  • Page 1 B R A N D N A M E ALTAIR RTN INSTALLATION, USE AND MAINTENANCE IST 04 C 126 - 01...

  • Page 2: Warnings

    Dear Customer, Thank you for choosing and buying one of our boilers. Please read these instructions carefully in order to install, operate, and maintain this equipment properly.

  • Page 3: General Notes For The Installer, Maintenance Technician And User

    GENERAL NOTES FOR THE USER AND THE INSTALLER This INSTRUCTION BOOKLET is an When installing the equipment do Where the equipment is not to be integral and essential part of this not throw the packing away. All the used for an extensive period of time, product and must be handed to the materials can be recycled and must disconnect it from the electrical...

  • Page 4: Table Of Contents

    CONTENTS Warnings page 1 General notes for the installer, maintenance technician and user page 2 Instructions for the user page 4 Control panel page 4 Operating the boiler page 5 1.2.1 Switching on page 5 1.2.2 Switching off page 5 1.2.3 Burner cut-out page 5 1.2.4 Cut-Out do to overheating...

  • Page 5: Instructions For The User

    1. INSTRUCTIONS FOR THE USER 1.1 CONTROL PANEL fig. 1 1. General switch with line light (green) 6. LED to indicate cut-out due to no 9. Water thermometer (models RTN 2. Reset button draught on the flue or low gas 18 to RTN 48) or thermometer/pres- 3.

  • Page 6: Operating The Boiler

    1.2 Operating the boiler (Fig. 1) Please Note: When igniting the bur- Contact qualified personnel or an ner after the boiler has been out of authorised Service Centre for main- 1.2.1 Switching on use for a long period of time, espe- tenance.

  • Page 7: Cut-Out Due To Incorrect Draught On The Flue

    1.2.5 Cut-out due to incorrect The boiler must be maintained only draught in the flue by qualified personnel. The user may only clean the casing Should conditions arise that lead to a on the boiler, and this must be faulty draught in the flue, the boiler done using products for cleaning cuts out and red light 6 comes on.

  • Page 8: Technical Characteristics And Dimensions

    21st May 1992. tric circuit. EMC Directive 89/336/EEC dated • Provision for the electrical connec- ALTAIR RTN E 18 and RTN 18 with 3rd May 1989, as amended by tion of a heating pump. a heat output of 18 kW.

  • Page 9: Dimensions

    2.2 Dimensions Delivery Return Smoke Flue MODEL (mm) D (mm) RTN 18/RTN E 18 G1” 1/4 G1” 1/4 G 3/4” RTN 24/RTN E 24 G1” 1/4 G1” 1/4 G 3/4” RTN 32/RTN 36 - RTN E 32/RTN E 36 G1” 1/4 G1”...

  • Page 10: Technical Data

    2.3 Technical Data MODELS RTN E 18 RTN E 24 RTN E 32 RTN E 36 RTN E 48 RTN 18 RTN 24 RTN 32 RTN 36 RTN 48 EC Efficiency class 51BP2712 EC PIN Category II2H3+ Type B11BS Heat output 31,5 Heat input 26,6...
  • Page 11 MODELS RTN E 60 RTN E 70 RTN E 80 RTN E 90 RTN E 100 EC Efficiency class EC PIN 51BP2708 Category II2H3+ B11BS Type Heat output 76,3 87,3 98,2 109,7 Heat input 91,7 91,7 91,7 91,6 91,6 Performance at nominal load 90,6 90,40 90,3...

  • Page 12: Instructions For The Installer

    3. INSTRUCTIONS FOR THE INSTALLER 3.1 Installation standards 3.2.5 Smoke chimney system The producer accepts no respon- This ALTAIR boiler must be installed sibility for damage to people, ani- The ALTAIR boilers have a smoke in compliance with current laws and mals, or property due to failure to flue coupling that is suitable for con- standards, which are taken as being...

  • Page 13: On-Site Measurement Of Combustion Efficiency

    3.2.6 On-site measurement of During installation relevant stan- 3.3 Filling the system combustion efficiency dards must be complied with and are taken as being an integral part Once all the connections in the To determine combustion efficiency of this booklet. system have been completed, the the following measurements must be heating circuit can be filled.

  • Page 14: Starting The Boiler

    3.4 Starting the Boiler 3.5 Wiring Diagrams 3.4.1 Preliminary Checks BC: Flame control Before starting the boiler it is advisable to check that: EA: Ignition electrode • The smoke flue has been installed in compliance with ER: Flame detection electrode F1: Protection fuse F4A 250V instructions.

  • Page 15: General Layout

    3.5.1 General layout ALTAIR 18 - 48 RTN fig. 6 ALTAIR 18 - 48 RTN E fig. 7...
  • Page 16 ALTAIR 60 RTN E fig. 8 ALTAIR 70 - 100 RTN E fig. 9...

  • Page 17: Topographycal Diagrams

    3.5.2 Topographical Diagrams ALTAIR 18 - 48 RTN fig. 6a ALTAIR 18 - 48 RTN E fig. 7a...
  • Page 18 ALTAIR 60 RTN E fig. 8a ALTAIR 70 - 100 RTN E fig. 9a...

  • Page 19: Gas Conversions

    3.6 Gas conversions pressure regulating screw all the the nut that secures the olive. way. • Remove the LPG nozzle on the Changing a boiler over from natu- • Screw the pressure regulating cap main burner and fit the natural gas ral gas to LPG and vice versa is back on and seal it (using paint or a nozzle, checking that this is as indi-...
  • Page 20 B R A N D N A M E Fondital S.p.A. 25078 VESTONE (Brescia) Italy Via Mocenigo, 123 Tel. (+39) 0365 596.211 Fax (+39) 0365 820.200 e mail: fondital@fondital.it The producer reserves the right to make minor modifications to the products www.novaflorida.it as required, without affecting the basic features.
