Belleze 014-HG-31060 Manual

Century bed with drawer
Hide thumbs

Advertisement

Table of Contents

Century Bed with Drawer
FOLLOW US:
@bellezefurniture
CONTACT INFO:
support@belleze.com
1-800-682-6376
www.belleze.com
ITEM NO. 014-HG-31060
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 014-HG-31060 and is the answer not in the manual?

Questions and answers

Related Manuals for Belleze 014-HG-31060

Summary of Contents for Belleze 014-HG-31060

  • Page 1 Century Bed with Drawer FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-31060 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
  • Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 70 mins Weight limitations are as follows: Maximum Load 30 lb Maximum Load 700 lb Maximum Load 30 lb...
  • Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.

  • Page 4: Package Contents

    PACKAGE CONTENTS 24 x 16pcs x 10pcs...
  • Page 5 PACKAGE CONTENTS CODE DESCRIPTION Left Headboard Frame Right Headboard Frame Top Panel Socket Panel Back Panel Top Panel Support Slat Cross Rail Headboard Support Rail Support Rail Support Rail Support Rail Center Support Beam Center Support Beam Center Support Frame Support Post Slat Side Rail Support Post...
  • Page 6 PACKAGE CONTENTS 20x + 2x 66x + 6x Install all hardware perpendicular to the opening.
  • Page 7 Required tools for assembly (Not included) Attach top panel support slat (6) to the top panel (3). Assemble the back panel (5) to the top panel (3). v.08232023...
  • Page 8 Attach the power hub to the socket panel (4). Assemble the socket panel (4) to the back panel(5). Use the cable management clips to affix the power cord to the panel. Install wire clamp , this is not a lixed position , the specifie posigion can be adjusted at will.
  • Page 9 Attach the headboard (8) under the socket panel (4). Assemble the headboard assembly and the crossrail (7) between the headboard frames (1, 2). Be aware of the orientatioin of the rail. v.08232023...
  • Page 10 Assemble the side rail support posts (18) to the sides of the center support frame (15) Attach support posts (16) under center support beams (13, 14).
  • Page 11 Attach support rails (9, 10, 11, 12) into the side rail support posts (18). v.08232023...
  • Page 12 Assemble the center support beams (13, 14) to the center support frame (15).
  • Page 13 Assemble the support rails (9, 10) and the center support beam (13) to the headboard assembly. v.08232023...
  • Page 14 Assemble footboard (21) to the other end of the bed frame assembly. Secure the center support beam (14) to the footboard (21).
  • Page 15 Attach decoration panels (19, 20) to the support rails (9, 10). Further secure the decoration panels to the headboard frame. v.08232023...
  • Page 16 Assemble slats (17) to the bedframe.
  • Page 17 Unfold the drawer tray (22). Assemble 4 drawers. v.08232023...
  • Page 18 Assemble drawer rollers (24) underneath the drawer tray (22). Turn the drawers over to assemble the rollers. Assemble the drawer front panel (23) the drawer tray.
  • Page 19 Attach hanging bolts to the drawer front panel (23). Note:Please don't fulltighten two F screws attop positions on the board. Slide the drawers under the bedframe and hang the drawer to the side rails. When you pull out the drawer, lift it up a bit. Connect the power adapter to the LED light strip cable, then plug the power adapter to power outlet.
  • Page 20 USER INSTRUCTION (LED LIGHT REMOTE CONTROL) Auto Loop Mode Selection Brightness Speed Control Control Static Color Shortcut Selection Light Color Control Rhythm Rhythm Remote Control Lock MODE - 3 colors spectrum cycling - 7 colors spectrum cycling - mixed colors cycling - 7 colors strobe COLOR CONTROL Press the color button to select 1 of the 16 static light color options.
  • Page 21 USER INSTRUCTION (LED LIGHT REMOTE CONTROL) BRIGHTNESS / SPEED There are 10 levels of brightness and speed setting. NOTE: Speed control does not work when the light strip is showing static color. AUTO REMOTE CONTROL LOCK Press the lock button to lock any remote control input. When lock function is enabled, only the ON, OFF and lock button will be functional.

  • Page 22: Maintenance

    FURNITURE CARE AND MAINTENANCE Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE • •...
  • Page 23 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.08232023...

  • Page 24: Warranty

    WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
