- Page 1 ToughArmor Full Metal MiniSAS HD to 8 x 2.5" SAS / SATA Backplane Cage Copyright © ICY DOCK International. All Rights Reserved. 650255 VER 1.0...
- Page 2 Package Contents Packungsinhalt Contenu Contenido del paquete 包裝說明 包装说明 Device User manual Drive ID Plug 8 x M3*2.5 pan head screws for device 32 x M3*4 flat head screws for 2.5" HDD/SSD (2 x Screws for spare parts) (2 x Screws for spare parts) Note: Please use the included screws to secure the device.
- Page 3 Rear View MiniSAS HD Connector 15 Pin Power 3 Pin Fan Header （SFF-8643） Installation Guide Installationsanleitung Guide d'Installation Guía de instalación 製品の組み込み手順について 操作步驟 操作步骤 Push the drive tray ejection button to The drive tray latch will pop open once eject the drive tray. the drive tray ejection button is pushed.
- Page 4 M3*4 screw x 4 This device accommodates drives with up to Use the included M3*4 screws to secure 15mm height. Insert the 2.5” drive upside down the drive onto the tray, then flip the tray into the tray, be sure that the drive’s connector back to the top side.
- Page 5 SAS. 2. ICY DOCK 3. ICY DOCK ne pourra être tenu responsable de la perte ou dégradation de tout logiciels, matériels ou données suite à des dommages ou des disfonctionnements de matériels utilisés avec nos produits ICY DOCK. La responsabilité de ICY DOCK ne pourra être engagées que pour ces propres produits.
- Page 6 Para comprobar sea el dispositivo principal admite la función de intercambio en caliente, consulte las especificaciones y el manual del usuario de la placa base o de la tarjeta controladora. 6. Si tiene alguna pregunta o duda acerca de los productos ICY DOCK, visite nos en el sitio web http://www.icydock.com 1.
