ASSEMBLY INSTRUCTION
OM E L E A N CE
G
2020TBK-1 METAL TWIN BED
PART LIST:
A:LSF Headboard Post
B:RSF Headboard Post
C:LSF Footboard Post
D:RSF Footboard Post
1PC
1PC
1PC
1PC
E:Headboard/Footboard
H:Rail Support Leg
F:Rail section(1)
G:Rail section(2)
2PCS
2PCS
2PCS
2PCS
J:Center support Bar
O:Slat Connector
P:Finial
N:Slat
1PC
16PCS
32PCS
4PCS
HARDWARE LIST:
Q*20PCS
R*4PCS
S*4PCS
U*1PC
V*1PC
1/4*13MM
1/4*32MM
1/4
Advertisement
Related Manuals for Homelegance Averny 2020TBK-1
Summary of Contents for Homelegance Averny 2020TBK-1
- Page 1 ASSEMBLY INSTRUCTION OM E L E A N CE 2020TBK-1 METAL TWIN BED PART LIST: A:LSF Headboard Post B:RSF Headboard Post C:LSF Footboard Post D:RSF Footboard Post E:Headboard/Footboard H:Rail Support Leg F:Rail section(1) G:Rail section(2) 2PCS 2PCS 2PCS 2PCS J:Center support Bar O:Slat Connector P:Finial N:Slat...
- Page 2 N ote: Pls do not tighten all bolts until the bed is assembled completely STEP 1 STEP 2 STEP 3 STEP 4 STEP 5...
