Sennheiser SKM 300-865 G3 Quick Manual

Sennheiser SKM 300-865 G3 Quick Manual

Handheld vocal radio microphone
Hide thumbs Also See for SKM 300-865 G3:
1
2
3
4
5
6

Advertisement

Table of Contents

SKM 300-835 G3
SKM 300-845 G3
SKM 300-865 G3
FEATURES
Sturdy metal housing

42 MHz bandwidth: 1680 tunable UHF

frequencies for interference-free reception
Enhanced frequency bank system with up

to 24 compatible frequencies
Pilot tone squelch for eliminating RF inter-

ference when transmitter is turned off
Enhanced AF frequency range

Increased range for audio sensitivity

Wireless synchronization via infrared

interface from receiver
User-friendly menu operation with more

control options
Illuminated graphic display

Auto-Lock function avoids accidental

changing of settings
HDX compander for crystal-clear sound

Battery indication in 4 steps, also shown

on receiver display
Programmable Mute button

Easy-exchangeable microphone modules

from evolution series
Contacts for recharging BA 2015 accupack

directly in the transmitter
Wide range of accessories adapts the

system to any requirement
Optimized PLL synthesizer and micro-

processor technology
Increased immunity to intermodulation

and interferences in multi-channel ope-
ration
Extended muting function due to MIC

button on the radio microphone
Handheld vocal radio microphone
SKM 300-835 G3
The
such as a convenient menu interface, vivid graphic display, and programmable
mute button. You can program the mute button to support push-to-talk, push-
to-mute, and more if you choose.
Designed for absolute reliability and
impressive sound, this handheld
transmitter/microphone combina-
tion makes it easy to concentrate
on what is important: your own
performance.
SKM 300-845 G3
The microphone capsule of this handheld transmitter/microphone combination is
based on Sennheiser's successful evolution 800 series. Power and presence meet
control as the super-cardioid capsule
rejects feedback while providing a
rich and detailed reproduction of the
voice. A programmable mute button
silences the microphone when
needed or can aslso be set to act as
a push-to-talk mode.
SKM 300-865 G3
This handheld transmitter/microphone combination provides the user with a tool
that is both powerful and sensitive
at the same time. Elite condenser
technology reproduces vocal nuan-
ces reliably and precisely. The super-
cardioid characteristic guarantees
the least possible feedback. Finally,
the programmable mute button
offers the valuable option of silence
when it is needed.
gives you both power and control with new features

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKM 300-865 G3 and is the answer not in the manual?

Questions and answers

Related Manuals for Sennheiser SKM 300-865 G3

Summary of Contents for Sennheiser SKM 300-865 G3

  • Page 1 Auto-Lock function avoids accidental The microphone capsule of this handheld transmitter/microphone combination is changing of settings based on Sennheiser‘s successful evolution 800 series. Power and presence meet HDX compander for crystal-clear sound control as the super-cardioid capsule Battery indication in 4 steps, also shown...

  • Page 2: Technical Data

    SKM 300-835 G3, SKM 300-845 G3, SKM 300-865 G3 Handheld vocal radio microphone ARCHITECT’S TECHNICAL DATA SPECIFICATIONS Modulation ...............wideband FM Frequency ranges............ 516 – 558, 566 – 608, 626 – 668, The handheld vocal radio microphone shall 734 –776, 780 – 822, 823 – 865 MHz be for use with a companion receiver as Transmission frequencies ........
  • Page 3 SKM 300-835 G3, SKM 300-845 G3, SKM 300-865 G3 Handheld vocal radio microphone ARCHITECT’S TECHNICAL DATA SPECIFICATIONS SKM 300-845 G3 Transducer / microphone type ......dynamic Power shall be supplied to the radio micro- AF sensitivity ............1,6 mV/Pa phone by two 1.5V AA size batteries or by Sound pressure level (SPL) ........154 dB(SPL) max.

  • Page 4: Frequency Response And Polar Pattern

    SKM 300-835 G3, SKM 300-845 G3, SKM 300-865 G3 Handheld vocal radio microphone DIMENSIONS FREQUENCY RESPONSE AND POLAR PATTERN SKM 100-835 G3 SKM 100-845 G3 ° ° 30° 30° 30° 30° - 40 - 40 - 50 - 50 60°...

  • Page 5: Product Variants

    SKM 300-835 G3, SKM 300-845 G3, SKM 300-865 G3 Handheld vocal radio microphone PRODUCT VARIANTS SKM 300-865 G3-B – Frequency range 626...668 MHz Cat. No. 503630 SKM 300-835 G3 SKM 300-865 G3-C – SKM 300-835 G3-A – Frequency range 734...776 MHz Cat.
  • Page 6 SKM 300-835 G3, SKM 300-845 G3, SKM 300-865 G3 Handheld vocal radio microphone RECOMMENDED ACCESSORIES MZW 1 – wind and pop shield Cat. No. 004839 MZQ – 1 microphone clamp Cat. No. 002155 MMK 965-1 NI – e965 switchable condenser...
