Viking VEDO1302SS Installation Manual
Professional custom built-in electric single and double ovens
Hide thumbs
Also See for VEDO1302SS:
- Manual (32 pages) ,
- User manual (24 pages) ,
- Use & care manual (24 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Viking VEDO1302SS
Summary of Contents for Viking VEDO1302SS
- Page 1 Viking Installation Guide Professional Custom Built-In Electric Single and Double Ovens...
- Page 2 Please Read and Follow! Your safety and the safety of others is very important. DANGER Hazards or unsafe practices which WILL result in severe personal injury or death WARNING Hazards or unsafe practices which COULD result in severe personal injury or death CAUTION Hazards or unsafe practices which COULD result in minor personal injury or...
- Page 3 Read and Follow! shall be used if required by NFP -70 (National Electric Code), federal/state/local WARNING laws, or local ordinances. DO NOT If the use of a GFI is required WARNING WARNING WARNING DANGER ELECTRICAL SHOCK HAZARD WARNING MOVING HAZARD WARNING...
- Page 4 (measured to H M standard)* (total oven cavity) *The H M Standard for measuring oven capacity subtracts the door plug and convection baffle dimension from the total oven volume.
- Page 5 Note: minimum of 2” (5.1 cm) spacing above and below the oven to any adjacent items is required for ventilation purposes.
- Page 6 (measured to H M standard)* (Overall) *The H M Standard for measuring oven capacity subtracts the door plug and convection baffle dimension from the total oven volume.
- Page 7 Note: minimum of 2” (5.1 cm) spacing above and below the oven to any adjacent items is required for ventilation purposes.
- Page 8 LEGEND LEGEND Blocking Blocking Finished Finished Surfaces Surfaces Finished Finished Surfaces Surfaces Vertical Vertical Blocking Blocking 3/4” Base Blocking 3/4” Base Blocking Note: To install the professional custom oven in a flush mount application the flush mount Note: To install the professional custom oven in a flush mount application the flush mount accessory kit is required.
- Page 9 Distance will vary depending on the cabinet Vertical Blocking Vertical Blocking Screw Screw LEGEND Blocking Cabinet Cross Section Base Blocking...
- Page 10 LEGEND LEGEND Blocking Blocking Finished Finished Surfaces Surfaces Finished Finished Surfaces Surfaces Vertical Vertical Blocking Blocking 3/4” Base Blocking 3/4” Base Blocking Note: To install the professional custom oven in a flush mount application the flush mount Note: To install the professional custom oven in a flush mount application the flush mount accessory kit is required.
- Page 11 Distance will vary depending on the cabinet Vertical Blocking Vertical Blocking Screw Screw LEGEND Blocking Cabinet Cross Section Base Blocking...
- Page 12 CAUTION CAUTION...
- Page 13 Green White White Neutral Neutral Green Black Black White Neutral Green Black *Note:...
- Page 15 Professional Series–Select Self-Clean Electronic Off/On Temperature Indicator light Digital Clock Timing Center Indicator light Control CLEAN OVEN CLEAN OVEN SELF CLEAN BAKE CLEAN SELF CLEAN CLEAN BAKE OVEN CONV. LIGHT BAKE BROIL BROIL BROIL BROIL CONVEC CLOCK MIN/SEC BAKE START BROIL BROIL TIMER...
