Owners &
Freestanding Woodstoves
Installation Manual
Medium Freestanding Woodstove
with optional Gold Legs.
Medium Freestanding Step Stove
with Pedestal Base.
MODELS:
F1100S
F2100M
F3100L
S2100M
S3100L
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
908-288
FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
01/13/03
