Bulk Chain

This bidirectional dump describes a set of program chains (either the internal set of 10, or 10 from a card).
This can be initiated from the front-panel as a bulk chain dump.
Byte #
1-4
5
6
7-26
27-206
207

Chain

This bidirectional dump describes a complete program chain. This can be initiated from the front-panel
as a chain dump.
Byte #
1-4
5
6
7
8
9-26
27

Chain Element

This is a bidirectional dump which describes a single position in a program chain.
Byte #
1-4
5
6
7
8
9
10

Display

This is a bidirectional dump. When transmitted from the PCM-80, this holds the current display
information. When received by a PCM-80, this text is briefly displayed (for 2 seconds).
Byte #
1-4
5
6-25
26-45
46
Note: Any characters below 0x20 (space) or above 0x7e (tilde) are converted to space.
ByteValue Description
Header
0x5 Chain Bulk
0000 000i Internal/Card (0=Internal, 1=Card)
0iii iiii Data for chain 0 (10 if card). See description for Chain message
(0x6), bytes 7-26 for details
.... .... Data for chains 1-9 (11-19 if card)
0xF7 End of SysEx
ByteValue Description
Header
0x6 Chain Data
0iii iiii Chain #
0iii iiii Bank for chain position 0 (0x7f if nothing is mapped to this position)
0iii iiii Offset for chain position 0 (0x7f if nothing is mapped to this position).
Bank/offset for positions 1-9
0xF7 End of SysEx
ByteValue Description
Header
0x7 Chain Element Data
0iii iiii Chain #
0iii iiii Offset in chain
0iii iiii Bank
0iii iiii Offset
0xF7 End of SysEx
ByteValue Description
Header
0x08 Display message
0iii iiii Top line of display (blank-padded, no NULL terminator)
0iii iiii Bottom line of display (blank-padded, no NULL terminator)
0xF7 End of SysEx
