Addictive Desert Designs AC11044NA01 Installation Manual

AC11044NA01
TOOLS REQUIRED
(Socket) 9/16, 7/16
(Wrench) 9/16, 7/16
(Allen) 7/32, 5/16
(Torx) T50
(Drill Bit) 25/64
1/4-20" Rivet Nut Mandrel
Rivet Nut Hand Tool
Ratchet
SKILL
-Easy/Intermediate
-BEFORE YOU INSTALL THIS KIT-
Read and understand all instructions, warnings,
cautions, & notes contained in this installation
instruction guide. Consult your vehicle owner's manual
for proper disconnection of electrical and lifting of
vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel
that you are capable of performing this install please
take this product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service (480) 671-0820
17-20/FORD RAPTOR
LEVEL
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
Addictive desert designs is not responsible for any
bodily injury or harm to you or your vehicle as a result
of an improper install.
Proper installation of this kit required knowledge of
the factory recommended procedures for removal and
installation of original equipment components.
We recommend that the factory shop manual and
any special tools needed to service your vehicle be
on hand during the installation. Installation of this kit
without proper knowledge of the factory recommended
procedures may affect the performance of these
components and the safety of the vehicle.
INSTALLATION
BED CAB MOLLE
AC11046NA01 AC11045NA01
TIME REQUIRED
- 1 hours for OEM Removal/molle Install
INCLUDED IN KIT
8- 3/8-16 X 1" Button Head Bolt
8- 3/8" Flat Washer
8- 3/8-16" Nylon Lock Nut
14- 1/4-20 X 3/4" Button Head Bolt
22- 1/4" Flat Washer
8- 1/4-20" Nylon Lock Nut
6- 1/4-20" Rivet Nut
Inspect all contents of this package to make sure
product is not damaged and all installation hardware
has been included. If parts are missing from kit, please
be prepared to provide the following information:
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
*ALWAYS WEAR EYE PROTECTION
WHEN OPERATING POWER TOOLS*
