– Insert the shoulder strap through the locking
mechanism and tension (Figure 5.3). Close flap.
Important:
Check once again that the belt is correctly
inserted in the guides as indicated (Figure
5.4). Otherwise the safe functioning of the
child seat cannot be guaranteed.
The vehicle seat belt must be pulled taut and
must not be twisted. The lap and shoulder belts
must not be confused.

6. Changing the cover and instructions for care

To change the cover (see step-by-step guide on rear
GB
flap of the instructions for use):
In order to change the cover, first remove the shoulder
straps (Fig. 6.1 and Section 4). Undo the clasp (Fig.
6.2). Release the cover at the front of the adjustment
mechanism (Fig. 6.3). Slide off the padding on the
belt and clasp (Figs. 6.4 and 6.5). Lift out the
polystyrene tray liner and loosen the Velcro fastener
on each of the crotch belts (Fig. 6.6). Pull cover off
forwards and simultaneously push the clasp and the
two straps down through the slits in the cover (Fig.
6.7 and 6.8).
Reverse these steps to replace the cover:
Pull on cover and insert straps and clasp through the
slits in the cover (Figs. 6.8 and 6.7). Close the Velcro
fastener (Fig. 6.6). Position the polystyrene tray liner
in the shell of the seat, tighten the crotch belts and
replace the belt padding (Fig. 6.5 and 6.4). Attach
cover to adjustment mechanism (Fig. 6.3) and
reposition the shoulder straps at the correct height
(Fig. 6.1 and Section 4). Check that the straps have
been mounted correctly (Section 4 and Fig. 6.9).
Care instructions: The cover may be washed on a
gentle cycle at 30°C. For details, refer to the washing
label on the cover. The cover fabrics can easily fade
when they come into contact with moisture, especially
during washing. Do not use solvents!
30°

7. Sun shade (accessories)

The sun shade is clipped onto the two side lugs
(Figure 7). The child seat may also be placed on a
Concord buggy and locked into position. It can be
released again by pressing the locking button on the
carrying handle.
8. Important information, Note!
Please note the instructions in the car's operating
manual for transporting children in a car.
Information on the use of child seats together
with an airbag should be observed with particular
care.
Children sometimes have items in their jacket or
trouser pockets (e.g. toy) or wear hard items that are
attached to their clothes (e.g. belt buckle). Check that
these items do not get between the child and the
safety belt – they could cause unnecessary injuries
in the event of an accident. These hazards also apply
to adults!
Naturally children can often be very lively. You should
therefore explain to children how important it is to
always be safely fastened in. Children must understand
that they should never change the way the belts are
positioned, and never open the buckle.
Only if safety equipment is correctly installed and
used can your child enjoy maximum safety.
All straps in the child restraint system and all belts
required for securing the seat in the car must be fitted
tautly and without twists, and must be protected
against damage.
0696-02
