| SPECTRAVIEW II - USER'S GUIDE
4
Using SpectraView
Launching
(Mac OS)
Double click the SpectraView II application
icon in the Applications folder.
As SpectraView launches, it will automatically search for any supported displays, and a supported color sensor.
If SpectraView is unable to detect either a supported display or the last selected color sensor, an error message will
be displayed and the Calibrate button will be disabled. Refer to the Troubleshooting section of this manual.
Selecting a calibration Target
A Target specifies the color characteristics of the display for the calibration process. A Target can be either predefined,
or custom defined.
Existing Targets can be selected in the main SpectraView II window from the Target listbox.
Selecting a Target will automatically configure the White Point, Tone Response Curves, Intensity and Black Level
(if applicable).
The choice of Target depends on the particular application and viewing conditions such as the ambient light level.
Modifying Targets
The parameters of Targets can be modified using the Edit Target button which will display the Edit Target dialog.
Note that modifying a Target will require the display monitor to be recalibrated to the new Target parameters.
(Windows)
Select SpectraView II from the NEC Display
Solutions program group on the Windows
Start menu.
