- Page 1 R 22x C MANUEL D'UTILISATION GEBRAUCHSANWEISUNG BRUGSANVISNING INSTRUCCIONES DE USO OPERATING MANUAL ISTRUZIONI D’USO > GEBRUIKSAANWIJZING...
- Page 2 This appliance comes with a 24-month manufacturer’s warranty on all defects in material or workmanship. We wish you much warmth and comfort from your heater. Yours sincerely, PVG International b.v. Customer Service Department 1 READ THE DIRECTIONS FOR USE FIRST. 2 IN CASE OF ANY DOUBT, CONTACT YOUR DEALER.
-
Page 3: General Directions For Use
GENERAL DIRECTIONS FOR USE MAIN COMPONENTS Below you will find the main steps to be taken for using your heater. For more details, please refer to OFF - button the MANUAL (pages 53 ff.). Knurled wick adjustment knob Remove all packaging materials (refer to Section A, Fig. A). Ignition button Fill the removable tank and wait 30 minutes before you... -
Page 4: What You Need To Know In Advance
WHAT YOU NEED TO KNOW IN ADVANCE ALWAYS MAKE SURE THAT THERE IS SUFFICIENT VENTILATION This heater is equipped with an air quality control system . When there is insuffi- cient ventilation in the room or when the heater is being used in a room which is too small, the heater will shut off automatically. -
Page 5: Installing The Heater
MANUAL INSTALLING THE HEATER Carefully remove your heater from the box and check the contents. In addition to the heater you also need to have: a transportation cap these directions for use Keep the box and the packaging materials (Fig. A) for storage and/or transportation. - Page 6 Take the manual fuel pump and insert the smooth, most rigid tube into the jerrycan. Make sure that it is in a higher position than the removable tank (Fig. I). Insert the ribbed hose into the opening of the removable tank. Lock the valve on top of the pump (turn clockwise).
-
Page 7: Switching Off The Heater
If the heater has been used only a few times and the wick adjustment knob is not locked, first turn the wick adjustment knob (Fig. M) completely left, before putting the wick in the highest position for ignition (Section C). After having ignited the heater, always check whether the combustion chamber is level, by sliding it slightly to the left and the right by its handle... -
Page 8: Maintenance
IRREGULAR FLAME AND/OR SOOT AND/OR SMELLS The combustion chamber has not been positioned correctly. Use the handle to put it level, until you can easily slide it slightly to the left and to the right and the chamber is level. You are using fuel which is past its ‘use by’... - Page 9 1. THE BATTERIES You may replace the batteries yourself. Do not dispose of old batteries along with the other domestic waste. Follow the locally applicable regulations regarding the disposal of domestic chemical waste. 2. THE IGNITION COIL The ignition coil will have a longer life, if you ignite the heater in the correct manner.
-
Page 10: Warranty Provisions
TRANSPORTATION Take the following measures to avoid fuel leakage during the transportation of the heater: Let the heater cool down. Remove the removable tank from the heater and remove the fuel filter (Fig. O). Some drops may leak from the filter; keep a cloth at hand. Store the fuel filter and the removable tank outside the heater. -
Page 11: Tips For Safe Use
The warranty will not apply to damages caused by actions not in compliance with the Directions for Use, neglect, and the use of an incorrect type of fuel, or fuel past its use-by date. The use of incorrect fuel can even be dangerous*. Transportation costs and the risks involved during the transportation of the heater or heater components will always be the responsibility of the purchaser. - Page 12 20 cm 50 cm 50 cm REPLACEMENT OF THE WICK 150 cm 50 cm ENSURE THAT THE HEATER IS OFF AND COMPLETELY COOL BEFORE STARTING TO REPLACE THE WICK. Open the lid and remove the removable tank. Remove the batteries from the battery holder. Open the front grill.
- Page 13 Install the wick to the wick sleeve according to the allo- 1 1 2 2 a a 1 1 2 2 b b wed direction engraved on the wick sleeve. Install the wick sleeve (with wick) to the primary air tube.
- Page 14 1-3 cm.
- Page 15 20 cm *R22xC: Stover R222C 150 cm 50 cm Tectro R223C 3 Sous réserve de modification 2 Ändrungen vorbehalten 6 Ændringer forbeholdes 5 Nos reservamos el derecho de hacer modificaciones 4 Subject to modifications > Sogetti a modifiche 1 Wijzigingen voorbehouden 100 cm 20 cm 50 cm...
- Page 16 DISTRIBUTED IN EUROPE BY PVG INTERNATIONAL b.v. i ÖSTERREICH 4 UNITED KINGDOM PVG Austria VertriebsgmbH Scott Brothers Ltd. The Old Barn, Holly House Estate Salaberg 49 Cranage, Middlewich, CW10 9LT UK 3350 HAAG tel.: +44 1606 837787 tel: +43 7434 44867...
