VideoMate V600 TV Box Hardware Guide

Power SW
(Hold 2 sec.)
Ear Phone
Jack
4
Channel +
Volume –
Channel –
15 pin D-sub
Component Input (Y/Cb/Cr)
Composite (L&R Audio, Video) S-Video
Menu
Volume +
12V Power Jack
Line In from PC
Line Out to Speaker
Connect to Computer
(15 pin D-sub input)
Connect to Monitor
(15 pin D-sub output)
TV Cable/Antenna
Input
