- Page 1 FORD BRONCO SPORT 2021 INSTALLATION INSTRUCTIONS PEERLESS RUNNING BOARD FOR FORD BRONCO SPORT 2021 PART # PR-F1069BK Page 1 of 8...
-
Page 2: Parts List
PREMIUM RUNNING BOARD BRACKETS FOR FORD BRONCO SPORT 2021 PARTS LIST: Driver/Left Running Board 10mm x 60mm Hex Bolts Passenger/Right Running Board 10mm x 27mm OD x 2mm Flat Washers Driver/Left Front Mounting Bracket 10mm Lock Washers Passenger/Right Front Mounting Bracket 10mm Hex Nuts Driver/Left Center Mounting Bracket 10mm Plastic Retainers... - Page 3 PREMIUM RUNNING BOARD BRACKETS FOR FORD BRONCO SPORT 2021 4. Select the Driver/Left Mounting Bracket. Attach the Mounting Bracket to the Bolt Plate with (1) 10mm Flat Washer, (1) 10mm Lock Washer and (1) 10mm Hex Nut, (Figure 10). Do not tighten hardware. Attach the Bracket to the Spiral Bolt with (1) 10mm Flat Washer, (1) 10mm Lock Washer and (1) 10mm Hex Nut, (Figure 11).
- Page 4 PREMIUM RUNNING BOARD BRACKETS FOR FORD BRONCO SPORT 2021 Driver/Left Side Installation Pictured Front (Fig 3) Plastic clip removed from the front location trim (Passenger side shown) Front (Fig 4) Locate the Driver/Left front mounting location (Fig 5) Insert the tail on the Spiral Bolt into the slot, keeping the threads pointed outwards (Fig 6) Insert the bend on the tail into the slot, keeping the threads pointed outwards...
- Page 5 PREMIUM RUNNING BOARD BRACKETS FOR FORD BRONCO SPORT 2021 Front Follow link for 10mm (Fig 8B) Spiral Bolt installation. https://youtu.be/BqQis3QjZNc (Fig 8A) Insert (1) 10mm Spiral Bolt into the side panel Front (Fig 9) Insert (1) 10mm Short Front Bolt Plate into the floor panel 10mm Short Bolt Plate 10mm Plastic Retainer 10mm Flat Washer...
- Page 6 PREMIUM RUNNING BOARD BRACKETS FOR FORD BRONCO SPORT 2021 Driver/Left Side Installation Pictured 10mm Spiral Bolt 10mm Flat Washer 10mm Lock Washer 10mm Hex Nut (Fig 11) Attach (1) Driver/Left Front/Rear Support Bracket to the Spiral Bolt Front (Fig 12) Insert (2) 10mm Spiral Bolts into the outer center location Page 6 of 8...
- Page 7 PREMIUM RUNNING BOARD BRACKETS FOR FORD BRONCO SPORT 2021 Driver/Left Side Installation Pictured (2) 10mm Spiral Bolts (2) 10mm Flat Washers (2) 10mm Lock Washers (2) 10mm Hex Nuts Front Front (Fig 13) (2) 10mm Spiral Bolts inserted into the outer center location (2) 8mm Hex Bolts (4) 8mm Flat Washers (2) 8mm Lock Washers...
- Page 8 PREMIUM RUNNING BOARD BRACKETS FOR FORD BRONCO SPORT 2021 Driver/Left Side Installation Pictured Rear 10mm Spiral Bolt 10mm Long Bolt Plate Rear (Fig 17) Example of the rear location (Passenger side shown) (Fig 18) Insert (1) 10mm Spiral Bolt 10mm Spiral Bolt into the side panel and (1) 10mm 10mm Flat Washer Long Bolt Plate into the floor panel...
