Nuvo 60/540 Assembly Instruction

NOTE:
Please consult a qualified electrician if you are not certain of the installation.
CAUTION:
Before starting the installation, disconnect the power by turning off the circuit breaker or by
removing the fuse at the fuse box.
1. Fasten the provided 2 mounting screws to the cross bar to outlet box using 2 outlet box screws provided.
(Make sure the thread of the mounting screws are facing outside when the cross bar is attached to the
outlet box)
2. Connect the white wire to white and black to black. Cover the connections using the wire connectors
provided. Tie the ground wire from outlet box and from fixture to the ground screws on the cross bar.
3. Placing the fixture body to the wall by aligning the protruding mounting screw all the way through the
wall plate and tighten the fixture using 2 lock nuts provided. Fasten the fixture until it is held firmly to the
wall.
4. Install bulb (Not included). Place the top cover onto the top of the lamp compartment, and secure in poison
using the decorative head screws provided.
5. Thread the nipple into the bottom of lamp compartment. Screw the tail section onto the bottom of nipple.
6. Turn on the power.
ASSEMBLY INSTRUCTION
SKU#60/540/541/542
A Satco Product
