Delta Electronics Exhaust Fan GFB Series Specification

Bearing Type
*
Ball Bearings
Material
*
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires : UL 1061 AWG #26
*
OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 84g (2.96 oz)
*
MODEL
PART NO. REV. FUNCTION
GFB0412SHS -A -R00 / -F00
GFB0412EHS -A -R00 / -F00
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
GFB
DIMENSIONS DRAWING
P & Q CURVE
Operating
Rated Input
Voltage
Voltage Current
Range
Amp
VDC VDC
12 7.0 to 13.2 1.02
12 7.0 to 13.2 1.40
40 x 40 x 56 MM SERIES
Air Direction
(AT RATED VOLTAGE)
Speed
Input
(Front /Rear)
Power
Watt R.P.M .
12.24 16200/7800 0.659
16.80 16200/12000 0.762
72
MOUNTING PANEL CUTOUT
OUTLET SIDE
Maximum Maximum
Air Flow Air Pressure
mmH
CFM O IN H
2
23.29 44.41 1.748
26.92 45.76 1.802
mm
UNIT:
(INCH)
INLET SIDE
mm
UNIT:
(INCH)
Noise
O dB-A
2
58.5
62.5
