INSTALLATION INSTRUCTION
Important Instructions. Please read first
•
Please follow instructions carefully. Failure to do so will void the
local law and applicable standards.
1.
Ensure correct input v oltage is supplied to the luminaire.
2.
Ensure the power is disconnected before making any connections.
3.
Do not make modification nor alter the luminaire without written approv al from GLP.
4. Ensure to keep luminaire in a clean area free of debris.
INSTALLATION
•
Step 1:
Find the location where the luminaire has to be installed. Install a suitable wiring ( armoured cable) from
the main supply (110-260V AC, 50/60Hz)) to the luminaire.
•
Step 2:
Unscrew and remov e the bottom plate of the luminaire as illustrated.
•
Step 3:
Mount the bottom plate of the luminaire onto a hard surface using appropriate stainless steel
screws as illustrated. Maintain foundation height 50mm abov e the ground for softscape installation.
www.globallightllc.com
.
info@globallightllc.com
warranty.
Please ensure installation complies with
Tel: +971 4 340 44 58
BL220270
Fax: +971 4 341 10 90
Advertisement
Related Manuals for Global Light & Power LCC BL220270
Summary of Contents for Global Light & Power LCC BL220270
- Page 1 INSTALLATION INSTRUCTION BL220270 Important Instructions. Please read first • Please follow instructions carefully. Failure to do so will void the warranty. Please ensure installation complies with local law and applicable standards. Ensure correct input v oltage is supplied to the luminaire.
- Page 2 • Step 4: Connect the luminaire input cable to the main supply (110-260V AC, 50/60Hz) using a waterproof KIT. Ensure the waterproof KIT is installed within 30cm from the luminaire as illustrated. Please make sure the earth (ground) wire is reliable. •...
