Simrad PI DEPTH - DATASHEET REV A Datasheet page 2

The PI Depth sensor provides information
about the current depth and the depth
changes of your gear.
• Bottom trawl: On a bottom trawl, you will use the
sensor to achieve full control when shooting, and
to position the trawl on the slope.
• Pelagic trawl: During pelagic trawling, you know
how important it is to position the trawl relative to
the largest concentration of fish. By using a Depth
sensor, you can monitor the exact depth relative to
the surface, and adjust the trawl depth accordingly.
Additional depth sensors on the doors will monitor
if the doors stay at the same depth.
• Purse seine: During seining, use the Depth sensor
to monitor the depth of the net, and the descending
speed of the net. Then you will know when to start
pursing, and which speed to use.
PI Systems: PI32, PI44 or PI54
Update rates:
• Fast: Every 4,5 second (approx.)
• Normal: Every 14 second (approx.)
• Slow: Every 34 second (approx.)
Default update rate: Fast
Lifetime between each recharge:
• Fast update rate: 24 hours
• Normal update rate: 75 hours
• Slow update rate: 100 hours
Communication frequency range: 43,5 to 49,5 kHz
Accuracy: 1% of total range
Simrad Horten AS
Strandpromenaden 50
P.O.Box 111
NO-3191 Horten
Norway
Telephone: +47 33 03 40 00
Facsimile: +47 33 04 29 87
M A X I M I Z I N G
Applications
Specifications
Y O U R P E R F O R M A N C E
• Danish seine: Mounted on a Danish Seine the
Depth sensor monitors the sinking speed of the net,
and it will tell you when to start hauling once the
net has stopped sinking.
Depth ranges: 100 m, 300 m and 1000 m
Physical properties:
• Length: 246 mm
• Width: 171 mm
• Thickness: 123 mm
• Weight in air: 4,3 kg
Charging time with PI Charger:
• To 70% capacity: 1 hour
• To 100% capacity: 4 hours
Charging time with PS Charger:
• To 100% capacity: 16 hours
Specifications can be altered without prior notification.
www.simrad.com
A T S E A
(855-165192 / Rev.A / April 2005)
