MultiSync LCD2690WUXi
User's Manual

Advertisement

loading

  Also See for NEC LCD2690WUXI2-BK - MultiSync - 26" LCD Monitor

  Related Manuals for NEC LCD2690WUXI2-BK - MultiSync - 26" LCD Monitor

  Summary of Contents for NEC LCD2690WUXI2-BK - MultiSync - 26" LCD Monitor

  • Page 1 MultiSync LCD2690WUXi User’s Manual...
  • Page 2: Table Of Contents

    Index Warning, Caution ........................English-1 Declaration ..........................English-1 Canadian Department of Communications Compliance Statement ........... English-2 Declaration of Conformity ......................English-2 Contents ............................English-3 Quick Start ..........................English-4 Controls ............................English-8 Recommended use ........................English-13 Specifications ..........................English-15 Features ............................English-16 Troubleshooting ...........................
  • Page 3: Declaration

    U.S. registered trademark. NERGY ErgoDesign is a registered trademark of NEC Display Solutions, Ltd. in Austria, Benelux, Denmark, France, Germany, Italy, Norway, Spain, Sweden, U.K. All other brands and product names are trademarks or registered trademarks of their respective owners.
  • Page 4: Canadian Department Of Communications Compliance Statement

    This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. U.S. Responsible Party: NEC Display Solutions of America, Inc. Address: 500 Park Blvd, Suite 1100 Itasca, Illinois 60143 Tel.
  • Page 5: Contents

    Contents Your new NEC monitor box* should contain the following: • MultiSync LCD2690WUXi2 monitor with tilt/swivel/pivot/height adjust stand • Power Cord • Video Signal Cable (15-pin mini D-SUB male to DVI-A) • Video Signal Cable (DVI-D to DVI-D cable) •...
  • Page 6: Quick Start

    Please check Tilt, Rise and Lower monitor screen and screen rotation when you manage cables. 30˚ Tilt Highest Stand Position Power cord DVI-I DVI-D DC-OUT D-SUB Figure C.2 Figure C.1 NEC optional product attachment. Do not use this connector unless specified. English-4...
  • Page 7 Figure C.4 Figure C.3 7. Hold all cables firmly and place the cable cover onto the stand (Figure D.1). To remove the cable cover, lift the cover off as shown in Figure D.2. 8. Connect one end of the power cord to the AC inlet on the back of the monitor and the other end to the power outlet. NOTE: Please refer to Caution section of this manual for proper selection of AC power cord.
  • Page 8: Raise And Lower Monitor Screen

    Raise and Lower Monitor Screen The monitor may be raised or lowered in either Portrait or Landscape mode. To raise or lower screen, place hands on each side of the monitor and lift or lower to the desired height (Figure RL.1). NOTE: Handle with care when raising or lowering the monitor screen.
  • Page 9: Remove Monitor Stand For Mounting

    Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1. Disconnect all cables. 2. Place hands on each side of the monitor and lift up to the highest position. 3. Place monitor face down on a non-abrasive surface (Figure S.1). Figure S.1 4.
  • Page 10: Controls

    Controls OSD (On-Screen Display) control buttons on the front of the monitor function as follows: To access OSD menu, press the MENU button. To change signal input, press the SELECT button. NOTE: OSD must be closed in order to change signal input. Landscape Portrait 1 AMBIBRIGHT SENSOR...
  • Page 11: Eco Mode

    Brightness/Contrast Controls BRIGHTNESS Adjusts the overall image and background screen brightness. NOTE: When PROGRAMMBLE is set by PICTURE MODE (Page 26), you cannot select BRIGHTNESS. CONTRAST Adjusts the image brightness in relation to the background. AUTO CONTRAST (Analog input only) Adjusts the image displayed for non-standard video inputs.
  • Page 12: Color Control Systems

    FINE (Analog input only) Improves focus, clarity and image stability by increasing or decreasing this setting. If the “Auto Adjust function” and the “H.Size” function do not give you a satisfactory picture setting, a fine tuning can be performed using the “Fine” function. For this a Moiré...
  • Page 13: Off Timer

    EDID EXTENSION (Digital Input Only) Selects the type of input to be used with EDID EXTENSION. NORMAL: When a PC or other computer equipment is connected, select “NORMAL”. ENHANCED: When a DVD player or other type of high definition device is connected, select “ENHANCED”. NOTE: Interlaced signals (480i, 576i, 1080i) are not supported.
  • Page 14: Osd Transparency

    OSD LOCK OUT This control completely locks out access to all OSD control functions. When attempting to activate OSD controls while in the Lock Out mode, a screen will appear indicating the OSD controls are locked out. There are four types of OSD LOCK OUT: OSD LOCK OUT with BRIGHTNESS and CONTRAST control: To activate the OSD Lock Out function, press SELECT, then “UP”...
  • Page 15: Recommended Use

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 16 CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: • For optimum performance, allow 20 minutes for warm-up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.
  • Page 17: Specifications

    60 Hz (Digital) 1680 x 1050* at 60 Hz to 75 Hz (Analog), 1680 x 1050* at 60 Hz (Digital) 1920 x 1200 at 60 Hz........NEC DISPLAY SOLUTIONS cites 1024 x 1280* at 60 Hz recommended resolution for optimal...
  • Page 18: Features

    Allows for the monitor to be mounted on a wall or an arm using any third party compliant device. Visual Controller: Is a ground-breaking software family, developed by NEC Display Solutions Europe GmbH, providing intuitive access to all monitor setting controls and remote diagnosis via the Windows interface, based upon the VESA standard, DDC/CI. Using a standard VGA or DVI signal cable, Visual Controller can either benefit single users or, with Visual Controller Administrator, can reduce the Total Cost of Ownership through remote network-wide maintenance, diagnosis and asset-reporting.
  • Page 19: Troubleshooting

    NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 20: Appendix

    Appendix If you need detailed information about the controls, please use the advanced menu. <How to use the advanced menu> • Turn off your monitor. • Turn on your monitor by pushing the “POWER” and “INPUT/SELECT” button at the same time for at least one second simultaneously.
  • Page 21 Tag2 R-H.position Adjusts the position of the red component of the image. Press “Left” or “Right” to adjust. (Analog input only) G-H.position Adjusts the position of the green component of the image. Press “Left” or “Right” to adjust. (Analog input only) B-H.position Adjusts the position of the blue component of the image.
  • Page 22 H. Size Adjusts the horizontal size of the screen. (Analog input only) If the “AUTO Adjust function” do not give you a satisfactory picture setting, a further tuning can be performed using the “H.Size (V.Size)” function (dot clock). For this a Moiré test pattern could be used.
  • Page 23 Tag6 Color Control Color Control Systems: Seven preset color settings. For preset settings 1, 2, 3 and 5, the following levels can be adjusted: TEMPERATURE: Adjust the white temperature by increasing or decreasing this setting. A lower color temperature will make the screen reddish and a higher color temperature will make the screen bluish.
  • Page 24 “Tag window frame color”, “Item select color” & ”Adjust Window frame color” can be changed. BOOT LOGO The NEC logo is briefly displayed after the monitor is powered on. This feature can be turned on or off in the OSD.
  • Page 25 Signal Information Signal information can be displayed in the corner of the screen. Signal information is either “On/Off”. Resolution Notifier The optimal resolution is 1920 x 1200. If ON is selected, a message will appear on the screen after 30 seconds, notifying you that the resolution is not set to 1920 x 1200. Press “Left”...
  • Page 26 TagA Tile Matrix The Tile Matrix feature allows one image to be displayed over multiple screens. This feature can be used with up to 25 monitors (5 vertical and 5 horizontal). Using Tile Matrix requires the PC output signal be sent through a distribution amplifier to each individual monitor.
  • Page 27: Using The Auto Brightness Function

    Using the Auto Brightness function The brightness of the LCD screen can be set to increase or decrease depending on the amount of ambient light within the room. If the room is bright, the monitor becomes correspondingly bright. If the room is dim, then the monitor will dim accordingly.
  • Page 28: Using The Picture Mode Function

    Using the PICTURE MODE function Choose the Picture mode that is most suitable for the type of content that is shown. ® There are five types of mode (STANDARD, sRGB, PROGRAMMABLE, Adobe RGB and MEDICAL). • To access the Picture mode, press Reset button while OSD menu is not showing. •...
  • Page 29: Tco'03

    TCO’03 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
  • Page 30: Manufacturer's Recycling And Energy Information

    Manufacturer’s Recycling and Energy Information NEC DISPLAY SOLUTIONS is strongly committed to environmental protection and sees recycling as one of the company’s top priorities in trying to minimize the burden placed on the environment. We are engaged in developing environmentally- friendly products, and always strive to help define and comply with the latest independent standards from agencies such as ISO (International Organisation for Standardization) and TCO (Swedish Trades Union).
