Users Instruction & Installation Book for:
Europa Gas
Note: Timer must be set to 'Time of Day' and 'Manual'
before the ovens can be used.
Note: Ensure that the oven is securely fixed to the
cabinet before use.
This appliance shall be installed in accordance with the
regulations in force and only used in a well
ventilated space.
Read the instructions before installing or using the
appliance and retain them for future use

Advertisement

Table of Contents
loading

Related Manuals for Creda HBE230

Summary of Contents for Creda HBE230

  • Page 1 Double Ovens Users Instruction & Installation Book for: Europa Gas Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the ovens can be used. Note: Ensure that the oven is securely fixed to the cabinet before use. This appliance shall be installed in accordance with the regulations in force and only used in a well ventilated space.
  • Page 2 For more information on our exciting product range ring Creda Answer Centre 0541 54 64 74 Visit us on the NET at http://www.creda.co.uk interactive cookbook product selector. Our site invites you to make use of our Feel browse our product range...

  • Page 3: Table Of Contents

    CONTENTS Introduction For Your Safety – Always For Your Safety – Never Features Controls Oven Timer Operation Know Your Timer Electronic Clock & Automatic Oven Timer Operation 11-14 Grill Pan and Handle Using The Grill Using the Top Oven Using the Main Oven Care and Cleaning Installation Something Wrong?

  • Page 4: Introduction

    INTRODUCTION Your new cooker is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. To help make best use of your cooking equipment, please read this booklet carefully.

  • Page 5: For Your Safety - Always

    FOR YOUR SAFETY When used properly, your appliance is completely safe but as with any product there are certain precautions that must be observed. PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. ALWAYS Always make sure you remove all packaging and literature from inside the oven and grill compartments before switching on for the first time.

  • Page 6: For Your Safety - Never

    FOR YOUR SAFETY NEVER Never leave children unsupervised where a cooking appliance is installed as all cooking surfaces will be hot during and after use. Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach. Never remove the oven shelves whilst the oven is hot.

  • Page 7: Features

    FEATURES MAIN OVEN TEMPERATURE TOP OVEN CLOCK & OVEN TIMER CONTROL TEMPERATURE & GRILL CONTROL GRILL BURNER OVEN LIGHT GRILL PAN INNER DOOR GLASS TOP OVEN OVEN LIGHT DOOR OVEN SHELF STAY CLEAN LINER MEAT PAN MAIN OVEN DOOR DATA BADGE – Record the Model No. INNER DOOR GLASS and the Serial No.

  • Page 8: Controls

    CONTROLS TIMER MAIN OVEN TEMPERATURE CONTROL TOP OVEN TEMPERATURE & GRILL CONTROL CONTROL MARKINGS Control Description Function Knob Push in and turn the control knob fully anti-clockwise, wait for the oven burner to ignite, Main Oven Temperature Control and then turn to the required gas mark number. Note: The oven burner will only operate when the door is closed.

  • Page 9: Oven Timer Operation

    OVEN TIMER OPERATION Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the ovens can be used. AUTOMATIC COOKING The Top Oven and Main Oven can be controlled by the automatic timer. When the timer control has been set for one oven, it is possible to use the other oven only during the same automatic cooking programme.

  • Page 10: Know Your Timer

    KNOW YOUR TIMER CLOCKFACE The timer incorporates a 24 hour clock. Ensure the correct time of day is always set, before using you cooker. PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00 HOURS AND 06.00 HOURS TO PREVENT GLARE. However, should you operate the timer during these hours the display will return to normal brightness for a few seconds and then dim again.

  • Page 11: Electronic Clock & Automatic Oven Timer Operation

    ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is turned on. Step 3 When switched on the display will show 0.00 and Auto symbol will be flashing intermittently.

  • Page 12: Auto Cooking Programmes

    ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION AUTO COOKING PROGRAMMES There are two Auto Cooking programmes that can be selected using your timer:– (a) To set the timer to switch the oven(s) On and Off Automatically (b) To set timer to switch on immediately and OFF automatically after a set cook period. a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY This allows you to cook at a specified time for a chosen period before the oven switches off Automatically.
  • Page 13 ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing the Cook Period button. Note 2 When cooking automatically the End Time can be checked at any time by simply pressing the End Time button.
  • Page 14 ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION TO CANCEL AN AUTO COOKING PROGRAMME BEFORE THE COOK PERIOD HAS FINISHED. Step 1 Turn the oven control(s) to the OFF position. Step 2 Press and hold in the “Cook Period” button. Step 3 With the “Cook Period” button still held in, return the display to 0.00 by pressing the “–”...

  • Page 15: Grill Pan And Handle

    GRILL PAN & HANDLE The grill pan handle is detachable from the pan, to facilitate cleaning and storage. The grill pan handle can be fixed as follows: Step 1 Remove screw & washers from the grill pan bracket. Step 2 Tilt the handle over the recess (a). Step 3 Slide it towards the centre of the pan (b).

  • Page 16: Using The Grill

    USING THE GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS USED. YOUNG CHILDREN SHOULD BE KEPT AWAY. TOP OVEN TEMPERATURE AND GRILL CONTROL Step 1 Open the top oven door and remove the grill pan. Step 2 Place the shelf in the chosen position (see grilling chart).

  • Page 17: Using The Top Oven

    USING THE TOP OVEN Note: DO NOT allow young children near to the appliance when the top oven is in use as the surfaces get extremely hot WARNING: Items stored in the top oven will get hot when the main oven is in use. The top oven can be used to cook small quantities of food or used in conjunction with the main oven to provide additional cooking space.

  • Page 18: Top Oven Cooking Chart

    TOP OVEN COOKING CHART The following times and setting are for guidance only. You may wish to alter the setting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed.
  • Page 19 TOP OVEN COOKING CHART Shelf Food Mark Positions Approx. Cooking Time and Comments CAKES, PASTRIES AND BISCUITS Small Cakes (16 per tray) 20 - 25 mins. Victoria sandwich (2 x 180mm / 7”) 25 - 30 mins. Swiss Roll (3 egg quantity) 10 - 12 mins.

  • Page 20: Using The Main Oven

    USING THE MAIN OVEN Note: DO NOT allow young children near to the appliance when the main oven is in use as the surfaces get extremely hot The oven has different heat zones - the temperature control settings refer to the temperature on the middle shelf;...
  • Page 21 USING THE MAIN OVEN COLD START COOKING Anything requiring long slow cooking such as casseroles and rich fruit cakes can be put into a cold oven. Satisfactory results can also be obtained with creamed mixture, rich pastries or yeast mixtures, but for perfection we recommend preheating the oven for about 15 minutes at the gas mark you require for cooking.
  • Page 22 USING THE MAIN OVEN The ‘Slow Cook’ setting on the main oven thermostat is used for slow cooking, keeping food warm and warming plates for short periods. USING THE ‘SLOW COOK’ SETTING All dishes cooked by the ‘Slow Cook’ setting should be cooked for a minimum 6 hours. They will ‘hold’...

  • Page 23: Main Oven Cooking Chart

    MAIN OVEN COOKING CHART The following times and setting are for guidance only. You may wish to alter the setting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed.
  • Page 24 MAIN OVEN COOKING CHART Shelf Food Mark Positions Approx. Cooking Time and Comments CAKES, PASTRIES AND BISCUITS Small cakes - 2 trays 2 & 4 17 - 25 mins - 1 tray " Victoria sandwich 2x8" (205mm) 2 & 4 25 - 35 mins Fatless sponge 2x7"...

  • Page 25: Care And Cleaning

    CARE AND CLEANING Warning: Before cleaning, please ensure that the electricity supply to the appliance is switched off and the appliance is fully cold. 1. “CREDACLEAN” OVEN LINERS - MAIN OVEN ONLY (a) How "Credaclean" works. The surfaces of the "Credaclean" oven liners are treated with a special vitreous enamel which absorbs cooking soils.
  • Page 26 CARE AND CLEANING 3. OVEN DOORS (a) Control Panel CONTROL PANEL Regularly wipe with a clean, damp cloth and polish with a clean, dry cloth. (b) Trims It is advisable to clean the trims regularly to prevent any build up of soiling which may detract from the appearance of the cooker.

  • Page 27: Cleaning The Doors

    CARE AND CLEANING Take particular care not to damage the inner surface of the door inner glass that is coated with a heat reflective layer. Do not use scouring pads, or abrasive powder, which will scratch the glass. Ensure that the glass panel is not subjected to any sharp mechanical blows.

  • Page 28: Installation

    INSTALLATION INSTRUCTIONS Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment conditions are compatible. The adjustment conditions for this appliance are stated on the data badge which is fitted behind the bottom of the main oven door seal. This appliance is not designed to be connected to a combustion products evacuation device.

  • Page 29: Final Installation

    INSTALLATION 1. GENERAL The appliance is designed for mounting at a safe level into an oven housing which must be secured to the backing wall. 2. VENTILATION a. The oven housing unit cabinet dimensions must comply with fig. 4. b. An air gap of 30mm minimum must be provided at the rear of any top or bottom cupboards or shelves (see fig.

  • Page 30: Tall Cabinet Ventilation

    TALL CABINET VENTILATION Figure. 1 Ventilation Slot required here if cabinet does not fit to ceiling -50mm x 450mm min. area Ventilation Slot required here if the cabinet does fit to the ceiling - 50mm x 450mm min. 30mm area Air Gap 30mm Air Gap...
  • Page 31 560mm Viewed down through cabinet Cabinet No. 6 x 15mm screw (4 supplied) 875mm Oven Door Fig. 3 Fig. 2 887mm 878mm if cooker trim is to overlap top edge The appliance can be installed into a of shelf cabinet of minimum depth 550mm pro- viding suitable means...

  • Page 32: Installation Instructions

    INSTALLATION INSTRUCTIONS CONNECTING TO GAS SUPPLY The oven is designed to be connected with an approved appliance flexible connection to BS 669. A length of 1.25 to 1.55m is recommended. An adaptor backplate should be fitted in the area shown to allow the appliance to be pushed fully back into the cabinet. The flexible hose should be fitted such that it cannot come into contact with moveable parts of the housing unit (e.g.

  • Page 33: Electrical Connection

    ELECTRICAL CONNECTION WARNING – THIS APPLIANCE MUST BE EARTHED. CONNECT TO A 230-240V A.C. SUPPLY ONLY. Connection to the electricity supply should be made via a properly earthed, readily accessible wall socket which is adjacent to, and not more than 1.25m away from the appliance and capable of electri- cal isolation.
  • Page 34 INSTALLATION INSTRUCTIONS INSTALLATION AND OPERATIONAL CHECKS After installation, check for gas soundness. The supply pressure can be checked at the grill injector. Loosen the fastening screw on the left hand side of the grill burner and slide the burner to the right and then off the injector. Ensure that the grill burner is correctly located and the fixing screw tightened on reassembly.

  • Page 35: Something Wrong

    SOMETHING WRONG? Before calling a Service Engineer, please check through the following lists. THERE MAY BE NOTHING WRONG. Problem Check Nothing works. If the timer display is blank. Then it is likely that there is no electricity supply to your oven. Check: (i) That the main cooker wall switch is turned on.

  • Page 36: Service

    Republic of Ireland: (01) 842 6836 08701 546474 For further product information All Creda Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
