VideoMate W800F TV Box Connection
USB Input
* The USB port for multimedia files playback only supports USB pen
driver, not support USB external hard drive.
Composite
Stereo Audio
Video Input
Input (L/R)
Power Adaptor
Line-Out to Speaker
Line-In from the Line-Out
connector of sound card
Connect to monitor by
VGA cable
Connect from TV box to
VGA card by 9-pin
Mini-DIN to 15-pin D-Sub
cable in the package
FM Antenna Input
DVB-T or Analog TV
Cable/Antenna Input
9-pin Mini-DIN to
S-video and component
video input
