INSTALLING THE HEATER

Carefully remove your heater from the box and check the contents.
1
In addition to the heater you also need to have:
a transportation cap
C
these directions for use
Keep the box and the packaging materials (Fig. A) for storage and/or
transportation.
Remove the other packaging materials:
2
Release the right side of the grill
D
side of the grill to the left and then pull it forward (Fig. B).
Pull both ends of the packaging to the rear and at the same time slightly
downwards (see Fig. C).
Remove the combustion chamber
aging underneath (see Fig. D).
Put the combustion chamber back into its place. The combustion chamber
E
is positioned correctly when it can be smoothly moved a little to the left
and to the right by its handle
reposition it in its slot.
Open the lid of the removable tank
If the left side of the grill has been removed, first insert the flattened upper left
F
end of the grill into the upper left slot and then insert the other flattened end
into the lower left slot (Fig. E).
Fill the removable tank as indicated in Section B.
3
Insert the batteries into their holder
4
Ensure that the positive and negative poles match the + and - marks indicated
G
on the battery housing. It is best to use new alkaline batteries (4x D-size).
The floor should be firm and completely level. Reposition the heater, when it is
5
not level. Do not correct the situation by placing books or other goods under the
heater.
Your heater is now ready for use.
6
B

FILLING FUEL

Do not fill the removable tank in the living room, but in a more suitable place
H
(there can always be some spillage). Follow the procedure below:
Make sure that the heater is switched off.
1
Open the lid
2
Note: Some drops may leak from the tank. Put down the removable tank
(cap pointing upwards) and screw off the fuel cap.
from the two slots by pulling the right
from the heater and remove the pack-
(Fig. F). Close the grill: Slightly lift it to
and remove the piece of cardboard.
at the back of the heater (Fig. G).
and lift the removable tank out of the heater (Fig. H).
