Bearing Type
Ball Bearings
*
Material
Impeller & Frame : Plastic(UL 94V-0)
*
Lead Wires :
UL 1061 AWG #24 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
*
Weight : 50g (1.766 OZ)
MODEL
PART NO.
FUNCTION
GFB0412SHE -R00 / -F00
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
GFB
DIMENSIONS DRAWING
P & Q CURVE
0.72
18.0
0.60
15.0
0.48
12.0
0.36
9.0
0.24
6.0
0.12
3.0
0
0
0
0
Operating
Rated
Input
Voltage
Voltage
Current
Range
VDC
VDC
Amp
12
7.0 to 13.2
0.56
40 x 50 x 38 MM SERIES
(AT RATED VOLTAGE)
GFB0412XE
3
.15
.30
.45
.60
.75
(M /MIN)
6.0
12.0
18.0
24.0
(CFM)
Air Flow
Input
Speed
Power
(Front /Rear)
Watt
R.P.M.
6.72
10000/9600
0.630
74
MOUNTING PANEL CUTOUT
OUTLET SIDE
Maximum
Maximum
Air Flow
Air Pressure
CFM
mmH O
IN H O
2
22.25
15.09
0.594
http://www.deltaww.com
mm
UNIT:
(INCH)
INLET SIDE
mm
UNIT:
(INCH)
Noise
dB-A
2
57.5
