with the Unit”. To ensure the best reception for pairing and re-connection, please make sure the mobile phone battery is fully charged before you begin.
Page 58 ) - Indicates whether the unit is connected with a BT device. Touch to connect to a BT device. ( ) - Touch to disconnect from a BT device. JRV9000 Device Name - Provides the name that will appear on the BT device. Scan - Touch the icon to search for BT devices...
Page 59 NOTE: Some mobile phones require a “pass key” or pairing code to connect. If your phone requires a pass key or pairing code, you will need to enter this number. The default pairing code for the JRV9000 is "1234". 10. A prompt to enter a PIN number or passkey for the unit should appear. The default passkey for the unit is “1234”.
Page 60: Managing Incoming Calls
JRV9000 Managing Incoming Calls When connected to a BT mobile phone, the unit will mute audio output, pause CD play, and change to the BTscreen below when a call is received. The incoming phone number or assigned name for that number will appear on the screen. An audible tone will sound from the unit and a graphic display will appear on the front panel.
Page 61: Direct Dialing
JRV9000 Direct Dialing: Press the front panel MENU button and then touch the BT icon to access the BT main menu. The following screen will appear: BT Direct Dial Screen 2. Use the 0-9, */+, and # icons to input the phone number. If necessary touch the green arrow icon to clear the last digit or the entire number and start over.
Page 62: Audio Mute
JRV9000 Audio Mute To mute the phone call audio from the unit when a call is received, press the front panel rotary knob. Press the front panel rotary knob again and phone call audio will be restored to the unit.
Page 63: Call Transfer
JRV9000 Call Transfer While talking, to transfer audio from the unit back to the mobile phone, touch the To Phone icon. You can only transfer a call after it has been answered. Touching the To Device icon will return the audio from the mobile phone to the unit.
Page 64 PTT (Push to Talk) Function The JRV9000 has a PTT button to allow you to access Siri or Google Voice through the head unit when connected via BT. You mobile phone must support Siri or Google Voice in order for this feature to be supported on the head unit.
Page 65: Camera Operation
JRV9000 CAMERA OPERATION Enter Camera Mode Connect the cameras to the unit using the CAMERA 1-3 Connection cables at the back of the unit. Enter 2nd page of main menu, press CAMERA to access camera mode. Enter Camera Mode This unit can connect 3 cameras:CAM1, CAM2 and CAM3. Each camera can be triggered back of the unit.
Page 66 JRV9000 Audio Output and Volume Adjustment In camera mode, if Camera 1 is not triggered, the front audio output will be the from the last audio source played. Rotate the VOL control (1) to adjust the volume of the audio source. When Camera 1 is triggered and the Auto Mic Enable feature is on, the camera 1 video appears on the entire screen and the audio input from the camera is played.
Page 67: Steering Wheel Controls (Swc)
SWC Ready The built-in SWC Interface is compatible with PAC steering wheel control modules. The PAC SWI-RC is recommended. A third-party adapter must be used in order for the JRV9000 to be compatible with any steering wheel controls. Note: Not all OE steering wheel functions may be supported by the JRV9000. PTT - Will activate Siri / Google Voice if mobile phone supports the feature.
Page 68 JRV9000...
Page 69: Siriusxm® Radio
JRV9000 SiriusXM® RADIO OPERATION Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the best sports, news, talk, comedy and entertainment. Welcome to the world of satellite radio. A SiriusXM Vehicle Tuner and Subscription are required.
Page 70 JRV9000 SiriusXM® User Interface The on-screen indicators and touch key areas for SiriusXM® functions are outlined below. Menu Page 1 SiriusXM® Menu Page 1 Source Icon - Touch to return to the unit’s Main Menu Screen. Band indicator (SXM1 icon) - Displays SiriusXM® radio band currently selected.
Page 71 JRV9000 Previous ( ) Icon - Touch to tune to the previous channel. Channel/Category Icon - Touch to toggle the icon displayed between Category and Channel. When Channel is displayed, touching tunes channels up or down. When Category is displayed, touching tunes channels within a category up or down.
Page 72: Direct Tuning
JRV9000 Switching to SiriusXM® Radio • Touch the top left corner of the screen (the Source box) to view the Main Menu screen. From the Main menu screen, touch the SiriusXM icon. • Press the MENU button on the front panel to switch to the SXM source.
Page 73 JRV9000 Using Preset Channels A preset is a channel name that is stored for instant access to that channel. Ten numbered preset buttons store and recall channels for each band. Storing a Channel Select a band (if needed), then select a channel.
Page 74 JRV9000 Searching for a Channel Search by Channel To search by channel: On the SirusXM® menu page 1, touch the Category/Channel icon (if needed) to select Channel. 2. Touch List to display the Channel Search Screen: Channel Search Screen 3. Touch on a channel to tune to that channel. Touch the or icon to scroll up or down the list.
Page 75 JRV9000 Locking SXM Mature Channels SiriusXM® attaches a label to channels with mature content. The radio recognizes these channels as “Mature”. The Mature Channel Lock option allows you to lock out channels with “Mature” labels. These channels will still appear in the channel...
Page 76 JRV9000 Temporarily Unlock a Mature Channel When the global “Mature Lock” is enabled, a mature channel can be temporarily unlocked. All mature channels are temporarily unlocked (but still hidden when channel browsing) until the SXM source is changed, Accy (Key) is cycled or the “Power Button”...
Page 77 JRV9000 Unlock All Mature Channels To unlock all mature channels: On the SirusXM® menu page 2, touch the Lock icon. The following screen appears: Enter Lock Password Screen 3. Enter your 4-digit password . The following screen appears: 4. Touch the Unlock All icon. All channels are now unlocked.
Page 78 JRV9000 Locking Individual SXM Channels An user can lock individual channels. When locked, a channel has the lock ( icon next to it on the channel list. Locking a Channel To lock an individual channel: On the SirusXM® menu page 2, touch the Lock icon. The following screen...
Page 79 JRV9000 Unlocking a Channel To unlock an individual channel: On the SirusXM® menu page 2, touch the Lock icon. The Enter Password Screen appears appears. 2. Enter your 4-digit password. The following screen appears: Unlock Screen 3. Touch a lock ( ) icon to unlock a channel.
Page 80 JRV9000 SiriusXM® Radio Advisory Messages SiriusXM® user advisory messages are listed below: Advisory Displayed Cause Check SXM Tuner Check the SiriusXM® tuner connection on the back of the unit to ensure that it’s correctly connected. Check SXM Antenna Ensure the SiriusXM® antenna cable is connected to the SiriusXM®...
Page 81: Troubleshooting
JRV9000 TROUBLESHOOTING Troubleshooting Problem Cause Corrective Action GENERAL Unit will not power Radio Fuse open Install new fuse with correct rating Car battery fuse open Install new fuse with correct rating Illegal operation Press the RESET button located in the middle...
Page 82 JRV9000 Problem Cause Corrective Action TFT Monitor No image Incorrect connection to parking Check wiring and brake wire correct Parking brake is not engage Stop vehicle in safe place and apply parking brake Flashing image DVD is not compatible with...
Page 83 JRV9000 Problem Cause Corrective Action Disc does not play Disc is warped or scratched Use disc in good back condition Clean disc with soft Disc is dirty or wet cloth Laser pickup is dirty Clean laser pickup with cleaning disc...
Page 84 JRV9000 Disc Error Messages Message Displayed Cause Corrective Action Loading Disc is being read No Disc Disc is dirty Clean disc with soft cloth Disc is upside down Insert disc with label side Disc not present in Insert disc loading compartment...
Page 85: Care And Maintenance
JRV9000 CARE AND MAINTENANCE Use only a clean silicone cloth and neutral detergent to clean the front panel or monitor. A rough cloth and non-neutral detergent (such as alcohol) may result in scratching or discoloration. 2. Do not get water or cleaning fluids on the unit.
Page 86: Specifications
JRV9000 SPECIFICATIONS DVD/CD Player Compatible Disc Media: DVD + R / RW (Single and Dual Layer) and CD-R / RW Compatible Media Formats: CD-DA, MP3, WMA, VCD, SVCD, Xvid, AVI, MPEG 1/2 and AAC Signal to Noise Ratio: >95dBA Dynamic Range: >95dB Frequency Response: 20Hz to 20 kHz, -3dB Channel Separation: >...
Page 87 JRV9000 General Auxiliary (Audio) Input Impedance: 10k -Ohm Power Supply: 11 to 16VDC, negative ground Power Antenna / Amp Remote (Blue): 500mA max (Current limited protection) Operating Temperature: 0C ~ 65C / 32F ~ 149F Fuse: 15-Amp, ATO type Chassis Dimensions: 7” X 7” X 4” (178mm x 178mm x 100mm)
Page 88: Notes
JRV9000 NOTES:...
Page 89: Common Replacement Parts
JRV9000 2602 Marina Drive, Elkhart, IN 46514 WWW.ASAELECTRONICS.COM © 2015 Printed in China JRV9000 Common Replacement Parts 30314240 Wire Harness (Pwr/Spk/Line Out/BT Mic/GPS Antenna) Trim Ring (Big) 30413950 Trim Ring (Small) 30413920 Remote Control 30714230 Hardware Bag 30513950 Operation manuals and other material online at: www.jensenmobile.com...
