Summarization of Contents
installation
CHECKING THE INSTALLATION ENVIRONMENT
Guidelines for ensuring optimal operating conditions and air circulation for the device.
RACK INSTALLATION
Instructions for mounting the DVR unit in a rack, including foot separation.
INSTALLING THE HDD
Procedures and precautions for installing a Hard Disk Drive into the DVR unit.
CONNECTING EXTERNAL DEVICES
Connecting the USB
Details on connecting USB devices like HDDs, memory, or mice to the DVR's USB port.
Connecting External SATA HDD (eSATA)
Guidance on connecting external SATA HDDs for storage expansion and backup purposes.
Connecting POS Device
Instructions for connecting Point of Sale devices to the DVR via RS-232C or Ethernet.
Connecting the Alarm Input/Output
Explains the configuration of Alarm Input/Output ports for sensor and alarm device connections.
CONNECTING THE NETWORK
Connecting the RS-485 Device
Describes how to connect PTZ cameras and system keyboards using RS-485 communication.
Connecting to Network through Ethernet (10/100/1000BaseT)
Details network connection setup using Ethernet cables for remote monitoring.
GETTING STARTED
Starting the system
Step-by-step guide on powering on the DVR and initiating the system startup sequence.
Shutting Down the System
Procedures for safely powering off the DVR, requiring login and confirmation.
Login
Instructions on how to access the DVR's features by entering user credentials.
LIVE SCREEN CONFIGURATION
Icons on the Live Screen
Explanation of the various icons displayed on the Live Viewer screen and their meanings.
Live Screen Menu
Split Mode Menu
Describes the context-sensitive menu options available in split screen display modes.
LIVE MODE
Switching the screen mode
How to change display layouts like single, 4-split, 9-split, and sequence modes.
Switching the split mode
Explains switching between different split screen configurations for multi-channel viewing.
ZOOM
SPOT OUT
Configuration options for the Spot Out port, used for independent monitoring of specific channels.
AUDIO ON/OFF
FREEZE
Functionality to temporarily pause the live video feed for closer inspection.
SYSTEM SETUP
Date/Time/Language
Settings for system date, time, time zone, and user interface language.
Setting Holiday
Allows setting specific dates as holidays, affecting recording and alarm schedules.
Permission Management
Setting the Administrator
Procedures for setting or changing the DVR's administrator ID and password.
Setting the Group
Creating user groups and assigning permissions for menu access and functions.
To set the group authority
Defining specific permissions for group users regarding channel access and menu features.
To restrict the user permissions
To change the user password
Guide for users to change their individual passwords, especially when access is restricted.
Setting the User
Setting Permissions
Configuring restricted access for general users, including network access and auto log-out settings.
System Management
Checking the System Information
Viewing software version, broadcast format, MAC address, and DVR name.
Updating the Software
Steps to update the DVR's firmware using a USB device or network connection.
Log Information
System Log
Records system startup, shutdown, and setting changes with timestamps.
Event Log
Logs events such as alarms, motion detection, and video loss with timestamps.
Backup Log
Details recorded backup operations, including time, channel, device, and file format.
SETTING THE DEVICE
Camera
Configuration of video, audio, channel name, dwell time, and screen settings for cameras.
Privacy Region
Specifies areas within camera video to be protected for privacy, masking sensitive zones.
Setting the PTZ
Configuration of PTZ camera settings, including port, ID, and protocol matching.
Storage Device
Confirming Devices
Displays information about connected storage devices like HDDs and USB memory.
Formatting
Procedures for formatting storage devices to prepare them for use with the DVR.
HDD Alarm
Configuration of alarm settings for HDD defects, including output ports and duration.
Remote Devices
POS Devices
Settings for Point of Sale devices, including channel synchronization and communication ports.
POS Device Setup
Detailed setup for POS device communication, including channel, preset, and port configuration.
Monitor
Setting the Monitor
Configuring display settings for the monitor, such as event display dwell time and screen resolution.
Screen Setup
Adjusting the display position of OSD information on the monitor for better visibility.
Setting the Spot Out
Setting the Screen Mode
Configuring live and playback screen layouts, including split screen options.
SETTING THE RECORDING
Recording Schedule
Setting up scheduled recordings for specific dates and times for all or selected channels.
Event Record Duration
Defining pre- and post-event recording times for alarms, motion detection, and other events.
REC Quality / Resolution
Setting recording resolution, frame rate, and quality for standard recordings.
Setting Event Recording Properties
Configuring resolution, frame rate, and quality for event-triggered recordings.
Record Option
Setting the DVR's behavior when the HDD is full, including overwrite and beep options.
SETTING THE EVENT
Sensor Detection
Configuring sensor operation modes, connected cameras, alarm outputs, and durations.
Motion Detection
Setting motion detection modes, sensitivity, alarm outputs, and defining detection areas.
Video Loss Detection
Configuring alarm outputs and durations for detected video loss events.
Tampering Detection
Setting up tamper detection modes, sensitivity, alarm outputs, and dwell times.
Alarm Schedule
Scheduling alarm outputs based on day of the week and time, with event synchronization options.
BACKUP
Setting the Backup
Configuring backup schedules and parameters for transferring data to external storage devices.
NETWORK CONFIGURATION
Connection Mode
Setting up network connection routes and protocols like Static, DHCP, and PPPoE.
Setting the Port
Configuring protocol types (TCP/UDP), device ports, and HTTP ports for network communication.
Alarm setting
Configuring alarm outputs and durations for network connection status changes.
Network Overview
Notification
Information regarding HTTP port settings for multi-browser environments.
Port Forwarding
Instructions for configuring router port forwarding for external DVR access.
Live Transfer
Mailing Service
Configuring SMTP server settings for sending email notifications upon events.
Event Setting
Setting the interval and type of events for which email notifications are sent.
Group Setting
Managing recipient groups and their permissions for receiving email notifications.
Recipient Setting
SNMP
Configuring SNMP protocol settings for network device monitoring.
INFORMATION
Displays connected DVR model name and Web Viewer version.
CONTROLLING A PTZ CAMERA
Getting started with PTZ
Initial steps to activate and control PTZ cameras connected to the DVR.
Using the PTZ camera
Detailed guide on using PTZ controls like pan, tilt, zoom, focus, and presets.
Preset Setting
Saving and managing specific camera positions (presets) for quick PTZ camera access.
Camera Setting
Accessing and configuring camera-specific settings via the PTZ control menu.
SEARCH
Time Search
Searching recorded video footage based on specific dates and times.
Event Search
Searching recorded data by event type, such as motion detection or alarms.
Backup Search
Searching for data that has been backed up to external storage devices.
POS Search
Searching for data related to Point of Sale transactions connected to the DVR.
Motion Search
Searching for recorded video segments where motion was detected within specified areas.
PLAYBACK
Play
Instructions on how to play back recorded video data from the HDD or backup.
Using the Playback Button
Explains the functions of various playback control buttons for navigating video recordings.
INTRODUCING WEB VIEWER
System Requirements
Recommended hardware and operating system specifications for running the Web Viewer.
Split-Screen
To switch to full screen mode
Method to display a single camera feed in full screen from a split screen view.
Changing the Live Screen Mode
Options for switching between single, quad, and sequence display modes.
To capture a screen
Steps to save the current video image as a JPEG, BMP, or PNG file.
To print a screen
Instructions for printing the current camera video image.
To save as AVI
Procedure for saving live video in AVI format, including path and capacity settings.
Audio
Controls for turning audio on or off for connected channels.
OSD
Option to display or hide On-Screen Display information on the live screen.
CONTROLLING A CONNECTED PTZ CAMERA
Controlling PTZ
Overview of controlling PTZ cameras through the DVR interface, including available controls.
To set a preset
Steps to save specific camera positions (presets) for PTZ camera control.
To activate the preset
How to recall and activate saved presets for PTZ camera positioning.
To activate Swing, Group, Tour and Trace
Guides on activating advanced PTZ movement functions like Swing, Group, Tour, and Trace.
Controlling OSD Menu
Accessing and managing the camera's On-Screen Display (OSD) menu for settings adjustment.
USING SEARCH VIEWER
Searching the Recorded Video in the Calendar
Detailed steps for searching recorded video by date using the calendar interface.
To search by date
Method for selecting specific dates to view recorded video information.
To adjust timeline
Techniques for navigating and zooming the timeline for detailed review of recorded video.
Names and Functions of Play Buttons
If you back up searched videos
Steps for backing up recorded video files after performing a search.
VIEWER SETUP
System
Accessing system-level settings for the DVR remotely via the network.
Date/Time/Language
Configuring system date, time, and language settings through the viewer interface.
Holiday
Permission Management
Managing user permissions, including admin, group, and individual user settings.
User
Adding, changing, or removing user accounts for DVR access.
Setup
Configuring user-specific permissions and restrictions for accessing DVR features.
System Management
Accessing system information and managing software updates for the DVR.
Device
Camera
Configuring settings for connected cameras, including video and audio parameters.
Privacy Region
Defining privacy zones within camera video feeds to protect sensitive areas.
PTZ
Configuring settings for PTZ cameras, ensuring correct ID and protocol matching.
Storage Device
Device
Checking the status, type, and usage of connected storage devices like HDDs.
HDD Alarm
Setting up alarms for HDD defects and configuring output ports and durations.
Remote Device
Managing remote devices like PTZ cameras and keyboards connected via RS-485.
POS Device
Monitor
Configuring monitoring screen settings and output system parameters.
Record
Recording Schedule
Scheduling recording sessions for specific dates and times.
Event Record Duration
Defining the duration for recordings triggered by specific events.
REC Quality & Resolution
Record Option
Configuring disk end modes, such as overwrite or stop, when the HDD is full.
Event
Setting resolution, frame rate, and quality for event-triggered recordings.
Sensor Detection
Configuring sensor operation, alarm outputs, and durations for detection events.
Motion Detection
Video Loss Detection
Configuring alarm outputs and durations for detected video loss events.
Tampering Detection
Setting up tamper detection modes, sensitivity, alarm outputs, and dwell times.
Alarm Schedule
Network
Configuring network settings for remote DVR access and checking current mode/IP address.
DDNS
Live Transfer
Adjusting image quality and resolution for data transferred over the network.
Recipient Setting
SNMP
Configuring SNMP protocol settings for network device monitoring.
INFORMATION
Displays connected DVR model name and Web Viewer version.
CONTROLLING A PTZ CAMERA
Getting started with PTZ
Initial steps to activate and control PTZ cameras connected to the DVR.
Using the PTZ camera
Detailed guide on using PTZ controls like pan, tilt, zoom, focus, and presets.
Preset Setting
Saving and managing specific camera positions (presets) for quick PTZ camera access.
Camera Setting
Accessing and configuring camera-specific settings via the PTZ control menu.
SEARCH
Time Search
Searching recorded video footage based on specific dates and times.
Event Search
Searching recorded data by event type, such as motion detection or alarms.
Backup Search
Searching for data that has been backed up to external storage devices.
POS Search
Searching for data related to Point of Sale transactions connected to the DVR.
Motion Search
Searching for recorded video segments where motion was detected within specified areas.
PLAYBACK
Play
Instructions on how to play back recorded video data from the HDD or backup.
Using the Playback Button
Explains the functions of various playback control buttons for navigating video recordings.
INTRODUCING WEB VIEWER
System Requirements
Recommended hardware and operating system specifications for running the Web Viewer.
Split-Screen
To switch to full screen mode
Method to display a single camera feed in full screen from a split screen view.
Changing the Live Screen Mode
Options for switching between single, quad, and sequence display modes.
To capture a screen
Steps to save the current video image as a JPEG, BMP, or PNG file.
To print a screen
Instructions for printing the current camera video image.
To save as AVI
Procedure for saving live video in AVI format, including path and capacity settings.
Audio
Controls for turning audio on or off for connected channels.
OSD
Option to display or hide On-Screen Display information on the live screen.
CONTROLLING A CONNECTED PTZ CAMERA
Controlling PTZ
Overview of controlling PTZ cameras through the DVR interface, including available controls.
To set a preset
Steps to save specific camera positions (presets) for PTZ camera control.
To activate the preset
How to recall and activate saved presets for PTZ camera positioning.
To activate Swing, Group, Tour and Trace
Guides on activating advanced PTZ movement functions like Swing, Group, Tour, and Trace.
Controlling OSD Menu
Accessing and managing the camera's On-Screen Display (OSD) menu for settings adjustment.
USING SEARCH VIEWER
Searching the Recorded Video in the Calendar
Detailed steps for searching recorded video by date using the calendar interface.
To search by date
Method for selecting specific dates to view recorded video information.
To adjust timeline
Techniques for navigating and zooming the timeline for detailed review of recorded video.
Names and Functions of Play Buttons
If you back up searched videos
Steps for backing up recorded video files after performing a search.
VIEWER SETUP
System
Accessing system-level settings for the DVR remotely via the network.
Date/Time/Language
Configuring system date, time, and language settings through the viewer interface.
Holiday
Permission Management
Managing user permissions, including admin, group, and individual user settings.
User
Adding, changing, or removing user accounts for DVR access.
Setup
Configuring user-specific permissions and restrictions for accessing DVR features.
System Management
Accessing system information and managing software updates for the DVR.
Device
Camera
Configuring settings for connected cameras, including video and audio parameters.
Privacy Region
Defining privacy zones within camera video feeds to protect sensitive areas.
PTZ
Configuring settings for PTZ cameras, ensuring correct ID and protocol matching.
Storage Device
Device
Checking the status, type, and usage of connected storage devices like HDDs.
HDD Alarm
Setting up alarms for HDD defects and configuring output ports and durations.
Remote Device
Managing remote devices like PTZ cameras and keyboards connected via RS-485.
POS Device
Monitor
Configuring monitoring screen settings and output system parameters.
Record
Recording Schedule
Scheduling recording sessions for specific dates and times.
Event Record Duration
Defining the duration for recordings triggered by specific events.
REC Quality & Resolution
Record Option
Configuring disk end modes, such as overwrite or stop, when the HDD is full.
Event
Setting resolution, frame rate, and quality for event-triggered recordings.
Sensor Detection
Configuring sensor operation, alarm outputs, and durations for detection events.
Motion Detection
Video Loss Detection
Configuring alarm outputs and durations for detected video loss events.
Tampering Detection
Setting up tamper detection modes, sensitivity, alarm outputs, and dwell times.
Alarm Schedule
Network
Configuring network settings for remote DVR access and checking current mode/IP address.
DDNS
Live Transfer
Adjusting image quality and resolution for data transferred over the network.
Recipient Setting
SNMP
Configuring SNMP protocol settings for network device monitoring.
INFORMATION
Displays connected DVR model name and Web Viewer version.
MOBILE VIEWER
What is Mobile Viewer?
Introduction to the mobile application for remote DVR management.
Key Features
Highlights of the mobile viewer's capabilities, including remote access and PTZ control.
Compatible Smartphone
Lists supported smartphone operating systems and versions for the mobile viewer.
SEC BACKUP VIEWER
Recommended System Requirements
Specifies the minimum hardware and software requirements for using the SEC backup viewer.
OPEN SOURCE ANNOUNCEMENT
How to Apply These Terms to Your New Programs
Guidance on incorporating the software's terms into new programs.
GNU LESSER GENERAL PUBLIC LICENSE
TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION
Outlines the terms and conditions for copying, distributing, and modifying software under this license.
Need help?
Do you have a question about the SRD-894 and is the answer not in the manual?
Questions and answers
