Delta Electronics FFB1012EHE Dimensions And Installation Information

Bearing Type
*
Ball Bearings
Material
*
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires :
*
UL1007AWG#24 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 350g (12.34 oz)
*
MODEL
PART NO. FUNCTION
FFB1012EHE -R00 / -F00
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
FFB

DIMENSIONS DRAWING

P & Q CURVE
0.96
24.0
0.80
20.0
0.64
16.0
0.48
12.0
0.32
8.0
0.16 4.0
0 0
0
0
Operating
Rated Input
Voltage
Voltage Current
Range
VDC VDC Amp
12 7.0 to 12.6 2.20
100 x 100 x 38 MM SERIES
(AT RATED VOLTAGE)
FFB1012EHE
EH
3
(M /MIN)
0.9 1.8 2.7 3.6 4.5
(CFM)
35.0 70.0 105.0 140.0
Air Flow
Input
Speed
Power
Watt R.P.M.
26.40 5000
60

MOUNTING PANEL CUTOUT

OUTLET SIDE
Maximum Maximum
Air Flow Air Pressure
CFM mmH O
2
4.052 143.09 21.19
mm
UNIT:
(INCH)
INLET SIDE
mm
UNIT:
(INCH)
Noise
IN H O dB-A
2
0.835 62.0
