Table Of Contents - Lexicon MPX 1 V1.10 - MIDI IMPLEMENTATION DETAILS Midi Implementation Manual

Overview .................................................................. 1
Data Formatting .................................................... 1
Message Tables ................................................... 2
System Control ..................................................... 3
Parameter Types ............................................. 3
Messages ........................................................ 4
Request •System Configuration
Parameter Description • Parameter
Type • Data Transfer
"Learning" the MPX 1 ........................................... 4
Building a Parameter Description
Database ................................................... 4
Building the Control Tree ................................ 5
Using the Information ........................................... 7
An MRC-type Controller .................................. 7
A Glass Interface Controller ............................ 9
Device Inquiry .......................................................... 9
Message Classes .................................................. 10
00 System Configuration Message ..................... 10
Number of Parameter Types ......................... 11
Bottom Parameters ....................................... 11
01 Parameter Data Message .............................. 11
02 Parameter Display Message ......................... 13
03 Parameter Type Message ............................. 14
04 Parameter Description ................................... 15
Parameter Type Number ............................... 15
Number of Parameter Name Characters ...... 15
Parameter Name ........................................... 16
Number of Bytes ........................................... 16
Control Flags ................................................. 16
Options Parameter Type ............................... 16
Number of Units/Limits .................................. 16
Minimum Value ............................................. 16
Maximum Value ............................................ 16
Display Units Type ........................................ 17
Requesting the Parameter Description ......... 17
05 Parameter Label Message ............................ 17
06 Requests ....................................................... 18
12 Handshaking .................................................. 19
16 Database Dump ............................................. 20
18 Report Effect Parameters .............................. 21
19 Report All Effect Parameters ......................... 22
1A Program Information ..................................... 23
1B Program Dump .............................................. 24
Parameter Data ............................................. 26
LFOs through Envelopes .............................. 28
Contents
Sort Flags ...................................................... 28
Audio Routing ................................................ 29
Rules ....................................................... 31
Algorithm Numbers ....................................... 32
Program Name .............................................. 32
Effect Status .................................................. 33
Knob Data ..................................................... 33
Patch System Data ....................................... 33
Soft Values .................................................... 35
Tempo ........................................................... 35
Tempo Source ............................................... 36
Beat Value ..................................................... 36
Tap Source .................................................... 36
Tap Average .................................................. 36
Tap Source Level .......................................... 36
Meter ............................................................. 36
Master Level .................................................. 37
Master Mix ..................................................... 37
Requesting a Program Dump ........................ 37
1C Compact Program ......................................... 37
Parameters ............................................................. 37
Unique Parameters ............................................. 37
MIDI Speed ................................................... 37
Panel Button Message .................................. 37
Rate ............................................................... 38
Dumps ................................................................ 39
All LEDs Dump ................................................... 39
Display Dump ..................................................... 41
Custom Character Bitmap Dump ........................ 41
Setup Dump ........................................................ 42
Global Patches Dump ......................................... 45
Bypass Controllers Dump ................................... 46
Remap Controllers Dump ................................... 46
Current Choices Dump ....................................... 47
Patches Dump .................................................... 51
Soft Row Dump .................................................. 51
Units ................................................................ 52
Appendix A: Controller Indeces .......................... 53
Master List of Controllers .................................... 54
Global Patch Controllers ..................................... 54
Bypass Controllers ............................................. 55
Appendix B: Display Units ................................... 56
Appendix C: Glossary of Terms .......................... 57
Appendix D: Known Bugs .................................... 58
