Brent Bed with Drawer
FOLLOW US:
@bellezefurniture
CONTACT INFO:
support@belleze.com
1-800-682-6376
www.belleze.com
ITEM NO. 014-HG-31020
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 014-HG-31020 and is the answer not in the manual?

Questions and answers

Related Manuals for Belleze 014-HG-31020

Summary of Contents for Belleze 014-HG-31020

  • Page 1 Brent Bed with Drawer FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-31020 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
  • Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 50 mins Weight limitations are as follows: Maximum Load 30 lb Maximum Load 700 lb Maximum Load 30 lb...
  • Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.

  • Page 4: Package Contents

    PACKAGE CONTENTS 1 x2 14 x16 6 x2 11 x12 9 x2 13 x4 12 x4...
  • Page 5 PACKAGE CONTENTS CODE DESCRIPTION Headboard Frame LED Top Panel Back Rail Headboard Cross Rail Side Rail Footboard Slat Center Support Beam Support Post Support Rail Slat Drawer Front Panel Drawer Tray Drawer Roller Required tools for assembly (Not included) v.04272023...
  • Page 6 PACKAGE CONTENTS 12x + 1x 12x+1x 44x + 4x Install all hardware perpendicular to the opening.
  • Page 7 Assemble the power outlet hub to the socket panel (3). Assemble the socket panel (3) to the headboard (4). Use the cable management clips to arrange the power cord. Install wire clamp,this is not a lixed position, the specifie position can be adjusted at will. v.04272023...
  • Page 8 Assemble the LED top panel (2), headboard (4), and cross rail (5) between the headboard frames (1). LED strip should be installed to the round corner of the panel. Be aware of the orientatioin of the rail. Leave bolts 80% tightened.
  • Page 9 Unfold the side rails. (6) WARNING keep fingers away from the joints to avoid injury 。 v.04272023...
  • Page 10 Assemble the side rails (6) between the headboard frames (1) and the footboard slat (7). Leave bolts 80% tightened.
  • Page 11 Unfold the center support beam (8). WARNING keep fingers away from the joints to avoid injury 。 Assemble the support posts (9) to the center support beam (8). Leave bolts 80% tightened. v.04272023...
  • Page 12 Assemble the center support beam (8) to the cross rail (5). Leave bolts 80% tightened.
  • Page 13 Assemble the center support beam (8) to the footboard slat (7). v.04272023...
  • Page 14 Assemble the support rail (10) on top of the center support beam and the side rails. Leave bolts 80% tightened.
  • Page 15 Assemble slats (11) to the bed frame. v.04272023...
  • Page 16 Unfold the drawer tray (13) to an upright position.
  • Page 17 Assemble drawer rollers (14) underneath the drawer tray (13). Turn the drawers over to Insert the rollers， attach the screws from the surface. Assemble the drawer tray (13) to the drawer front panel (12) v.04272023...
  • Page 18 Attach a M6 x 15 keyhole bolt to the drawer front panel. Slide the drawers under the bedframe and hang the drawer to the side rails. When you pull out the drawer, lift it up a bit. YOU’RE FINISHED!
  • Page 19 FLASH7 STROBE7 FLASH16 STROBE16 RF Remote Controller USER INSTRUCTION (REMOTE CONTROL)
  • Page 20 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
  • Page 21 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.04272023...

  • Page 22: Warranty

    WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
