CCD-TRV3E/TRV13E/TRV23E/TRV45E/TRV55E/
TRV65E/TRV69E/TRV75/TRV75PK/TRV715
SERVICE MANUAL
B MECHANISM
Video camera recorder
System
Video recording system
CCD-TRV75/TRV75PK/TRV715 : 4
rotary heads (SP/LP independent heads)
CCD-TRV3E/TRV13E/TRV23E/
TRV45E/TRV55E/TRV65E/TRV69E :
2 Rotary heads
Helical scanning FM system
Audio recording system
Rotary heads, FM system
Video signal
CCD-TRV75/TRV75PK/TRV715 :
NTSC color, EIA standards
CCD-TRV3E/TRV13E/TRV23E/
TRV45E/TRV55E/TRV65E/TRV69E :
PAL color CCIR standards
Usable cassette
8mm video format cassette
CCD-TRV3E/TRV13E/TRV23E/
TRV45E/TRV55E : standard 8
CCD-TRV65E/69E/TRV75/TRV75PK/
TRV715 : Hi8 or standard 8
Recording / Playback time
CCD-TRV75/TRV75PK/TRV715 :
(using 120 min. cassette)
SP mode: 2 hours
LP mode: 4 hours
CCD-TRV3E/TRV13E/TRV23E/
TRV45E/TRV55E/TRV65E/TRV69E :
(using 90 min. cassette)
SP mode: 1 hours and 30 minutes
LP mode: 3 hours
MICROFILM
Photo : CCD-TRV55E
: RMT-708
SPECIFICATIONS
Fastforward/rewind time
CCD-TRV75/TRV75PK/TRV715 :
(using 120 min. cassette) Approx. 5 min.
CCD-TRV3E/TRV13E/TRV23E/
TRV45E/TRV55E/TRV65E/TRV69E :
(using 90 min. cassette) Approx. 5 min.
Image device
CCD (Charge Coupled Device)
Viewfinder
Electronic viewfinder
Monochrome
Lens
Combined power zoom lens
Filter diameter 17/16 in. (37 mm)
CCD-TRV13E (AEP,UK) :
16 x (Optical), 32 x (Digital)
CCD-TRV13E (EE,NE,RU) :
16 x (Optical), 160 x (Digital)
CCD-TRV65E (AEP,UK)/TRV75 (US,
CND)/TRV715 :
18 x (Optical), 72 x (Digital)
CCD-TRV23E/TRV45E/TRV55E/
TRV65E (EE,NE,RU,E,AUS,HK,CN)/
TRV75 (E, JE)/TRV75PK :
18 x (Optical), 220 x (Digital)
Focal distance
CCD-TRV3E/13E : 3/16 - 2 5/8 in.
(4.1 - 65.6 mm)
CCD-TRV23E/TRV45E/TRV55E/
TRV65E/TRV69E/TRV75/TRV75PK/
TRV715 : 3/16 - 8 in. (4.1 - 73.8 mm)
When converted to a 35 mm still camera
CCD-TRV3E/TRV13E :
1 9/16 - 24 7/8 in. (39.4 - 630 mm)
CCD-TRV23E :
1 9/16 - 28 in. (39.4 - 709 mm)
CCD-TRV45E/TRV55E/TRV65E/
TRV69E/TRV75/TRV75PK/TRV715 :
1 7/8 - 33 1/2 in. (47.2 - 850 mm)
North European Model
For MECHANISM ADJUSTMENTS, refer to
the "8mm Video MECHANICAL ADJUSTMENT
MANUAL VII" (9-973-801-11).
Color temperature
Auto
Minimum illumination*
* Minimum illumination expresses the
light level a camcoder requires to
produce a picture.
CCD-TRV23E : 0.4 lux (F 1.4)
CCD-TRV3E/13E : 0.4 lux (F1.4)
(*Visible minimum low light 0.2 lux)
* Visible minimum low light expresses
the light level to produce a visible
signal.
CCD-TRV45E/TRV55E/TRV65E/
TRV69E/TRV75/TRV75PK/TRV715 :
0.7 lux (F 1.4)
CCD-TRV23E/TRV45E/TRV55E/
TRV65E/TRV69E/TRV75/TRV75PK/
TRV715 :
0 lux (in NightShot mode)*
* Object invisible for the dark can be
shot with infrared lighting.
hVIDEO CAMERA RECORDER
CCD-TRV3E/TRV13E/TRV23E/TRV45E/TRV55E
HVIDEO CAMERA RECORDER
CCD-TRV65E/TRV69E/TRV75/TRV75PK/TRV715
RMT-708/717
US Model
Canadian Model
CCD-TRV75/TRV715
E Model
CCD-TRV3E/TRV23E/TRV45E/
TRV55E/TRV75/TRV75PK
AEP Model
CCD-TRV13E/TRV65E/TRV69E
UK Model
East European Model
Russian Model
CCD-TRV13E/TRV65E
Hong Kong Model
CCD-TRV3E/TRV23E/TRV45E/TRV55E
Tourist Model
CCD-TRV3E/TRV55E/TRV75
Australian Model
CCD-TRV3E/TRV23E/TRV45E
Chinese Model
CCD-TRV3E/TRV23E/TRV45E/
TRV55E/TRV65E
Illumination range
CCD-TRV3E/TRV13E/TRV23E :
0.4 lux to 100,000 lux
CCD-TRV45E/TRV55E/TRV65E/
TRV69E/TRV75/TRV75PK/TRV715 :
0.7 lux to 100,000 lux
Recommended illumination
More than 100 lux
LCD screen
CCD-TRV3E/TRV13E/TRV23E/
TRV65E/TRV69E :
2.5 inches measured diagonally
2 x 1 1/2 in.(50.3 x 37.4 mm)
CCD-TRV45E/TRV55E :
3.5 inches measured diagonally
2 7/8 x 2 in.(72.4 x 50.4 mm)
— Continued on next page —
