VideoMate V150/V150F TV Box Using Guide

Using at the first time
Please refer to the above for correct setup to use V150/V150F TV box. After
you have connected the power adaptor, you can press the power switch to turn
on the TV box and you will see the green LED light beside the power button.
The default TV settings will be your local country and TV system, and you can
change it from OSD menu later. Now you may enjoy the TV shows on your
monitor.
If you have connect V150/V150F TV box to your computer's video card, press
the power button on the TV box to switch between TV and PC signal.
Order of the Sources: TV
VideoMate V150/V150F TV Box supports 60 and 75 Hz with 9 resolutions from
below. The default setting is 1024*768 @ 60Hz.
Resolution 1 -> 640*480 (4:3)
Resolution 2 -> 800*600 (4:3)
Resolution 3 -> 1024*768 (4:3)
Resolution 4 -> 1280*720 (16:9)
To change resolution, please open up menu and select the resolution you want.
Refer to later instruction for more detail. "Resolution" button from the remote
controller can also switch the resolution.
If using PIP feature, the refresh rates in Windows support resolutions below:
Resolution
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 1024
1280 x 720
1440 x 900
1400 x 1050
AV (Composite)
Resolution 5 -> 1280*1024 (5:4)
Resolution 6 -> 1400*1050 (4:3)
Resolution 7 -> 1440*900 (16:10)
Support Refresh Rate
60 Hz 70 Hz
Yes
Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
S-Video
72 Hz
- Yes
- Yes
Yes
-
Yes
Yes
Yes
Yes
FM TV...
75 Hz
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
9
