Summarization of Contents
Safety
Directives
Compliance with European, legal, and environmental protection regulations.
General Safety Instructions
Operating personnel training, manual use, safety covers, and disconnection procedures.
Safety
Safety Symbols
Explanation of hazard, injury, and electric voltage warning symbols used in the manual.
Owner-Operator Responsibilities
Owner-operator duties regarding manual availability, training, and safety compliance.
Safety
Operating Personnel
Responsibilities and obligations for operating personnel in safe machine use.
Technical Staff
Responsibilities and obligations for technical staff in maintenance and repairs.
Safety
Specific Danger Warnings
Specific warnings about operating area, needle range, and machine part hazards.
Machine Technical Specifications
PFAFF 2081; PFAFF 2083 Specifications
Detailed specifications including stitch type, needle system, speed, and dimensions.
Transport, Packaging, and Storage
Transport to Customer Premises
Information on how machines are packed for delivery.
Transport Within Customer Premises
Guidelines for transporting machines within customer premises, emphasizing vertical position.
Packaging Material Disposal
Details on packaging materials and customer responsibility for disposal.
Machine Storage Guidelines
Guidelines for storing the machine, protecting against dirt, moisture, and corrosion.
Machine Operating Controls
Main Power Switch
Location and function of the main power switch for turning the machine on/off.
Machine Head Keys and Functions
Explanation of keys on the machine head for backtacking and parameter assignment.
Machine Operating Controls
Pedal Controls and Functions
Functions of the pedal positions for sewing, foot lift, and thread trimming.
Sewing Foot Hand Lever Operation
Operation of the hand lever to lift the sewing foot.
Machine Operating Controls
Feed Regulator Adjustment
Adjusting stitch length and using the key for reverse sewing.
Knee Lever Control
How to use the knee lever to raise the sewing foot.
Machine Operating Controls
Edge Trimmer -731/01 Operation
Operation and safety warning for the edge trimmer -731/01.
Control Panel Information Reference
Reference to the drive manual for control panel description.
Machine Set-up and Initial Commissioning
Initial Site Set-up Requirements
Requirements for the erection site and electrical connections for initial setup.
Adjusting Table Height
Instructions for adjusting the table height and leveling the stand.
Machine Set-up and Initial Commissioning
Installing Sewing Machine into Stand
Steps for mounting the sewing head onto the table top and securing it.
Machine Set-up and Initial Commissioning
Start Inhibitor Assembly and Adjustment
Procedure for mounting and adjusting the start inhibitor switch.
Machine Set-up and Initial Commissioning
Electrical Connections and Grounding
Guide to connecting plugs and ground cables for proper operation and safety.
Machine Set-up and Initial Commissioning
Reel Stand Assembly
Instructions for assembling the reel stand and securing it to the table top.
Machine Set-up and Initial Commissioning
Initial Commissioning Procedures
Steps for initial setup, including oil, inspection, cleaning, and voltage checks.
Machine On/Off Control
Procedure for turning the machine on and off using the main switch.
Drive Home Position Reference
Reference to the drive service manual for home position settings.
Start Inhibitor Function Check
Steps to verify the start inhibitor function and error message display.
General Set-up Procedures
Needle Insertion Procedure
Procedure for inserting the needle, including safety and system requirements.
General Set-up Procedures
Bobbin Winding and Tension Adjustment
Instructions for winding bobbins and adjusting bobbin thread tension.
General Set-up Procedures
Bobbin Case Removal and Insertion
Steps for safely removing and inserting the bobbin case.
Bobbin Insertion and Tension Adjustment
Procedure for inserting the bobbin and adjusting bobbin thread tension.
General Set-up Procedures
Needle Threading and Tension Adjustment
Guidance on threading the needle and adjusting needle thread tension.
Machine Maintenance and Care
Recommended Maintenance Intervals
Recommended maintenance schedule based on operation time and frequency.
Machine Cleaning Procedures
Guidelines for cleaning the machine based on operation type and dust formation.
Machine Maintenance and Care
Oil Tank Refilling
Procedure for refilling the oil reservoir, including oil type recommendations.
Oiling the Edge Trimmer -731/01
Instructions for oiling the edge trimmer and lubricating guides.
Machine Maintenance and Care
Parameter Settings Information
Note that parameter settings are in a separate list and require qualified technicians.
Table Top Specifications
Table Top Cutout Dimensions
Technical drawing with dimensions for the table top cutout.
Table Top Specifications
Table Top Assembly Layout
Diagram showing the layout and placement of components on the table top.
