User's Guide
Benutzerhandbuch
Manuel d'utilisation
Manuale dell'utente
Guía de usuario
MODELS.
- Base Frame Model : 32", 40", 42", 46", 47", 52", 55", 70", 82"
- Kiosk Model : 46", 52", 70"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 55" and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai 55"

Summary of Contents for Hyundai 55"

  • Page 1 User’s Guide Benutzerhandbuch Manuel d’utilisation Manuale dell’utente Guía de usuario MODELS. - Base Frame Model : 32", 40", 42", 46", 47", 52", 55", 70", 82" - Kiosk Model : 46", 52", 70"...
  • Page 2 U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 1. Hyundai IT Corp. 1229 In-ri, Apo-eup Gimcheon, Gyeongsangbuk-do 740-860 Rep. of Korea 2. Hyundai IT Corp. San 136-1 Ami-ri, Bubal-eub, Ichon-si, Kyungki-Do, 467-860 Rep. of Korea We herewith confirmed to comply with the requirements set put in the Council Directive on the Approximation of the Lows of the Member States relating to Electromagnetic Compatibility Directive (89/336/EEC), Low-Voltage Directive(73/23/EEC , 93/68/EEC) .

  • Page 4: Table Of Contents

    DIGITAL SIGNAGE Contents Major features ......................2 Safety Information ....................2 Be sure to understand ....................5 Check the product list ....................6 Proper location for product installation ..............7 Portrait Mode ......................7 Installing a Bracket(Option) ..................8 Installing a Wall Mount(Option) ................9 Title and function of each part ................

  • Page 5: Major Features

    DIGITAL SIGNAGE Major features This product has been designed to enable the user ease of use, and display information effectively and conveniently. • TFT LCD Module adopted • Vivid digital color display • OSD control function • Automatic Image control •...
  • Page 6 DIGITAL SIGNAGE - Plug the power cord correctly into the end, do not wobble/jiggle, it may cause electric shock fire. - Do not touch the power cord with wet hands, it may cause electric shock. - Overloaded AC outlets and extension cables are as dangerous as the power cord being damaged, call service engineer for replacement as it may cause electric shock or fire.
  • Page 7 DIGITAL SIGNAGE - In case of Kiosk Model, keep installing the product on the flat location and fixing the wheels not to move itself or fall down. - On Kiosk Model, make sure to turn off the power before connecting cables. - This manual contains general instructions for the display products only so refer to the provided CD-ROM manual and the driver installation manual for the driver installation instructions for touch screen and/or touch screen itself.

  • Page 8: Be Sure To Understand

    DIGITAL SIGNAGE Be sure to understand Image quality of the product CAUSE Due to the nature of LCD's property, Afterimage can occur. Afterimage appears when identical frames / images are displayed continuasly. If displayed for prolonged periods of time this can become permanent. PREVENTION When you display a freeze frame for a long time, lower the brightness and contrast (Brightness, 70/ Contrast, 80).

  • Page 9: Check The Product List

    DIGITAL SIGNAGE Check the product list Please check the following components provided with the product after you open the box. Remote control & batteries Power Cord Base Frame Type User's manual D-SUB Cable HDMI to DVI Cable (Option) HDMI cable RS232C Cable (Option) Kiosk Type (Landscape) Kiosk Type (Portrait)

  • Page 10: Proper Location For Product Installation

    DIGITAL SIGNAGE Proper location for 1. Locate the product at least 30cm away from the electric appliance or heating product. 2. The product must be placed at least 10cm away from the wall and ground. product installation 3. Keep the product out of direct ray of light and locate screen not to be reflected by the sunlight.

  • Page 11: Installing A Bracket(Option)

    DIGITAL SIGNAGE Installing a Bracket - The contents may vary depending on models (Option)

  • Page 12: Installing A Wall Mount(Option)

    DIGITAL SIGNAGE •• - Only install the product on a vertical wall. Near high-tension wires Installing a Wall Mount - To ensure product performance and avoid damage, it is - Use an appropriate installation method for the material of the (Option) strongly recommended that you avoid the following wall.

  • Page 13: Title And Function Of Each Part

    DIGITAL SIGNAGE Title and function of each Remote control receiving sensor. Menu button : to display menu or exit from the menu. part Power display LED red-stand by/ Green-working. select button. OSD button. To move down in OSD menu. Control Panel Power button ;...
  • Page 14 DIGITAL SIGNAGE Terminal panel AC IN PC D-SUB OUT COMPONENT OUT (Y/Pb/Pr) AC POWER SWITCH UPGRADE CVBS IN CVBS OUT HDMI IN PC AUDIO IN COMPONENT AUDIO IN (L/R) HDMI OUT RS-232C OUT COMPOSITE AUDIO IN (L/R) SPEAKER OUT RS-232C IN &...
  • Page 15 DIGITAL SIGNAGE Remote control To turn the power on or off. Move up in OSD menu. To move left or control the volume down in OSD menu. To move right or control the volume up in OSD menu. To move down in OSD menu. Select in OSD menu.

  • Page 16: How To Connecting Kiosk

    DIGITAL SIGNAGE How to Connecting Kiosk PC or Player (Satellite receiver, Camcorder etc.)

  • Page 17: How To Connecting Digital Rgb(Hdmi)

    DIGITAL SIGNAGE How to Connecting Digital RGB(HDMI) 1. Please ensure that the power to the device is switched off, then connect each cable one after another before restoring power. 1 when connect HDMI to HDMI cable 2 when connect DVI to HDMI cable –...
  • Page 18 DIGITAL SIGNAGE Support timing for Horizontal frequency Vertical frequency Resolution HDMI (KHz) (Hz) 480p 640 x 480p 576p 720 x 576p 720p 1280 x 720p 50 / 60 1080i 1920 x 1080i 50 / 60 640 x 480 31.47 59.94 800 x 600 37.88 60.32...

  • Page 19: How To Connecting Analog Rgb(Pc D-Sub)

    DIGITAL SIGNAGE How to Connecting analog RGB (PC D-SUB) 1. Please ensure that the power to the device is switched off, then connect each cable one after another before restoring power. 2. Connect D-SUB to D-Sub cable. Then tighten the screw of the cable after connecting PC D-SUB.
  • Page 20 DIGITAL SIGNAGE Support timing for PC Horizontal frequency Vertical frequency Resolution (KHz) (Hz) 640 x 480 31.47 59.94 800 x 600 37.88 60.32 1024 x 768 48.36 60.00 1366 x 768 47.71 60.00 1280 x 1024 63.98 60.00 1920 x 1080 67.50 60.00 *6 is for Full HD model only.

  • Page 21: How To Connecting The Component(Option)

    DIGITAL SIGNAGE How to Connecting the component (Option) 1. Please ensure that the power to the device is switched off, then connect each cable one after another before restoring power. 2. Connect the component cables to Y, Pb, and Pr correctly. Connect BNC cable and tighten.
  • Page 22 DIGITAL SIGNAGE Support timing for Horizontal frequency Vertical frequency Resolution component & AV (KHz) (Hz) 480i 640 x 480i 59.94 / 60 640 x 480p 59.94 / 60 480p 720 x 480p 59.94 / 60 576p 720 x 576p 720p 1280 x 720p 59.94 / 60 / 50 1080i...

  • Page 23: How To Connecting The The Video(Option)

    DIGITAL SIGNAGE How to Connecting the the video (Option) 1. Please ensure that the power to the device is switched off, then connect each cable one after another before restoring power. 2. Connect video cable and BNC cable, and then tighten. 3.

  • Page 24: Adjusting Osd And Explanation Of Its Function

    DIGITAL SIGNAGE Adjusting OSD and Users can automatically adjust the picture mode according to the input mode. explanation of its Picture Picture function Picture Mode Custom Picture Mode Custom How to Select the Picture Custom  Dynamic Custom  High Mode Colour Tone ...
  • Page 25 DIGITAL SIGNAGE How to Set the Desired Users can manually adjust their desired picture Picture 1. Press Menu button. Custom Menu items appear on the screen. Brightness 2. Press ↲ button to select "Picture" Icon. Contrast "Picture mode" is highlighted. Colour 3.
  • Page 26 DIGITAL SIGNAGE Users can adjust Color as users want. How to Select a Colour Tone 1. Press Menu button. Colour Tone Menu items appear on the screen. Colour Tone Custom 2. Press ↲ button to select "Picture" Icon. "Picture Mode" is highlighted. Green 3.
  • Page 27 DIGITAL SIGNAGE How to Set the Display Size Users can adjust the display scale as they want Picture Picture Picture Mode Auto size Picture Mode Custom Wide Custom   Colour Tone Panorama Colour Tone 4 : 3   Size Zoom Size...
  • Page 28 DIGITAL SIGNAGE 1. Press Menu button. How to set image adjustment Picture Menu items appear on the screen. in PC mode 2. Press ↲ button to select "Picture" Icon. (Supported only in PC mode) Auto Adjust  Phase "Picture Mode" is highlighted. H-Posilion 3.
  • Page 29 DIGITAL SIGNAGE User can eliminate noises on the screen in AV/Component mode.(Not supported in PC/HDMI mode) How to Set Noise 1. Press Menu button. Reduction(NR) Picture Menu items appear on the screen. Picture Mode 2. Press ↲ button to select "Picture" Icon. Custom ...
  • Page 30 DIGITAL SIGNAGE Users can adjust sound mode automatically as they want. How to Select the Audio 1. Press Menu button. Menu items appear on the screen. Mode Sound 2. Press ▲ / ▼ buttons to move to “Sound” Icon. 3. Press ↲ button to select “Sound” Icon. “Mode” is Mode Custom Volume...
  • Page 31 DIGITAL SIGNAGE Users can adjust sound mode automatically as they want. How to Adjust the Desired Audio Mode Sound Sound Mode Custom 10KHz Volume 3KHz Balance L50 R50 Equalizer  1KHz Auto Volume 300Hz Sound Mode Stereo 100Hz HDMI Sound ...
  • Page 32 DIGITAL SIGNAGE How to Select Auto Volume This function will automatically give a similar volume size to each channel. 1. Press Menu button. Sound Menu items appear on the screen. Mode 2. Press ▲ / ▼ buttons to move to "Sound" Icon. Volume 3.
  • Page 33 DIGITAL SIGNAGE How to Select HDMI Sound 1. Press Menu button. Sound Menu items appear on the screen. Mode 2. Press ↲ button to select “Sound” Icon. Volume “Mode” is highlighted. Balance 3. Press ▲ / ▼ buttons to move to “HDMI Sound”. Equalizer ...
  • Page 34 DIGITAL SIGNAGE How to Reset Setup 1. Press Menu button. Menu items appear on the screen. Reset  2. Press ↲ button to select "Setup" Icon. Time  "Reset" is highlighted. Language 3. Press ▶ or ↲ buttons to select to "Reset". OSD Tone Key Lock 4.
  • Page 35 DIGITAL SIGNAGE <Go to step 6 if you need to set the "On or Off Timer"> Time 6. Press ▲ / ▼ buttons to move to "On or Off Timer". Clock 05 : 00 7. Press ▶ or ↲ buttons to select "On or Off Timer" . On Timer 00 : 00 8.
  • Page 36 DIGITAL SIGNAGE How to set OSD tone 1. Press Menu button. Setup Menu items appear on the screen. Reset  2. Press ↲ button to select "Setup" Icon. Time  "Reset" is highlighted. Language 3. Press ▲ / ▼ buttons to move to "OSD Tone" OSD Tone 4.
  • Page 37 DIGITAL SIGNAGE How to select DCR 1. Press Menu button. Setup Menu items appear on the screen. Reset  2. Press ▲ / ▼ button to move to “Setup” Icon. Time  3. Press ↲ button to select "Setup" Icon. Language "Reset"...
  • Page 38 DIGITAL SIGNAGE How to Set the Multi Multi Multi Function Multi Function  H Set CounL Heal Control  V Set CounL Display Sequence H Edge ADJ V Edge ADJ SET ID Master     U Move Menu U Move Menu Enter...
  • Page 39 DIGITAL SIGNAGE Set up Value installation item Product 1 Product 2 Product 3 Product 4 Product 5 Product 6 H Set Count V Set Count Display Sequence H Edge ADJ / These are the set up value to make up the un-displayed area of Bezel Part. V Edge ADJ It can be adjustable according to the contents It is necessary to control via RS232 communication port on PC.
  • Page 40 DIGITAL SIGNAGE To connect multiple monitors HDMI Cable to the PC in HDMI mode DVI-IN DVI-OUT DVI-IN DVI-OUT DVI-IN DVI-OUT DVI-HDMI Cable (not included) Product 1 Product 2 Product 3 To connect multiple monitors to the PC in RGB mode D-SUB Cable PC-IN PC-OUT...
  • Page 41 DIGITAL SIGNAGE To connect multiple monitors to the PC in Component mode Component Cable COMPONENT-IN COMPONENT-IN COMPONENT-IN CVBS-IN CVBS-IN CVBS-IN (not included) COMPONENT-OUT COMPONENT-OUT COMPONENT-OUT CVBS-OUT CVBS-OUT CVBS-OUT Product 1 Product 2 Product 3 To connect multiple monitors to the Video in AV mode COMPONENT AUDIO-IN COMPONENT AUDIO-IN COMPONENT AUDIO-IN...
  • Page 42 DIGITAL SIGNAGE How to Set the Heat "Heat control" allows you set up fan operation according to interior temperture of the product Control Multi Multi Multi Function  Fan Control Auto 38 °C Heal Control  Fan Active Temp 5 °C Hysteresis 32 °C Current Temp...

  • Page 43: Diagnosis

    DIGITAL SIGNAGE Diagnosis When the product is not working properly, please check before you call customer center. Symptoms How to solve the problem It happens not to show the screen noise when the power is on. Therefore it is not a Screen displays late defect.
  • Page 44 DIGITAL SIGNAGE Symptoms How to solve the problem The screen displays check the volume up and down with remote control and audio connection cable without the sound. No sound from either Confirm the status of the sound balance on OSD menu and check the connection right speaker or left of speaker cable.

  • Page 45: Specifications

    DIGITAL SIGNAGE Specifications 1366 x 768 Pixel (HD) Model List - D320ML(I/G) D320ML(I/G) : 697.7 x 392.3 Screen size (HxV/mm) D462FL D462FL / D466ML / D468FL : 1018.4 x 572.5 D466ML D468FL Recommended resolution 1366 x 768 @60Hz Digital RGB, Analog RGB, Component(Option), Video(Option), PC Audio L/R, Input Component Audio L/R(Option), Composite Audio L/R(Option), RS232C Digital RGB, Analog RGB, Component(Option), Video(Option),...
  • Page 46 DIGITAL SIGNAGE Specifications 1920 x 1080 Pixel (Full HD) D405ML(I/G) / D407ML(I/G/P/T) : 885.6 x 498.2 Model List D425ML(I/G/P/T) : 930.25 x 523 - D405ML(I/G) D465ML(I/G) / D467ML(I/G/P/T) : 1018.1 x 572.7 D407ML(I/G/P/T) D471ML(I/G/T) : 1039.7 x 584.8 Screen size (HxV/mm) D523ML(I/G) / D525ML(I/G) : 1152.00 x 684.00 D425ML(I/G/P/T) D557ML(I/G/T) : 1209.6 x 680.4...
  • Page 47 DIGITAL SIGNAGE Specifications 1920 x 1080 Pixel (Full HD) Model List D465SL(I/G) / D467SL(I/G) : 1018.1 x 572.7 - D465SL(I/G) Screen size (HxV/mm) D525SL(I/G) : 1152.0 x 648.0 D467SL(I/G) D525SL(I/G) D705SL(I/G) : 1549.4 x 871.6 D705SL(I/G) Recommended resolution 1920 x 1080 @ 60Hz Digital RGB, Analog RGB, Component(Option), Video(Option), PC Audio L/R, Input Component Audio L/R(Option), Composite Audio L/R(Option), RS232C...
  • Page 48 < REMOTE CONTROL SPEC > 1. REMOTE CONTROL WAVE FORM 2. REMOTE CONTROL KEY CODE TABLE 1) Remote Control System Infrared rey system Custom Code : 7788H fosc=455KHZ fc=fosc/2=37.917KHZ DATA 2) Signal code POWER 0x80 MENU 0x95 • Transmission EXIT 0x96 - One pulse SOURCE...
  • Page 49 < RS232C COMMAND SPEC > 1. CONFIGRATION Example. 1 To power on Set ID No 1 1) SPEED : 9600 Baud/s, 8 bit, No parity, 1 Stop bit. 2) Cable Connetion Item HEADER SET ID COMMAND askii did: hexa 0x64 0x69 0x64 0x3A 0x30 0x31 0x2D 0x70 0x6E 0x2E...
  • Page 50 Item Command Description hexa Item Command Description hexa factory reset picture mode custom 0x70 0x6D 0x63 0x66 0x72 factory option view picture mode high 0x70 0x6D 0x68 “lp:?, am:?, av:?, si:?, pwm:?, mot:?.” picture mode middle 0x70 0x6D 0x68 0x66 0x6F - last power, aging, av enable, source, pwm, motion picture mode low...
  • Page 51 Item Command Description hexa Item Command Description hexa picture size center 0x70 0x63 left 0x6A picture size wide 0x70 0x77 right 0x6B osd tone off 0x6F 0x74 0x66 enter 0x65 Picture osd tone on 0x6F 0x74 0x6E menu 0x6D Option auto adjust 0x61 0x74 exit...
