Belleze Brent 014-HG-31020 Assembly Instructions Manual

Bed with drawer
Hide thumbs Also See for Brent 014-HG-31020:

Advertisement

Quick Links

Download this manual
Brent Bed with Drawer
FOLLOW US:
@bellezefurniture
CONTACT INFO:
support@belleze.com
1-800-682-6376
www.belleze.com
ITEM NO. 014-HG-31020
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Brent 014-HG-31020 and is the answer not in the manual?

Questions and answers

Related Manuals for Belleze Brent 014-HG-31020

Summary of Contents for Belleze Brent 014-HG-31020

  • Page 1 Brent Bed with Drawer FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-31020 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
  • Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 50 mins Weight limitations are as follows: Maximum Load 30 lb Maximum Load 700 lb Maximum Load 30 lb...
  • Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.

  • Page 4: Package Contents

    PACKAGE CONTENTS...
  • Page 5 PACKAGE CONTENTS CODE DESCRIPTION Headboard Frame LED Top Panel Back Rail Headboard Socket Panel Cross Rail Side Rail Footboard Slat Center Support Beam Support Post Support Rail Slat Drawer Front Panel Drawer Tray Drawer Roller Required tools for assembly (Not included) v.12082022...
  • Page 6 PACKAGE CONTENTS 16x + 1x 2x + 1x 4x + 1x 40x + 2x 14x + 1x 3x + 1x Install all hardware perpendicular to the opening.
  • Page 7 Assemble the power outlet hub to the socket panel (5). v.12082022...
  • Page 8 Assemble the LED top panel (2), headboard (4), and cross rail (6) between the headboard frames (1). Leave bolts 80% tightened. Be aware of the orientatioin of the rail.
  • Page 9 Assemble the back rail (3) between the headboard frames (1). Leave bolts 80% tightened. Be aware of the orientatioin of the rail. v.12082022...
  • Page 10 Assemble the socket panel (5) on top of the back rail and the headboard (3, 4). Leave bolts 80% tightened. LED strip should be installed to the round corner of the panel. LED strip should be installed to the round corner of the panel. Install wire clamp,this is not a lixed position, the specifie position can be adjusted at will.
  • Page 11 Unfold the side rails. (7) WARNING v.12082022...
  • Page 12 Assemble the side rails (7) between the headboard frames (1) and the footboard slat (8). Leave bolts 80% tightened.
  • Page 13 Unfold the center support beam (9). WARNING Assemble the support posts (10) to the center support beam (9). Leave bolts 80% tightened. v.12082022...
  • Page 14 Assemble the center support beam (9) to the cross rail (6). Leave bolts 80% tightened.
  • Page 15 Assemble the center support beam (9) to the footboard slat (8). Leave bolts 80% tightened. v.12082022...
  • Page 16 Assemble the support rail (11) on top of the center support beam and the side rails. Leave bolts 80% tightened.
  • Page 17 Assemble slats (12) to the bed frame. v.12082022...
  • Page 18 Tighten all the bolts.
  • Page 19 Unfold the drawer tray (14) to an upright position. Assemble 4 drawers. v.12082022...
  • Page 20 Assemble drawer rollers (15) underneath the drawer tray (14). Assemble the drawer tray (14) to the drawer front panel (13)
  • Page 21 Attach a M4 x 14 keyhole bolt to the drawer front panel. Slide the drawers under the bedframe and hang the drawer to the side rails. When you pull out the drawer, lift it up a bit. YOU’RE FINISHED! v.12082022...

  • Page 22: User Instruction

    USER INSTRUCTION Remote Control The remote control comes paired with the unit. Maximum range of remote control is about 15 meters Power Button Press the power button to turn on the light or switch to standby mode. Mode + / Mode − Button Press the mode buttons to change from static color mode to dynamic modes.
  • Page 23 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE.

  • Page 24: Warranty

    WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
