Bearing Type
*
Ball Bearings
Material
*
Impeller & Frame : Plactic (UL 94V-0)
Lead Wires :
*
UL 1061 AWG #24 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
Weight : 130g (4.59 OZ)
*
MODEL
PART NO.
REV. FUNCTION
FFB0612UHE
-A
R00 / F00
FFB0612DHE
-A
R00 / F00
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
FFB
DIMENSIONS DRAWING
■
(1.496±0.020)
P & Q CURVE
■
2.40
60.0
2.00
50.0
1.60
40.0
1.20
30.0
0.80
20.0
0.40
10.0
0
0
0
0.45
0
Operating
Rated
Input
Voltage
Voltage
Current
Range
VDC
VDC
Amp
12
7.0 to 13.2
0.90
12
7.0 to 13.2
1.50
60 x 60 x 38 MM SERIES
38.0±0.5
2-4.0±0.3
(2-0.157±0.012)
10.0
(0.394)
370.0±10.0
(14.567±0.394)
(AT RATED VOLTAGE)
FFB0612XE-A
DH
UH
(M 3 /MIN)
0.90 1.35
1.80
2.25
18.0
36.0
54.0
72.0
(CFM)
Air Flow
Input
Speed
Power
Watt
R.P.M.
m
3
10.80
11000
1.654
18.00
13000
1.970
60.0±0.5
(2.362±0.020)
50.0±0.3
(1.969±0.012)
LABEL
8-ø4.5±0.3
(8-ø0.177±0.012)
MOUNTING PANEL CUTOUT
■
OUTLET SIDE
57.4
(2.260)
50.0
(1.969)
4-ø4.5
(4-ø0.177)
Maximum
Maximum
Air Flow
Air Pressure
/min
CFM
mmH
O
2
58.42
39.40
69.55
52.47
http://www.deltaww.com
mm
UNIT:
(INCH)
INLET SIDE
57.4
(2.260)
50.0
(1.969)
4-ø4.5
(4-ø0.177)
mm
UNIT:
(INCH)
Noise
IN H
O
dB-A
2
1.551
60.0
2.066
64.0
