VideoMate V550 TV Box Software Guide

Using at the first time
Please refer to the above for correct setup to use V550 TV Box. After you have
connected the power adaptor, you will see orange light shining out from the
side. Press the Power switch at the top will turn on the TV Box and you will see
orange light become blue light. Now you may enjoy the TV Show.
If you have connect V550 TV box to your computer's video card, press the
power button on the TV box or the power button on the remote control will
switch between TV and PC signal. You may also press "TV/PC" button on the
remote control to achieve the same result.
Order of the Sources: TV > Composite > S-Video > Component > TV
VideoMate V550 TV Box supports 7 resolutions from below. Each resolution
Supports 60Hz and 75Hz. The default setting is 1024*768 @ 60Hz.
Resolution 1 -> 640*480 (4:3)
Resolution 2 -> 800*600 (4:3)
Resolution 3 -> 1024*768 (4:3)
Resolution 4 -> 1280*1024 (5:4)
Resolution 5 -> 1280*720 (16:9)
Resolution 6 -> 1440*900 (16:10)
Resolution 7 -> 1600*1200 (4:3)
To change resolution, please open up menu and select the resolution you want.
Refer to later instruction for more detail. "RES" button from the remote
controller can also switch the resolution.
OSD Menu Guide
Menu button will open up OSD Menu, please use the direction key to navigate.
(Picture)
Brightness
Contrast
Saturation
Sharpness
Hue
Y/C Sep. Mode
Reset
6
(TV) (Monitor)
Adjust the brightness (0~100) Default : 50
Adjust the Contrast (0~100)
Adjust the Saturation (0~100)
Adjust the Sharpness (0~15)
Adjust the Hue ( 0~100)
Choose between 2D/3D mode
Reset Picture Settings
(OSD)
Default : 50
Default : 50
Default : 0
Default : 50
Default : 3D Mode
(Sound)
