Loading the Batteries

The Concord Eye-Q ™ Duo uses 2 alkaline AA batteries.
Loading the batteries:
1. Locate the battery cover on the bottom of the
camera.
2. Slide the button on the battery cover toward
the center of the camera. (fig.1)
3. Lift the cover to open.
4. Insert the batteries with the positive terminal
toward the + sign, and the negative terminal
toward the – sign. (fig.1.1)
5. Close the cover.
Note: Remove the batteries from the Concord Eye-Q™ Duo if the
camera will not be used for an extended period of time to
prevent corrosion or battery leaks.
Checking the Batteries
The camera has a battery indicator that shows the current battery
level.
FULL
Battery has full
power and is
ready to use.
Do not attempt to use the camera once the "Empty" battery
indicator appears in the display. Replace the batteries immediately.
LOW
Battery has low
power and will
need to be
replaced soon.
7
fig.1
fig.1.1
EMPTY
Battery has very
little power and
must be replaced.
