Yaesu FTDX5000 - SOFTWARE UPDATE AND VERSION IDENTIFICATION Software Update

Software update and version identification
Hide thumbs
Table of Contents

Advertisement

Quick Links

12/17/10
FT
5000 Software Update and Version
DX
There are four different Software installations. Each one must be followed carefully. Installing the
wrong type software may cause difficulties. Check your radio before installing software to be sure
which updates are needed.
If multiple software installations are required the MAIN software should be installed first, as it is the
only one that requires a hard reset (FAST+LOCK).
The latest versions are listed below with the release dates.
MAIN Software Version 0111 (7/28/10)
Edsp Software Version 0529 (12/17/10)
DMU-2000 Software Version (Option): Please refer to the DMU-2000 update information on our
website.
EDSP-5000 Programming Writer Version 1.07 (7/09/10)
Implements improvements
Main： Ver. 0111 (7/28/10)
Corrected the STBY output delay when using the DIN connector for an external amplifier.
EDSP： Ver. 0529 (12/17/10)
Correct the lock up problem when setting the RX DSP Filter to "SOFT" and the manual Notch
Filter to ON at the same time. (Default setting is "SHARP")
EDSP-5000： Ver. 1.07 (7/09/10)
Extended writer time out.
We recommend: if you have any previous EDSP 5000 programming writer on your computer, that
you delete this before using the EDSP-5000： Ver. 1.07. Always use the latest version writer.
Identification

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FTDX5000 - SOFTWARE UPDATE AND VERSION IDENTIFICATION and is the answer not in the manual?

Questions and answers

Related Manuals for Yaesu FTDX5000 - SOFTWARE UPDATE AND VERSION IDENTIFICATION

Summary of Contents for Yaesu FTDX5000 - SOFTWARE UPDATE AND VERSION IDENTIFICATION

  • Page 1 12/17/10 5000 Software Update and Version Identification There are four different Software installations. Each one must be followed carefully. Installing the wrong type software may cause difficulties. Check your radio before installing software to be sure which updates are needed. If multiple software installations are required the MAIN software should be installed first, as it is the only one that requires a hard reset (FAST+LOCK).
  • Page 2 The software versions can be displayed on the radio While holding the three buttons [GEN]＋[50]＋[ENT] turn the radio on. The software version will be displayed See Fig. 1 and 2. Fig. 1 Fig. 2 ・ MAIN Software Version The version number will be shown on the VFD CLAR (Clarifier) display. See Fig. 2 and 3 (example MAIN software version V0106)．...
  • Page 3 ・ EDSP Software Version The version number will be shown on the VFD MAIN Frequency display. See Fig. 2 and 3 (example EDSP software version MAIN: V0510 and SUB V0510)． Fig. 3 ・ OEL (OLED) Software Version The version number will be shown on the CLAR/VFO-B DIAL display (Left side). See Fig. 2 and 4 (example OEL software version V0110).
  • Page 4 Install the data file to PC [The following procedures are provided to update the data file from the Yaesu website] 1. Download the FT 5000 data file [FTdx5000 12-17-10.zip] from the following website: http://www.yaesu.com/indexVS.cfm?cmd=DisplayProducts&ProdCatID=102&encProdID=12FF 98B9C73C8988F2398C979793E2E1&DivisionID=65&isArchived=0 2. Save the FT 5000 data file [FTdx5000 12-17-10.zip] to the desktop on your computer.
  • Page 5 MAIN Software Update ・ MAIN CPU Software Version *Don't forget to write down (or save to a CF Card) any personal menu settings you have changed from the default before you start. Please see the DMU-2000 Data Management Operation Manual for the procedure to save your settings to a CF card.
  • Page 6 6. When the program opens, confirm that the file AH036_V0111.SFL is highlighted; if not, click on it to highlight it. 7. Click "Configure" if necessary, to change the COM Port. 8. Click WRITE. The onscreen progress bar will indicate programming activity. 9.
  • Page 7 NOTE: The below instructions are for installing each software individually. If you are sequentially installing more than one software EDSP, OLED and SM-5000 LCD type, it is not necessary to turn off the rear panel Main power switch or disconnect the AC and programming cables until all of the software is installed.
  • Page 8 NOTE: If you receive a “Communications Error” message on your screen you should check the COM port number and speed under Device Manager. The writing speed 38.4kbps is fixed in the download algorithm of the EDSP board so you may need to set the port speed close to 38.4kbps.
  • Page 9 6. When the program opens, confirm that the file AH036UEL_V0110.SFL is highlighted; if not, click on it to highlight it. 7. Click "Configure" if necessary, to change the COM Port. 8. Click WRITE. The onscreen progress bar will indicate programming activity. 9.
  • Page 10 The new software version will be displayed See Fig. 2. We hope this new software will increase your enjoyment of your FT 5000. Thank you for choosing Yaesu radios. If you have any problems or questions please contact Vertex Standard, Amateur Tech Support. amateurtech@vxstdusa.com...
