RT-20 Universal Disc Player

REAR PANEL OVERVIEW

The RT-20 is manufactured for sale in several different countries. Each version features a rear panel that includes connectors and safety instructions
appropriate to that particular region.
3
1 3
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby
Apparatus Claims of U.S. Patent Nos. 4,631,603; 4,577,216; 4,819,098; 4,907,093 and 6,516,132 licensed for limited viewing uses only.
1
8
Note:
The rear panel shown above includes all possible connectors. However,
certain connectors are not included on some versions. These instances
are noted in the rear panel connector descriptions that begin below.
1. Digital Audio Output Connectors
2. Region Code Indicator
3. Analog Audio Output Connectors
4. Component Video Output Connectors
5. IR IN Connector
6. Trigger Input Connector
2
9
3
Y
4 10
11
7. Trigger Input Switch
8. HDMI Output Connector
9. RS-232C Connector
10. S-Video Output Connector
11. Composite Video Output Connectors
12. TV A/V Euroconnector
13. AC Input Connector
Basic Operation
4
6 7
5
ON OFF
13
12
2-7
