INSTALLATION GUIDE
THE CENTRIFUGAL FANS
VCN 100
VCN 125
VCN 150
VCN 200
INSTALLATION
Pencil
INSTALLATION AND MOUNTING GUIDELINES
The fans are used for vertical mounting in stack outlets
Disconnect the fan from power supply. Remove the fan cover.
Vents-US
400 Murray Road, Cincinnati, OH 45217, USA
Tel: 1-888-640-0925, 513-583-5786, Fax: 513-268-4597
E-mail: support@ventsus.com
www.vents-us.com
Drill (Ø 6 mm))
Tools required
Screwdriver
Dowel NTW 6/35 (4 pcs.)
Screws 4x35 mm (4 pcs.)
MIU_20EN-01
Advertisement
Related Manuals for Vents VCN 100
Summary of Contents for Vents VCN 100
- Page 1 INSTALLATION GUIDE THE CENTRIFUGAL FANS VCN 100 VCN 125 VCN 150 VCN 200 INSTALLATION Tools required Pencil Drill (Ø 6 mm)) Screwdriver Dowel NTW 6/35 (4 pcs.) Screws 4x35 mm (4 pcs.) INSTALLATION AND MOUNTING GUIDELINES The fans are used for vertical mounting in stack outlets Disconnect the fan from power supply.
