Icy Dock MB901SPR-B R1 Manual

Fatcage raid/tougharmor raid

Advertisement

Quick Links

FatCage RAID/ToughArmor RAID
2 Bay 2.5" / 3.5" SATA SSD / HDD RAID Backplane Cage for 2 x 5.25" Bay
Rugged 2 Bay 2.5" SATA SSD / HDD RAID Mobile Rack for 5.25" Bay
Copyright © ICY DOCK International. All Rights Reserved. 650302 VER 1.0
1
Package Contents
包装について
MB901SPR-B R1
Device
MB902SPR-B R1
2
Device Information
Información del dispositivo
MB901SPR-B R1
Front View
6
Drive Tray Ejection Button
Rear View
15 Pin Power
MB902SPR-B R1
Front View
6
Rear View
RAID 1 Status LED Indicator
1
LED Status
Solid green
LED off
Rebuilding Progress LED Indicator
2
LED Status
Flashing green
Solid green
LED Off
3
HDD Fail LED Indicator
LED Status
Solid red x 1
Solid red x 2
4
Double Source LED Indicator
There are two source disks in the device. Replace one with a formatted or brand
-new drive.
LED Status
Solid red
5
Capacity Error LED Indicator
The capacity of the target drive you insert is smaller than the source drive in the
device and causes rebuilding failure. Therefore, please use a drive that has the
same or larger capacity than the source drive.
LED Status
Solid red
6
Drive Activity LED Indicator
LED Status
Solid green
Flashing green
Solid red
3
Installation Guide
de instalación
1. Slide the drive tray ejection button to release the drive tray latch. Next, pull the drive tray from the
device.
MB901SPR-B R1
SLIDE
1
2. Place the 2.5" or 3.5" drive in their corresponding positions as shown. Make sure the connector is
facing the rear side of the drive tray. Then use the included screws to secure the drive.
3. Insert the drive tray back into the device and close the drive tray latch to complete the drive installation.
3. Insert the drive tray back into the device and close the drive tray latch to complete the drive installation.
MB901SPR-B R1
MB901SPR-B R1
4
4
Device Installation
Device Installation
Instalación del dispositivo
Instalación del dispositivo
设备安裝步驟
设备安裝步驟
1. Secure the device into the 2 x external 5.25" bay by using included 8 x M3*6 screws.
1. Secure the device into the 2 x external 5.25" bay by using included 8 x M3*6 screws.
2. Connect the 2 x 15 Pin power cable and 1 x 7 Pin SATA cable to the device to finish the
2. Connect the 2 x 15 Pin power cable and 1 x 7 Pin SATA cable to the device to finish the
device installation.
device installation.
1. Secure the device into the external 5.25" bay by using included 8 x M3*2.5 screws.
2. Connect the 1 x 15 Pin power cable and 1 x 7 Pin SATA cable to the device to finish the
device installation.
5
RAID mode
RAID模式
1. To do the initial setup, make sure the system is powered off and use the RAID mode switch to select
the desired mode and power the system to complete the configuration.
RAID1(SAFE)
The two physical drives are "mirrored" so that one
single logical volume mounts on the desktop. All of the
data on one drive will be recoverable from the other
drive (the available capacity of one drive cannot
exceed the available capacity of the other drive).
Note : In case both drives fail at the same time, it
is recommended to backup any stored data onto
another HDD periodically for extra security.
Note :
1. Setting up JBOD/RAID 1 array or switching between the RAID modes will erase any data
stored in the drives. Be sure to backup the data before the operation.
2. To erase the RAID index previously created - Power off the system, switch to JBOD
mode, and power on the system to complete the process.
6
Important Info
Información importante
1. It is recommended to use identical brand-new hard drives for the RAID 1 array. If you are using hard
drives that have been used in a RAID before, you must first erase the previous RAID index and
restore the hard drive to factory settings. Otherwise, the RAID array may not function properly due
to the existing RAID index on the hard drives.
2. The RAID array created by this device only works with RAID cages that have the same IC chipset
and firmware version. Moving the drives to the RAID cage that uses a different chipset and firmware
will cause data loss.
3. If the drive access LED does not function properly, but you can access the drive could mean the
drive does not support drive access signals or use non-standard drive signal specifications. Please
get in touch with our support if you believe it is an LED malfunction.
4. It is recommended to use ERC (Error Recovery Control) supported hard drives for the best RAID
performance.
5. If one of the hard drives malfunctions under the RAID 1 mode, the HDD fail indicator light will turn
red and indicate which drive has failed. To start the RAID rebuilding process, simply remove the
failed hard drive from the enclosure and insert a working hard drive with identical specifications
while the enclosure is powered. The HDD fail indicator light should disappear in a few seconds, and
then the rebuilding process will start promptly. The newly inserted drive will become a target drive,
while the remaining hard drive will become a source drive.
6. The RAID cage will perform a data rebuilding verification when swapping one of the hard drives
under RAID 1 mode. The rebuilding verification process takes about ten minutes to verify/rebuild
100GB drive capacity. The processing time may vary depending on the hard drive's specifications.
7. Never replace both of the drives under RAID 1 mode, as doing so will cause the drive
cage to rewrite the RAID table and corrupt the data saved in the RAID array. Note this action is not
reversible and will erase all the data permanently.
8. Please do not use the RAID cage for drive duplication or change the drive orders under RAID 1
mode, as doing so may cause data loss due to misplacing the source and target drives.
9. Removing or changing the hard drive in RAID 1 mode during the rebuilding progress may result in
data loss.
7
RAID Monitoring Software
de surveillance RAID
ソフトウェア ●
The RAID monitoring software supports both Windows and Mac OS. Please visit http://icydock.com
and download the software from the product page, located at Support & Download section :
a. Please ensure the device is installed in the computer and powered , and then double click
to launch the monitoring software.
ICY DOCK HW
RAID Manager
b. The RAID status will display on the main page of the software.
Controller 1
P0: H/W RAID 1
M0: ST3320620A
M1: ST3320620A
Scan the QR code for more product information
Packungsinhalt
包裝說明
User Manual
× 10
Device
× 10
Note : Please use included screws to secure the drive(s)
Geräteinformationen
1
2
RAID 1
25%
50%
75% 100%
OK
Rebuilding
RAID Mode Switch
7 Pin SATA
1
2
RAID 1
25%
50%
75%
100%
OK
Rebuilding
Drive Tray Ejection Button
RAID Mode Switch
RAID 1
JBOD
JBOD / rebuilding / drive Fail / RAID error
RAID is rebuilding. Divided into four stages:
The device is not in rebuilding mode
Indicate a fail drive / target drive's capacity
processing RAID 1 rebuilding (source drive)
processing RAID 1 rebuilding (target drive)
Drive fail / double Source / target drive's capacity
Installationsanleitung
製品の組み込み手順について
2
MB901SPR-B R1
M3*4 Screw
MB902SPR-B R1
Installation eines Gerätes
Installation eines Gerätes
MB901SPR-B R1
MB901SPR-B R1
MB902SPR-B R1
RAID Modi
Mode RAID
RAID模式
I Wichtige Informationen
重要な情報
oftware de seguimiento del RAID
RAID監控軟體
RAID and Disk Information
RAID Level
Status
Capacity
Plugged Member(s)
Disk 1
298.03 GB
Disk 2
298.03 GB
ICY DOCK reserves the right to change product specifications, components,
or accessories without prior notice. For the warranty information, please
visit www.icydock.com/warranty.php
Cremax Europe GmbH
Weidenweg 21H
47059 Duisburg, Germany
Email: support@icydock.com
Contenu
包装说明
User Manual
Informations dispositif
本体説明
機體說明
3
4
Double
Capacity
HDD Fail
Source
3
6
4
Double
HDD Fail
Source
15 Pin Power
Device Status
RAID 1 array is working properly
Device Status
25%, 50%, 75%, and 100%
RAID 1 rebuilding completed
Device Status
is smaller than the source drive
Double source drives
Device Status
Double source drives
Device Status
Capacity error
Device Status
Drive power /
Drive access /
is smaller than the source drive
Guide d'Installation
操作步驟
MB902SPR-B R1
1
#6-32*6
MB902SPR-B R1
MB902SPR-B R1
デバイス取付手順
デバイス取付手順
M3*6 Screw
M3*6 Screw
M3*2.5 Screw
Modo RAID
JBOD(NON RAID)
The two physical disks are read as two independent
hard drives in a single housing. Therefore, the
computer will show two separate drives.
Note : While in JBOD mode with two drives, make
sure that your system supports Port-Multiplier in
order to detect both drives. If not, only the top drive
will be detected.
I nformations importantes
重要注意事項
IRAID-Überwachungssoftware
RAID监控软件
RAID Information
RAID 1
Normal
298.03 GB
M0, M1
M0(P0)
298.03 GB
M1(P0)
298.03 GB
MB901SPR-B R1
(FatCage RAID)
MB902SPR-B R1
(ToughArmor RAID)
Contenido del paquete
× 10
× 10
× 10
× 10
机体说明
5
Error
5
Capacity
Error
7 Pin SATA
Guía
操作步骤
2
M3*4 Screw
Installation du dispositif
Installation du dispositif
裝置安裝步驟
裝置安裝步驟
RAIDモード
重要注意事項
Logiciel
RAID管理
